Billeter Germany 800 mm Diameter Rotary Surface Grinder

Name: Billeter Germany 800 mm Diameter Rotary Surface Grinder
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Billeter Germany 800 mm Diameter Rotary Surface Grinder Specification

Rotation
Rotary Table

Model
Billeter Germany

Product Type
Rotary Surface Grinder

General Use
Precision surface grinding of metal components

Material
Cast Iron Base, Steel Components

Type
Rotary Type

Capacity
Heavy Duty

Weight (kg)
Approx. 4200 kg

Computerized
No

Automatic
Semi-Automatic

CNC Or Not
Not CNC

Control System
Manual

Table Size
800 mm Diameter

Table Slide Way
Hydraulic

Magnetic Chuck Size
800 mm Diameter

Grinding Wheel Size
Approx. 400 mm Diameter

Grinding Wheel Speed
1450 RPM

Grinding Length
800 mm

Floor Space
Approx. 2500 x 2300 mm

Fuel Tank Capacity
Approx. 80 Liters (Hydraulic Oil)

Spindle Speed
1450 RPM

Power
15 HP

Voltage
415 V, 3 Phase

Dimension (L*W*H)
2500 x 2300 x 2100 mm

Feature
High Precision, Heavy Duty Construction, Magnetic Table

Color
Industrial Grey

Grinding Accuracy
±0.01 mm

Max Workpiece Height
300 mm

Working Speed
Variable

Main Motor
11 kW

Chuck Type
Electromagnetic

Installation Required
Yes

Phase
Three Phase

Cooling System
Yes (Integrated Coolant Facility)

Lubrication System
Automatic Centralized

Suitable For
Tool Rooms, Production Shops, Engineering Industries

Sound Level
Below 80 dB

Table Load Capacity
Up to 1200 kg

Billeter Germany 800 mm Diameter Rotary Surface Grinder Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Billeter Germany 800 mm Diameter Rotary Surface Grinder

Make - Billeter (Germany)

Table Diameter - 600 mm

Segmented Cup Wheel Diameter - 475 mm

Maximum Diameter of the Job - 800 mm

Wheel Type - Segmented ; 12 pcs.

Max. Height of the Job - 375 mm

Magnetic Table Rotation Speeds - 2 rpm to 30 rpm

Magnet Type - Electro-Magnet

Spindle Motor Power - 14 kW

- Motorised Rapid Forward and Backward Travel of Table.

- With Automatic Depth Adjustment "Auto-Cut" feature.

- Complete with Coolant Tank and Pump.

- Electrical Drawings of the machine are available.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/eDVlrueJk6o

Heavy-Duty Precision Grinding

Built for demanding environments, the Billeter Germany 800 mm Rotary Surface Grinder delivers outstanding stability and accuracy for heavy metal components. Its robust cast iron base and steel components minimize vibration, supporting precise surface finishes even during extended operation.

Advanced Features and Safety

Equipped with an electromagnetic chuck and automatic centralized lubrication, this grinder emphasizes operational safety and ease of maintenance. The integrated coolant facility helps reduce heat build-up, improving grinding accuracy and extending wheel life. Its sound level remains below 80 dB, allowing for quieter factory environments.

Versatile and User-Friendly

With variable working speeds and a large, hydraulic-driven rotary table, this surface grinder accommodates various workpiece sizes up to 1200 kg. Manual controls offer users direct command over grinding parameters, making it suitable for both tool rooms and high-volume production settings.

FAQ's of Billeter Germany 800 mm Diameter Rotary Surface Grinder:

Q: How does the integrated coolant facility benefit the grinding process?

A: The integrated coolant facility ensures optimal temperature control during grinding, minimizing thermal distortion of workpieces and preventing overheating of the grinding wheel. This promotes precision, extends tool life, and enhances surface finish quality.

Q: What makes the Billeter Germany 800 mm Rotary Surface Grinder suitable for heavy-duty applications?

A: Its robust construction, with a heavy cast iron base and high-capacity table load (up to 1200 kg), allows the machine to handle large, heavy workpieces with minimal vibration while maintaining grinding accuracy of 0.01 mm.

Q: Where is this rotary surface grinder commonly installed?

A: This grinder is typically installed in tool rooms, production shops, and engineering industries where precision surface finishing of metal components is required. Installation typically requires professional setup due to its size and weight.

Q: What is the process for operating the manual control system?

A: Operators adjust grinding parameters directly via manual controls, enabling fine-tuned grinding settings for each workpiece. The electromagnetic chuck securely holds components, and the hydraulic table drive allows smooth rotation for even material removal.

Q: When should the centralized lubrication system be maintained?

A: The automatic centralized lubrication system requires periodic inspection to ensure continuous, effective lubrication of all moving parts. Maintenance schedules depend on machine usage frequency, but regular checks help maintain optimal performance and prolong machine life.

Q: What are the main benefits of using an electromagnetic chuck on this grinder?

A: The electromagnetic chuck provides secure, consistent workpiece holding without mechanical clamps, enabling faster setups, improved safety, and uniform surface contact during grinding.

Q: How does the semi-automatic operation enhance usability?

A: Semi-automatic features simplify operation by automating certain functions like lubrication and coolant supply, reducing manual intervention and minimizing operator error while retaining direct manual control for process precision.
