Jones Shipman 1302 Universal Cylindrical Grinder

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Jones Shipman 1302 Universal Cylindrical Grinder Specification

Product Type
Universal Cylindrical Grinder

General Use
Precision Grinding of Cylindrical Surfaces

Material
Cast Iron Body

Type
Manual

Capacity
External and Internal Grinding

Weight (kg)
Approx. 1600 kg

Computerized
No

Automatic
No

Control System
Manual Controls

Drive Type
Electric Motor

Grinding Diameter
300 mm

Grinding Length
1000 mm

Spindle Speed
Up to 2500 RPM

Grinding Wheel Size
355 mm x 50 mm x 127 mm

Voltage
415 V

Dimension (L*W*H)
2600 x 1600 x 1500 mm

Feature
Precision and robust construction

Color
Industrial Grey

Wheel Head Swivel Range
±30 Degrees

Centre Height
150 mm

Maximum Distance Between Centres
1000 mm

Surface Finish
Up to 0.2 micron

Table Traverse
1100 mm

Chuck Size
Standard 3-Jaw

Tailstock Quill Travel
55 mm

Internal Grinding Attachment
Optional

Electrical Connection
3 Phase

Coolant System
Integral

Lubrication System
Automatic

Jones Shipman 1302 Universal Cylindrical Grinder Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Jones Shipman 1302 Universal Cylindrical Grinder

Make - Jones & Shipman (England)

Model - 1302 EIT

Center Height - 178 mm

Max. Job Diameter - 355 mm

Max. Length of Job - 686 mm

Grinding Wheel Size - Diameter 305 mm x 31.75 mm Width

Work-Head Speeds - 25 rpm to 300 rpm

Table Rotation - 18 Degree to -16 Degree

- Equipped with Internal Grinding Attachment.

- Features like Auto-Cut and Plunge Grinding.

- Micro-Feed Adjustments on both Table & Wheel-Head Travel.

- Complete with Coolant Tank & Pump.

- Double Swivel type Wheel Head.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/PSN4md5Vy0k

Precision Engineering

The Jones Shipman 1302 excels in delivering outstanding surface finishes up to 0.2 microns, thanks to its rigid cast iron construction and advanced grinding capabilities. Its 30-degree wheel head swivel and robust manual controls enable precise adjustment for intricate grinding requirements.

Versatile Grinding Capacity

Capable of both external and internal grinding, this machine supports a grinding diameter up to 300 mm and a length of 1000 mm, accommodating varied workpieces with accuracy. The optional internal grinding attachment enhances flexibility for specialized tasks.

Operator-Friendly Features

Designed with a standard 3-jaw chuck, automatic lubrication, and an integral coolant system, the 1302 ensures ease of use and reduced maintenance. Its ergonomic manual controls make it accessible for operators of different skill levels.

FAQs of Jones Shipman 1302 Universal Cylindrical Grinder:

Q: How is the Jones Shipman 1302 Universal Cylindrical Grinder typically used?

A: This machine is primarily used for precision grinding of cylindrical surfaces, addressing both external and internal components. Its suitable for tool rooms, manufacturing units, and repair shops where fine tolerances and quality finishes are required.

Q: What are the main benefits of using this grinder for industrial applications?

A: The main benefits include exceptional surface finish (up to 0.2 micron), robust and durable cast iron construction, and versatility in grinding both internally and externally. Its integral coolant and automatic lubrication systems also enhance operational efficiency.

Q: When should I choose this model over a computerized or automated grinder?

A: Opt for the Jones Shipman 1302 when manual operation, hands-on control, and adaptability to a wide range of job types are crucial. Its ideal when flexibility, cost-effectiveness, and reliability in precision grinding matter more than automation.

Q: Where is this grinder most commonly installed and used?

A: It is commonly found in precision engineering workshops, manufacturing facilities, repair and maintenance shops, and educational institutions focusing on mechanical engineering and toolmaking.

Q: What is the process for internal grinding with this machine?

A: To perform internal grinding, you equip the grinder with its optional internal grinding attachment. This allows the machine to grind the bore of cylindrical components, enhancing its functionality and range of applications.

Q: How does the lubrication and coolant system improve machine performance?

A: The automatic lubrication system reduces wear and extends machine lifespan by ensuring all moving parts are properly oiled. The integral coolant system helps prevent overheating, maintaining workpiece integrity during prolonged grinding sessions.
