GSP France 90 mm Radial Drilling Machine

Name: GSP France 90 mm Radial Drilling Machine
Brand: Liberty Metal & Machines Private Limited
Price: 75000 INR
Availability: InStock

Price 75000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

GSP France 90 mm Radial Drilling Machine Specification

Table Size
750 x 600 mm

Spindle Speed
21 1450 RPM

Cutting Area
Large

Diameter
Up to 90 mm

Dimension (L*W*H)
2600 x 1150 x 3200 mm

Noise Level
Low

Motor Power
7.5 HP

Features
Precision boring, tapping, reaming, easy operation, rigid construction

Condition
New

Frequency
50 Hz

Machine Type
90 mm Radial Drill

Product Type
Radial Drilling Machine

Material
Heavy Duty Cast Iron

Computerized
No

Automatic Grade
Semi-Automatic

CNC Or Not
No

Control System
Manual

Voltage
415 V

Power
7.5 HP

Power Source
Electric

Weight (kg)
3750 kg

Capacity
90 mm drilling diameter

Color
Grey/Blue

Usage & Applications
Heavy Duty Drilling for metal fabrication, manufacturing, workshops

Clamping
Hydraulic

Worktable Movement
360 Rotation

Max Drilling Depth
250 mm

Column Diameter
350 mm

Coolant System
Integrated

Max Distance Spindle to Base
1800 mm

Number of Spindle Speeds
12

Arm Length
2000 mm

Rotation of Arm
360

Standard Accessories
Drill Chuck, Keys, Tool Kit, Electricals, Instruction Manual

Table Adjustment
Motorized and Manual

Spindle Taper
Morse Taper No. 6

GSP France 90 mm Radial Drilling Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About GSP France 90 mm Radial Drilling Machine

Make - GSP (France)

Model - 46 Q 16

Drilling Capacity - 90 mm

Spindle Diameter - 110 mm

Arm Length - 1800 mm

Spindle Feed Travel - 415 mm

Spindle Taper - MT 5

Spindle Feed Rates - 0.05 mm/rev to 1.60 mm/rev

Vertical Travel of Arm - 825 mm

Table Size - 1000 mm x 805 mm

Clamping Type - Manual

- Equipped with Coolant Pump.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/_buzUZKnk5k

Advanced Engineering for Heavy-Duty Applications

This radial drilling machine is specially designed to handle rigorous tasks in metalworking, manufacturing, and professional workshops. Its sturdy construction, combined with precision controls and a range of spindle speeds, ensures accurate and efficient drilling, boring, tapping, and reaming operations across large workpieces.

User-Friendly Operation with Versatile Adjustments

Featuring a motorized and manual table adjustment, 360 worktable and arm rotation, and hydraulic clamping, the GSP France radial drill simplifies complex drilling setups. Operators can quickly adapt the machine to handle different materials and drilling requirements, improving productivity and reducing downtime.

Reliable Performance with Integrated Features

An integrated coolant system helps maintain optimal drilling conditions and protects both the tool and workpiece. The equipment is delivered with essential standard accessories, ensuring immediate installation and operation. Its electric-powered system operates at 415 V, making it suitable for industrial environments.

FAQs of GSP France 90 mm Radial Drilling Machine:

Q: How does the motorized and manual table adjustment work on the GSP France 90 mm Radial Drilling Machine?

A: The machine offers both motorized and manual options for table adjustment, allowing the operator to position the worktable precisely and easily depending on the size and type of workpiece being processed. This flexibility streamlines setup times and accommodates various drilling tasks.

Q: What are the benefits of the hydraulic clamping system?

A: Hydraulic clamping provides a secure hold on large or heavy workpieces, ensuring stability during drilling operations. This feature reduces the risk of movement, leading to greater accuracy, improved safety, and consistent drilling quality.

Q: When should I use the integrated coolant system?

A: The integrated coolant system should be used during extended drilling, tapping, or reaming operationsespecially on tough metals. It helps dissipate heat, reduces tool wear, extends machine life, and preserves workpiece integrity.

Q: Where is this machine most effectively utilized?

A: This radial drilling machine excels in metal fabrication shops, manufacturing facilities, and heavy industrial workshops requiring precise, high-capacity drilling and machining. Its size and capabilities make it ideal for both small and large production environments.

Q: How does the 360 rotation of the arm and worktable enhance usage?

A: The 360-degree rotation feature allows the drill arm and worktable to adjust easily for diverse drilling angles and positions, which is especially valuable when working with large or awkwardly shaped pieces. This improves flexibility, efficiency, and operator convenience.

Q: What is the process for adjusting spindle speeds on this machine?

A: The drill machine is equipped with 12 adjustable spindle speeds ranging from 21 to 1450 RPM. Speed adjustments are made manually through the control system, enabling optimal performance for different materials and hole sizes.
