Rosa Italy 450 x 1100 Surface Grinding Machine

Name: Rosa Italy 450 x 1100 Surface Grinding Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Rosa Italy 450 x 1100 Surface Grinding Machine Specification

Rotation
Clockwise & Counterclockwise

Model
Rosa Italy 450 x 1100

Product Type
Hydraulic Surface Grinding Machine

General Use
Precision Surface Grinding

Material
Cast Iron

Type
Surface Grinder

Capacity
Heavy Duty

Weight (kg)
Approx. 4500 kg

Computerized
No

Automatic
Semi-Automatic

CNC Or Not
Not CNC

Control System
Manual

Table Size
450 x 1100 mm

Table Slide Way
Double V

Magnetic Chuck Size
450 x 1100 mm

Grinding Wheel Size
350 x 40 x 127 mm

Grinding Wheel Speed
1500 RPM

Grinding Length
1100 mm

Floor Space
Approx. 2800 x 2000 mm

Fuel Tank Capacity
Approx. 100 Litres

Spindle Speed
1800 RPM

Power
7.5 HP

Voltage
415 V

Dimension (L*W*H)
2800 x 2000 x 1900 mm

Feature
High Accuracy, Robust Construction, Smooth Table Movement

Color
Standard

Table Load Capacity
900 kg

Machine Condition
Used/Good

Coolant Pump Motor
0.16 HP

Max Table Travel
1200 mm

Cross Feed Motor
0.37 kW

Lubrication
Centralized Automatic

Hydraulic Motor
2 HP

Table Longitudinal Speed
1 - 25 m/min

Max Distance from Table to Spindle Center
600 mm

Surface Finish
Up to 2 microns

Vertical Feed Graduation
0.005 mm

Rosa Italy 450 x 1100 Surface Grinding Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Rosa Italy 450 x 1100 Surface Grinding Machine

Make - Ermando Rosa (Italy)

Model - RTRC 1100

Job Grinding Size - 450 mm x 1100 mm

Max. Cross Travel - 500 mm

Max. Longitudinal Travel - 1200 mm

Current Magnet Size - 400 mm x 1000 mm

Grinding Wheel Size - Diameter 350 mm x 50 mm Width

Max. Distance b/w Magnet to Wheel Center - 525 mm

- Equipped with a Wheel-Top Mounted Wheel Dresser.

- Complete with Operating Manual, Electrical Drawings etc.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/gxhekoftqgc

Engineered for Precision and Durability

Manufactured in Italy, the Rosa 450 x 1100 surface grinder integrates high-quality cast iron and double V table slide ways for maximum stability and accuracy. Its robust construction supports heavy-duty work, while the manual control system allows skilled operators to fine-tune grinding parameters for every job requirement.

Versatile and User-Friendly Operation

The machine is suitable for a wide range of surface grinding applications, thanks to its generous table size, adjustable speeds, and centralized automatic lubrication. Both clockwise and counterclockwise spindle rotations, along with a 350 mm grinding wheel, enable seamless adaptability to various workpieces and materials.

Optimal Performance and Efficiency

Delivering up to 2-micron surface finishes with a rapid longitudinal table speed (1-25 m/min), this surface grinder promises efficiency in routine and complex tasks. An automatic lubrication system extends its lifespan while semi-automatic operations optimize workflow and precision.

FAQ's of Rosa Italy 450 x 1100 Surface Grinding Machine:

Q: How does the centralized automatic lubrication system benefit the Rosa Italy 450 x 1100 Surface Grinding Machine?

A: The centralized automatic lubrication system ensures that all moving components are continuously and adequately lubricated, which reduces wear, enhances machine accuracy, and extends overall lifespan for reliable long-term performance.

Q: What types of applications is this surface grinding machine suitable for?

A: This machine is ideal for precise surface grinding tasks in tool rooms, manufacturing units, and maintenance workshops, especially where high surface finish and heavy-duty table capacity up to 900 kg are essential.

Q: Where can the Rosa Italy 450 x 1100 Surface Grinding Machine be installed considering its dimensions and weight?

A: With a floor space requirement of approximately 2800 x 2000 mm and a weight of about 4500 kg, the machine should be installed in industrial environments with adequate space and reinforced flooring to support its heavy-duty structure.

Q: How is table movement controlled on this surface grinder?

A: The table movement utilizes a double V slide way system for enhanced stability and smoothness, and its longitudinal speed can be set between 1-25 m/min, allowing operators to adjust to the specific requirements of the grinding application.

Q: What is the process for achieving a high surface finish with this machine?

A: By selecting the appropriate grinding wheel, controlling spindle speed (up to 1800 RPM), setting precise vertical feed graduation (0.005 mm), and utilizing the robust table system, operators can consistently achieve surface finishes up to 2 microns.

Q: What maintenance is required for optimal operation of the grinder?

A: Regular inspection of lubrication levels, coolant system, grinding wheels, and machine alignment is essential. The automatic lubrication system simplifies upkeep, but periodic checks ensure continued high precision and machine reliability.
