Alpa RT 800 Surface Grinding Machine

Get a Price/Quote

MOQ : 1 Piece

Alpa RT 800 Surface Grinding Machine Specification

Rotation
Rotary Table Controlled

Model
RT 800

Product Type
Surface Grinding Machine

General Use
Surface Grinding of Metal Parts

Material
Cast Iron

Type
Rotary Table Surface Grinder

Capacity
High Precision Grinding

Weight (kg)
Approx 3500 kg

Computerized
No

Automatic
No

CNC Or Not
No

Control System
Manual

Table Size
800 x 400 mm

Table Slide Way
Box Type

Magnetic Chuck Size
800 x 400 mm

Grinding Wheel Size
350 x 40 x 127 mm

Grinding Wheel Speed
1450 RPM

Grinding Length
800 mm

Floor Space
2600 x 2400 mm

Fuel Tank Capacity
60 Litres

Spindle Speed
1450 RPM

Power
7.5 kW

Voltage
415 V

Dimension (L*W*H)
2600 x 2400 x 1800 mm

Feature
Sturdy Structure, High Accuracy, Efficient Performance

Color
Standard Grey/Blue

Noise Level
< 80 dB

Installation Type
Floor Mounted

Coolant System
Included

Surface Finish
<=0.003 mm

Lubrication
Automatic Centralized Lubrication

Minimum Increment
0.005 mm

Chuck Rotation Speed
5~30 RPM (Variable)

Cross Feed Travel
420 mm

Vertical Feed Travel
450 mm

Table Drive Type
Hydraulic

Hydraulic System
Integrated

Max Table Load
400 kg

About Alpa RT 800 Surface Grinding Machine

Make - Alpa (Italy)

Model - RT 800

Magnet Size - 800 mm x 300 mm

Grinding Wheel Size - Diameter 300 mm x 40 mm Width

Max. Distance b/w Magnet Top & Wheel-Axis - 360 mm

Cross Travel of Wheel-Head - 400 mm

- With Motorised Rapid Vertical Travel.

- Equipped with a Wheel-Dresser.

- Machine is in excellent working condition.

Video link - https://youtu.be/QIn8ur4nRC0

Precision Surface Grinding for Enhanced Productivity

The Alpa RT 800 ensures surfaces are ground to a finish of 0.003 mm, thanks to its rotary table and high-precision hydraulic drive. With a minimum increment of 0.005 mm, operators benefit from meticulous adjustment and consistently excellent results across a wide range of metal parts. Its sturdy build and efficient performance make it an asset in high-capacity workshops.

Operator Comfort and Safety Prioritized

This machine is engineered for a quiet operation (<80 dB) and includes automatic centralized lubrication to reduce manual intervention and maintenance downtime. The floor-mounted design offers stability, while integrated coolant and hydraulic systems foster safer, more controllable grinding processes for both experienced and new users.

FAQs of Alpa RT 800 Surface Grinding Machine:

Q: How do I operate the Alpa RT 800 Surface Grinding Machine safely and efficiently?

A: To operate the RT 800 safely, ensure the machine is securely floor-mounted and the magnetic chuck is clean and properly holding your workpiece. Before starting, check the coolant and hydraulic systems. Adjust the rotary table speed to match your material and desired finish, set the grinding increments, and use the manual control system for precise feed adjustments.

Q: What surface finish quality can the Alpa RT 800 achieve on metal parts?

A: The RT 800 can achieve a surface finish as fine as 0.003 mm, ensuring high precision on a variety of metal components. Its rotary table and high-speed grinding wheel enable consistent and smooth results, making it ideal for applications that demand close tolerances and fine finishes.

Q: When should I use the coolant system included with the RT 800?

A: The coolant system should be used during all grinding operations to minimize heat buildup, reduce friction, and extend the life of the grinding wheel. It also helps in achieving better surface finishes and protects both the workpiece and machine from overheating.

Q: Where is the Alpa RT 800 best installed for optimal performance?

A: The machine is designed for floor mounting and requires a dedicated space of 2600 x 2400 mm to accommodate its dimensions and allow easy access for operation and maintenance. Install in well-ventilated workshops with adequate electrical power supply (415 V) and flooring capable of supporting its 3500 kg weight.

Q: What benefits do the hydraulic drive and centralized lubrication system offer?

A: The integrated hydraulic system provides smooth, variable speed control for the table and chuck, enhancing operational precision. Automatic centralized lubrication reduces maintenance time and wear, keeping the machines moving parts in optimal condition and extending its operational lifespan.

Q: How do I maintain the RT 800 for consistent high accuracy and performance?

A: Regularly check and refill the coolant and hydraulic fluid tanks, ensure the automatic lubrication system is functioning properly, and inspect wear parts such as grinding wheels and slide ways. Cleaning the magnetic chuck and workspace after each use will also help maintain ongoing high accuracy and efficient performance.

Q: What types of metal parts can be processed with the Alpa RT 800?

A: The RT 800 is suitable for surface grinding of various metal parts, including large workpieces up to 400 kg. It is commonly used in manufacturing, engineering, and metalworking industries for high precision finishing tasks on components requiring tight tolerances.
