Jones & Shipman 1400 High-Precision Surface Grinder

Name: Jones & Shipman 1400 High-Precision Surface Grinder
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Jones & Shipman 1400 High-Precision Surface Grinder Specification

Model
1400

Rotation
Grinding Wheel Rotates Clockwise

Product Type
High-Precision Surface Grinder

General Use
Precision Surface Grinding

Material
Cast Iron, Heavy Duty Construction

Type
Surface Grinder

Capacity
High Precision

Weight (kg)
980

Computerized
No

Automatic
No

CNC Or Not
Not CNC (Manual)

Control System
Manual

Table Size
22 x 6 (560mm x 152mm)

Table Slide Way
Vee & Flat

Magnetic Chuck Size
18 x 6 (457mm x 152mm)

Grinding Wheel Size
8 x 0.75 x 1.25 (200mm x 19mm x 32mm)

Grinding Wheel Speed
2800 RPM

Grinding Length
18 (457mm)

Floor Space
69 x 45 (1750mm x 1150mm)

Spindle Speed
2800 RPM

Power
3 HP

Voltage
415V / 3Ph

Dimension (L*W*H)
69 x 45 x 67 (1750mm x 1150mm x 1700mm)

Feature
Hand Feed, Microfeed Adjustment, Coolant Pump, Dust Guard

Color
Grey

Cross Feed Graduation
0.05mm

Coolant System
Fitted As Standard

Maximum Height Under New Wheel to Table
13" (330mm)

Longitudinal Table Travel
20" (508mm)

Vertical Feed Graduation
0.002mm

Table Speed
0.5 - 25 m/min (variable, manual)

Max Workpiece Weight
120 kg (with magnetic chuck)

Lubrication
Centralized

Hydraulic Table Feed
Optional

T-Slot Size
Width 0.75" (19mm)

Jones & Shipman 1400 High-Precision Surface Grinder Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Jones & Shipman 1400 High-Precision Surface Grinder

Make - Jones & Shipman (England)

Model - 1400

Magnet Size - 204 mm x 610 mm

Grinding Wheel Size - Diameter 204 mm x 20 mm Width

Max. Height between Magnet to Wheel Center - 295 mm

Least Count of Vertical Travel - 1 Micron (0.001 mm)

Least Count of Cross Travel - 2.5 Micron (0.0025 mm)

Graduations on Dials - Metric (in mm)

- With Motorised Vertical Travel of the Wheel-Head.

- Equipped with Diaform make Profile Wheel Dressing Unit.

- Complete with Dust Collector Unit.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/o9qJRmHgi_I

Precision Engineered for Demanding Applications

With a high precision capacity and manual hand-feed controls, the Jones & Shipman 1400 is suitable for a variety of surface grinding applications where utmost accuracy is required. Its microfeed adjustment enables users to machine components within the tightest tolerances, making this grinder ideal for toolmaking, die maintenance, and component finishing in industrial settings.

Versatile Design and Construction

Built from heavy-duty cast iron and featuring a centrally-lubricated system, the Jones & Shipman 1400 assures long-term durability and stable operation. The grinder accommodates a range of workpiece sizes and shapes thanks to its spacious 22 x 6 inch table and 120 kg magnetic chuck capacity. Fitted with a dust guard and coolant pump as standard, it supports clean and efficient production environments.

User-Friendly Operation with Enhanced Safety

This surface grinder is operated manually, offering total control over table speed, cross feed, and vertical feed. Clear graduations, a reliable hydraulic table feed option, and a clockwise-rotating grinding wheel at 2800 RPM provide professional machinists with confidence during extended sessions. Its ergonomic design and robust safety features make it a popular choice for both manufacturers and suppliers.

FAQ's of Jones & Shipman 1400 High-Precision Surface Grinder:

Q: How does the hand feed system benefit the operation of the Jones & Shipman 1400 surface grinder?

A: The hand feed system gives users precise manual control over table movement and feed rate, ensuring accurate surface finishes and minimizing the risk of over-grinding. This feature is especially valuable when working on fine tolerances or when gradual feed rates are essential for complex workpieces.

Q: What is the process for using the fitted coolant system on this grinder?

A: The fitted coolant system is activated during grinding operations to minimize heat buildup, reduce friction, and flush away debris. This not only helps prolong the life of the grinding wheel and the workpiece but also improves the quality of the surface finish. Simply ensure the coolant reservoir is filled and the pump is running before starting the grinding process.

Q: When should the centralized lubrication system be refilled or checked?

A: It is recommended to check the centralized lubrication system daily or before each use, particularly during intensive operations. Regular refill and maintenance are crucial to keep all moving parts well-lubricated, ensuring smooth and consistent grinder performance and extending machine lifespan.

Q: Where can the Jones & Shipman 1400 surface grinder be installed for optimum performance?

A: Install the grinder on a solid, level foundation in a well-ventilated workspace. Ensure ample clearance around the 69 x 45 inch floor footprint (1750mm x 1150mm) and access to a 415V, 3-phase power supply. Proper setup helps avoid vibration, facilitates maintenance, and ensures operator safety.

Q: What types of materials and parts can be precisely ground with this machine?

A: The Jones & Shipman 1400 is suitable for grinding a wide range of ferrous and non-ferrous metals, tool steels, and hardened materials. Its high precision and adjustable settings make it ideal for finishing machine parts, dies, tools, and precision flat surfaces used in manufacturing, repair, and toolmaking industries.

Q: Is hydraulic table feed necessary for all grinding operations on this model?

A: Hydraulic table feed is optional on this machine. While manual feed is perfectly adequate for many jobs, the hydraulic option offers smoother, more consistent table movement, which is advantageous during longer grinding tasks or when processing heavier workpieces.

Q: What are the main benefits of choosing this surface grinder for my facility?

A: Key benefits include exceptional precision, robust build quality, and a versatile range of adjustments for optimized surface grinding. The inclusion of standard features like a coolant pump, dust guard, and a large magnetic chuck make the Jones & Shipman 1400 a reliable and efficient solution for a wide variety of machining applications.
