Jones and  Shipman 1212E High Precision Cylindrical Grinder
Jones and  Shipman 1212E High Precision Cylindrical Grinder

Jones and Shipman 1212E High Precision Cylindrical Grinder

Price 100000 INR/ Piece

MOQ : 1 Piece

Jones and Shipman 1212E High Precision Cylindrical Grinder Specification

  • Product Type
  • Cylindrical Grinder
  • General Use
  • Precision Grinding of Cylindrical Parts
  • Material
  • Cast Iron, Steel Components
  • Type
  • High Precision
  • Capacity
  • 200 mm (Swing over table)
  • Weight (kg)
  • 1200 kg
  • Computerized
  • No
  • Automatic
  • Semi-Automatic
  • Control System
  • Manual/PLC Controlled
  • Drive Type
  • Electric
  • Grinding Diameter
  • 200 mm
  • Grinding Length
  • 300 mm
  • Spindle Speed
  • Up to 2400 RPM
  • Grinding Wheel Size
  • 350 mm x 38 mm x 127 mm
  • Voltage
  • 415V / 3 Phase
  • Dimension (L*W*H)
  • 1700 x 1200 x 1500 mm
  • Feature
  • High Accuracy, Sturdy Construction, Adjustable Settings
  • Color
  • Industrial Grey
  • Chuck Size
  • 150 mm
  • Noise Level
  • Below 75 dB
  • Grinding Accuracy
  • 0.0015 mm
  • Surface Finish
  • 0.20.3 m Ra
  • Table Traverse
  • 330 mm
  • Wheel Head Movement
  • 175 mm
  • Max Distance Between Centers
  • 300 mm
  • Max Load Between Centers
  • 50 kg
  • Coolant System
  • Integrated
  • Work Head Spindle Taper
  • MT3
  • Lubrication
  • Automatic Lubrication System
  • Power Consumption
  • 3.2 kW
  • Standard Accessories
  • Grinding Wheel, Wheel Flange, Diamond Dresser, Coolant Equipment


Jones and Shipman 1212E High Precision Cylindrical Grinder Trade Information

  • Minimum Order Quantity
  • 1 Piece
  • Main Domestic Market
  • All India


About Jones and Shipman 1212E High Precision Cylindrical Grinder

Make - Jones & Shipman (England)

Model - 1212E

Center Height - 78 mm

Max. Job Diameter - 150 mm

Max. Length of Job - 355 mm

Grinding Wheel Diameter - 305 mm

Grinding Wheel Width - 25 mm

Least Count of Machine - 1 Micron (0.001 mm)

Rotation of Table - +20 degree to -20 degree

Work-Head Speeds - 75 rpm to 750 rpm (Infinitely Variable)

Grinding Wheel Speeds - 1985 rpm / 2385 rpm

- Complete with Coolant Tank and Pump.

- Machine is in excellent working condition.


Video of the Machine-

https://youtu.be/wWUOZPsLbX8



Exceptional Precision and Build Quality

Designed for high precision work, the Jones & Shipman 1212E delivers outstanding accuracy and repeatable results. The rigid, industrial-grey construction ensures vibration damping, while adjustable settings allow for fine-tuned grinding operations. This machine supports both manual and PLC-controlled processes, catering to varying production requirements and operator preferences.


Advanced Features for Seamless Operation

Featuring a fully integrated coolant system and automatic lubrication, the 1212E sustains long-term performance and extends component life. Its comprehensive range of accessoriesincluding a grinding wheel, wheel flange, diamond dresser, and coolant equipmentstreamlines set-up and maximizes productivity. With a low noise level below 75 dB and efficient 3.2 kW power consumption, the 1212E offers a comfortable and energy-effective working environment.

FAQs of Jones and Shipman 1212E High Precision Cylindrical Grinder:


Q: How does the automatic lubrication system work on the Jones & Shipman 1212E Cylindrical Grinder?

A: The automatic lubrication system is designed to systematically deliver oil to all critical moving parts, reducing friction and wear. This helps maintain consistent machine performance, extends component lifespan, and minimizes manual maintenance for operators.

Q: What materials can be processed with the 1212E cylindrical grinder?

A: The machine is optimized for precision grinding of both cast iron and steel components. Its robust design allows it to handle these materials efficiently, achieving superior surface finishes and high dimensional accuracy required for precision-engineered parts.

Q: When should the grinders coolant system be used?

A: The integrated coolant system should be activated during all grinding operations, particularly when working with ferrous metals or performing prolonged grinding cycles. This helps dissipate heat, prevents thermal distortion, and promotes optimal surface finishes.

Q: Where is the Jones & Shipman 1212E typically utilized?

A: This precision cylindrical grinder is widely used in industries such as automotive, aerospace, toolmaking, and component manufacturing, where the highest levels of accuracy and surface finish are essential. Its compact dimensions and sturdy construction make it suitable for various production environments.

Q: What process is followed for setting up the 1212E for a new grinding job?

A: Setup involves mounting the workpiece between centers or on a chuck, selecting the appropriate grinding wheel, adjusting wheel head and work head positions, and calibrating speeds via manual or PLC controls. Safety checks and ensuring coolant flow are important steps before operation.

Q: How does the semi-automatic control system benefit users?

A: Semi-automatic and manual/PLC controls offer flexibility for both skilled operators and programmed processes. This allows easy adaptation for custom jobs, optimizes efficiency, and maintains consistent grinding results, even in small batch or variable production environments.

Q: What are the key advantages of using the Jones & Shipman 1212E High Precision Cylindrical Grinder?

A: The 1212E offers high grinding accuracy (0.0015 mm), exceptional surface finishing (0.20.3 m Ra), user-friendly operation, low noise levels, and robust build quality. These features result in superior part quality, increased productivity, and reliable, long-term performance.
