Stefor Italy RTE 6_4 Surface Grinding Machine

Name: Stefor Italy RTE 6_4 Surface Grinding Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Stefor Italy RTE 6_4 Surface Grinding Machine Specification

Rotation
Clockwise / Counterclockwise

Model
RTE 6_4

Product Type
Surface Grinding Machine

General Use
Industrial Surface Grinding

Material
Cast Iron, Steel

Type
RTE 6_4

Capacity
Surface area up to 600 x 400 mm

Weight (kg)
Approx. 1750

Computerized
No

Automatic
No

CNC Or Not
Conventional (Not CNC)

Control System
Manual

Table Size
600 x 300 mm

Table Slide Way
V and Flat

Magnetic Chuck Size
600 x 400 mm

Grinding Wheel Size
300 x 76 x 40 mm

Grinding Wheel Speed
1450 RPM

Grinding Length
600 mm

Floor Space
1800 x 1300 mm

Fuel Tank Capacity
40 Litres

Spindle Speed
2850 RPM

Power
4 kW

Voltage
415 V

Dimension (L*W*H)
1800 x 1300 x 1700 mm

Feature
High Precision, Durable Build, Easy Operation

Color
Industrial Grey / Green

Wheel Motor Power
3 HP

Lubrication System
Centralized

Coolant System
Included

Max Table Load
120 kg

Max Grinding Height
350 mm

Installation
Floor-mounted

Table Feed
Manual and Hydraulic (Longitudinal)

Noise Level
Low

Manufacturing Year
Recent Years (Actual year based on availability)

Minimum Increment
0.01 mm

Cross Feed
Manual (Transverse)

Working Speed
Variable

Stefor Italy RTE 6_4 Surface Grinding Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Stefor Italy RTE 6_4 Surface Grinding Machine

Make - Stefor (Italy)

Model - RTE 6/4

Grinding Capacity - 300 mm x 600 mm

Longitudinal Travel of Table - 700 mm

Cross Travel of Table - 400 mm

Grinding Wheel Size - Diameter 350 mm x 50 mm Width

Height between Table Top to Wheel Center - 600 mm

- New Electrical Panel with PLC.

- Equipped with a Hydraulic Top Mounted Wheel Dresser.

- Electrical Drawings, Hydraulic Drawings, Operating Manual available.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/TiEBMUx7_OY

Robust Construction and High Precision

The RTE 6_4 boasts a durable build with cast iron and steel components, ensuring longevity and resistance to wear. Its finely engineered mechanisms allow for minimum increments of 0.01 mm, enabling precise grinding tasks vital for various industrial applications. The machine's variable feed speeds and centralized lubrication further guarantee smooth, consistent operations over extended use.

Intuitive Controls for Versatile Operations

Designed for manual control with hydraulic table feeding capabilities, this surface grinder offers both reliability and flexibility. Operators benefit from straightforward, user-friendly controls suited for both routine and intricate grinding work. The inclusion of a sizable magnetic chuck and adaptable operation speeds makes the RTE 6_4 an asset for a range of applications in manufacturing and metalworking.

Complete Integrated Systems for Efficiency

Equipped with a powerful coolant system and easy-to-maintain centralized lubrication, the RTE 6_4 minimizes downtime and maximizes productivity. The combination of high grinding wheel speed and robust spindle performance supports rapid material removal while maintaining a low noise level, making it suitable for busy industrial settings.

FAQ's of Stefor Italy RTE 6_4 Surface Grinding Machine:

Q: How do I operate the table feeds on the Stefor RTE 6_4 surface grinding machine?

A: The table feed for longitudinal movement can be controlled manually or switched to hydraulic mode for smoother, hands-free operation. Transverse (cross) feed is handled manually. Adjustment of feed rates and direction is intuitive using the control levers, allowing for precise control during grinding.

Q: What materials can I grind with the RTE 6_4 and what is the maximum load?

A: This surface grinder is suitable for working with materials such as cast iron and steel, supporting workpieces up to 120 kg. Its construction and magnetic chuck are designed to handle various industrial jobs within the 600 x 400 mm working area.

Q: When should I use the coolant and lubrication systems?

A: The integrated coolant system should be used whenever you are conducting grinding operations to maintain low temperatures and prolong wheel life. The centralized lubrication system operates automatically but should be checked regularly to ensure all moving parts receive adequate lubrication for optimal performance.

Q: Where can I install the Stefor RTE 6_4 machine?

A: This machine is designed to be floor-mounted and requires a workspace of at least 1800 x 1300 mm. It is suitable for installation in industrial workshops, tool rooms, or factory floors with sufficient power supply (415 V) and ventilation.

Q: What is the process for changing the grinding wheel or adjusting the table feed?

A: To change the grinding wheel, first ensure the power is switched off and follow standard safety procedures. The wheel guard should be removed, the old wheel detached, and the new wheel securely fitted. For table feed adjustments, use the appropriate manual levers and, for hydraulic feed, ensure that the hydraulic system is engaged for longitudinal travel.

Q: How does the machine benefit industrial operations?

A: The RTE 6_4 provides high-precision grinding, easy manual control, and robust performance, making it ideal for industrial environments that demand accuracy and repeatability. Its durable build, large working area, and user-friendly systems enhance productivity while minimizing operational downtime.
