Landis Type-C 1850 mm Length Cylindrical Grinder Machine

Name: Landis Type-C 1850 mm Length Cylindrical Grinder Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Landis Type-C 1850 mm Length Cylindrical Grinder Machine Specification

Product Type
Cylindrical Grinder Machine

General Use
Precision external and internal cylindrical grinding

Material
Cast Iron, Mild Steel

Type
Universal

Capacity
Heavy-duty; up to 1850 mm job length

Weight (kg)
Approx. 5000 kg

Computerized
No

Automatic
Semi-Automatic

Control System
Manual/Electromechanical

Drive Type
Belt Drive

Grinding Diameter
10 mm to 350 mm

Grinding Length
1850 mm

Spindle Speed
Variable, up to 1200 RPM

Grinding Wheel Size
500 mm (Diameter) x 75 mm (Width)

Voltage
415 V

Dimension (L*W*H)
4200 mm x 1700 mm x 1600 mm

Feature
High rigidity, precise slideways, coolant system, adjustable tailstock

Color
Industrial Green

Wheel Balancing Equipment
Included

Table Traverse
2000 mm

Type of Chuck
3-Jaw or Centers

Distance Between Centres
1850 mm

Swing Over Table
350 mm

Lubrication
Centralized automatic

Floor Space Requirement
Approx. 7.5 sq. m

Ideal For
Tool rooms, production lines, engineering workshops

Wheel Head Motor Power
7.5 HP

Surface Finish Quality
Superior finish suitable for precision components

Max Centre Height
175 mm

Machine Accuracy
Up to 0.002 mm

Made In
India

Tailstock Quill Travel
50 mm

Coolant System
Fitted

Landis Type-C 1850 mm Length Cylindrical Grinder Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

Landis Type-C 1850 mm Length Cylindrical Grinder Machine About

Make - Landis (USA)

Model - Type C

Center Height - 140 mm

Max. Length of Job - 1850 mm

Max. Job Diameter - 270 mm

Max. Grinding Wheel Diameter - 750 mm

Max. Grinding Wheel Width - 100 mm

Table Rotation - +8 degree to -4 degree

- Equipped with DRO on the Wheel-Head Travels.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/ye4Ts5apWYw

High-Precision Grinding Technology

Landis Type-C Grinder utilizes precise slideways and superior component alignment, ensuring highly accurate grinding results. Its advanced wheel balancing equipment and variable spindle speed deliver efficiency and customizable surface finishes, perfectly suited for precision jobs and repeatable production processes.

Flexible and Robust Build

Crafted with industrial-grade cast iron and mild steel, this heavy-duty machine offers a grinding length up to 1850 mm and supports weights up to 5000 kg. The semi-automatic, belt-driven mechanism guarantees stability and versatility for various job sizes, making it suitable for both large-scale manufacturing and specialized workshops.

Operator-Friendly Features

The machine is equipped with user-centric elements such as the adjustable tailstock, 3-jaw or center chuck options, and a centralized automatic lubrication system. Its manual and electromechanical controls, combined with an integrated coolant system, make operation straightforward while extending component lifespan and reducing maintenance requirements.

FAQ's of Landis Type-C 1850 mm Length Cylindrical Grinder Machine:

Q: How does the Landis Type-C 1850 mm Cylindrical Grinder achieve such high accuracy?

A: The grinder features precision slideways, robust construction, and high-rigidity components. Its wheel balancing equipment and variable spindle speed support accuracy up to 0.002 mm, providing consistent results and superior surface finish, ideal for precision engineering applications.

Q: What types of materials and components can be machined using this cylindrical grinder?

A: The Landis Type-C is suitable for grinding a variety of materials, including cast iron and mild steel. It can process job lengths up to 1850 mm and diameters from 10 mm to 350 mm, making it versatile for tool rooms, engineering workshops, and production lines requiring precision cylindrical components.

Q: When is the optimal time to use the coolant system during grinding operations?

A: The fitted coolant system should be activated during all grinding operations. It helps control the heat produced by friction, maintains surface finish quality, and prolongs both wheel and workpiece life, ensuring consistent accuracy throughout the process.

Q: Where is this machine typically installed and what are its space requirements?

A: It is ideally installed in tool rooms, production workshops, and engineering facilities. The machine requires a floor space of approximately 7.5 square meters, with overall dimensions of 4200 mm x 1700 mm x 1600 mm, making it suitable for medium to large industrial settings.

Q: What is the process for adjusting the grinding wheel speed and size?

A: The spindle speed is variable and can be adjusted up to 1200 RPM, depending on material and job specifications. The grinding wheel size supported is 500 mm in diameter and 75 mm in width, allowing customization for different machining tasks and achieving desired finishes.

Q: How does the centralized automatic lubrication system benefit users?

A: Centralized automatic lubrication reduces manual intervention and maintenance delays. It ensures consistent and optimal lubrication across moving parts, minimizing wear, extending machine life, and supporting sustained accuracy during intensive use.
