Send InquiryErnault Somua 220 mm x 650 mm Surface Grinder Machine
Price 100000 INR/ Piece
MOQ : 1 Piece
Ernault Somua 220 mm x 650 mm Surface Grinder Machine Specification
- Model
- Ernault Somua 220 x 650
- Rotation
- Grinding wheel
- Product Type
- Surface Grinder Machine
- General Use
- Precision surface grinding of metal components
- Material
- Cast iron, steel assemblies
- Type
- Manual Surface Grinder
- Capacity
- Medium duty (customizable)
- Weight (kg)
- 1850 kg
- Computerized
- No
- Automatic
- No, manual
- CNC Or Not
- Not CNC
- Control System
- Manual
- Table Size
- 220 mm x 650 mm
- Table Slide Way
- V & Flat guideways
- Magnetic Chuck Size
- 220 mm x 650 mm
- Grinding Wheel Size
- 350 mm x 40 mm x 127 mm
- Grinding Wheel Speed
- 1450 RPM
- Grinding Length
- 650 mm
- Floor Space
- 2100 mm x 1600 mm
- Fuel Tank Capacity
- 40 Liters (Hydraulic tank)
- Spindle Speed
- 1450 RPM
- Power
- 5 HP
- Voltage
- 415 V, 3 Phase
- Dimension (L*W*H)
- 2100 mm x 1600 mm x 1600 mm
- Feature
- High precision, heavy-duty construction, magnetic chuck included
- Color
- Grey & Blue
- Working Speed
- Up to 18 m/min
- Coolant System
- Inbuilt
- Surface Finish
- Ra 0.02 µm possible
- Hand Feed Graduation
- 0.002 mm
- Table Travel (Longitudinal)
- 700 mm
- Table Cross Feed (Max)
- 250 mm
- Max Distance Centre of Spindle to Table
- 400 mm
- Lubrication
- Centralized lubrication system
Ernault Somua 220 mm x 650 mm Surface Grinder Machine Trade Information
- Minimum Order Quantity
- 1 Piece
- Main Domestic Market
- All India
About Ernault Somua 220 mm x 650 mm Surface Grinder Machine
Make - H. Ernault Somua (France)
Model - MH 650
Magnet Size - 220 mm x 650 mm
Grinding Wheel Size - Diameter 225 mm x 32 mm Width
Max. Height between Magnet Top to Wheel Center - 300 mm
Least Count of the Machine - 2 Microns (0.002 mm)
Longitudinal Travel of the Table - 690 mm
Cross Travel of the Wheel-Head - 250 mm
- With Motorised Rapid Vertical Travels.
- Equipped with a Wheel Dresser.
- Complete with Coolant Tank and Pump.
- Operating Manual of the Machine is available.
- Machine is in excellent working condition.
Video of The Machine -
Precision Grinding for Demanding Applications
Engineered for high-precision surface finishing, the Ernault Somua 220 x 650 surface grinder delivers consistently accurate results for metal components. Its manual operation allows for detailed control, making it suitable for workshops requiring reliability and finesse in their grinding tasks. The inbuilt coolant system and centralized lubrication ensure smooth, efficient performance every session.
Robust Construction and Versatile Capacity
Constructed from high-quality cast iron and steel, this surface grinder offers remarkable durability for medium-duty operations. With a spacious table, longitudinal travel of 700 mm, and a magnetic chuck measuring 220 mm x 650 mm, users can accommodate a variety of workpieces. Flexible configuration options also allow for customized capacity based on specific manufacturing needs.
FAQ's of Ernault Somua 220 mm x 650 mm Surface Grinder Machine:
Q: How does the Ernault Somua 220 x 650 Surface Grinder achieve such high surface finish accuracy?
A: Thanks to its precision-engineered components, centralized lubrication, and stable V & flat guideways, this machine can achieve an impressive surface finish of Ra 0.02 m, ensuring even the most demanding applications yield superior results.Q: What types of materials can be processed with this surface grinder?
A: The Ernault Somua surface grinder is designed primarily for precision grinding of metal components, such as cast iron and steel assemblies, commonly found in machinery and industrial applications.Q: When should I use the inbuilt coolant system during grinding operations?
A: It is recommended to use the inbuilt coolant system for all grinding operations to reduce heat and friction, prolong the life of the grinding wheel, and maintain a consistently high-quality surface finish.Q: Where is the Ernault Somua 220 x 650 typically used?
A: This surface grinder is ideally used in industrial workshops, manufacturing plants, and tool rooms where medium-duty, high-precision metal grinding is required.Q: What is the process for adjusting the grinding operation speed?
A: The working speed of the table, up to 18 m/min, is manually controlled to match the material and finish requirements. Manual controls provide operators with the flexibility needed for different grinding applications.Q: How does manual control benefit this surface grinder compared to CNC models?
A: Manual control offers hands-on precision, making it easier to perform intricate adjustments on complex workpieces. This is especially advantageous for jobs requiring a skilled engineer's direct oversight.Q: What are the benefits of the included magnetic chuck?
A: The included 220 mm x 650 mm magnetic chuck securely holds workpieces in place during grinding, ensuring accurate results and reducing the risk of vibration or shifting during operation.
