Kellenberger 600 RJ Universal Cylindrical Grinder

Name: Kellenberger 600 RJ Universal Cylindrical Grinder
Brand: Liberty Metal & Machines Private Limited
Price: 50000 INR
Availability: InStock

Price 50000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Kellenberger 600 RJ Universal Cylindrical Grinder Specification

Product Type
Universal Cylindrical Grinder

General Use
Precision external and internal cylindrical grinding

Material
Heavy-duty cast iron base and components

Type
Manual / Semi-automatic

Capacity
Between centers: 600 mm

Weight (kg)
Approx. 2000 kg

Computerized
No

Automatic
No

Control System
Manual, with electrical panel

Drive Type
Electric

Grinding Diameter
8 mm to 280 mm

Grinding Length
Up to 600 mm

Spindle Speed
Up to 1,660 rpm

Grinding Wheel Size
400 mm x 50 mm x 127 mm

Voltage
380V / 415V, 3 Phase

Dimension (L*W*H)
2600 mm x 1600 mm x 1500 mm

Feature
High accuracy, robust design, long service life

Color
Gray

Surface Finish Achievable
Ra 0.2 m

Internal Grinding Attachment
Available as option

Table Swivel
+/- 10

Wheelhead Motor Power
3.2 kW

Tailstock
Quill diameter 60 mm, with fine adjustment

Workhead Swivel
+/- 90

Coolant System
Integrated

Max Workpiece Weight Between Centers
150 kg

Lubrication
Centralized lubrication system

Chuck Size
Up to 200 mm

Kellenberger 600 RJ Universal Cylindrical Grinder Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Kellenberger 600 RJ Universal Cylindrical Grinder

Make - Kellenberger (Switzerland)

Model - 600 RJ

Center Height - 175 mm

Max. Length of Job - 600 mm

Max. Diameter of Job - 350 mm

Grinding Wheel Size - Diameter 400 mm x 50 mm Width

Table Swivel - +10 degree to -10 degree

- Equipped with Internal Grinding Attachment.

- Equipped with 2-Axis Heidenhain DRO (resolution of 1 Micron).

- Features like Auto-Cut, Delay, Plunge, & Auto-Compensation.

- With Accessories like spare wheels, internal grinding spindles, job steady etc.

- With Accessories like many chucks, Centers, Coolant Filtration Unit etc.

- Operating Manual of the machine is available.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/ij4WGetSz68

Versatile Grinding Performance

With a table swivel range of 10 and workhead swivel of 90, the Kellenberger 600 RJ supports versatile external and internal cylindrical grinding operations. Its adaptable design accommodates a variety of workpieces, making it a suitable choice for both precision batch production and specialized component manufacturing.

Engineered for Precision and Durability

Built on a heavy-duty cast iron base, this cylindrical grinder guarantees stability and vibration damping during operation. Centralized lubrication and fine-adjustment tailstock maintain consistent accuracy, while robust construction extends the machines service life delivering reliable results for demanding industrial environments.

FAQs of Kellenberger 600 RJ Universal Cylindrical Grinder:

Q: How does the Kellenberger 600 RJ achieve high-precision grinding results?

A: The grinder combines a heavy-duty cast iron base for superior rigidity with fine adjustment tailstock and high-quality bearings. Together with the centralized lubrication and an integrated coolant system, these ensure minimal thermal distortion and stable machining, achieving surface finishes up to Ra 0.2 m.

Q: What is the process for grinding internal surfaces on this machine?

A: To perform internal grinding, the optional internal grinding attachment must be installed. Operators then set up the attachment, adjust parameters according to the workpiece dimensions, and use the machines manual or semi-automatic controls to complete precise internal grinding cycles.

Q: When should you choose the semi-automatic function over manual operation?

A: The semi-automatic function is preferred for repetitive tasks or production runs, as it reduces manual interventions and increases consistency. Manual operation is ideal when machining unique, prototypical, or highly specialized components requiring close operator supervision.

Q: Where can the Kellenberger 600 RJ be utilized most effectively?

A: This cylindrical grinder excels in toolrooms, maintenance workshops, high-precision manufacturing lines, and production centers requiring intricate grinding tasks. Its reliability and precision are especially valued in sectors like aerospace, automotive, and precision engineering.

Q: What are the benefits of the machines robust cast iron construction?

A: The heavy-duty cast iron base and structural components significantly reduce vibration, improve dimensional accuracy, and enhance overall durability of the machine, ensuring precise grinding and long-term performance in demanding industrial settings.

Q: How do you maintain the performance and accuracy of the Kellenberger 600 RJ?

A: Regular maintenance involves routine checks of the centralized lubrication system, cleaning the integrated coolant system, inspecting the grinding wheel for wear, and verifying tailstock and headstock alignments. Following these steps ensures optimal performance and longevity.
