Kia 500 x 500 Horizontal Machining Center

Send Inquiry

Request To Call Back

Kia 500 x 500 Horizontal Machining Center

Price 50000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Kia 500 x 500 Horizontal Machining Center Specification

Product Type
Horizontal Machining Center

General Use
Industrial / Metalworking

Material
Cast Iron Body, Hardened Steel Components

Type
CNC Machining Center

Capacity
Up to 800 kg Table Load

Weight (kg)
9000 kg

Computerized
Yes

Automatic
Fully Automatic

PLC Control
Available

Bar Feeder
No

Power Source
Electric

Power Consumption
20 kVA

Rigidity
High Structural Rigidity

Voltage
415 V

Motor
AC Servo and Spindle Motor

Table Size
500 mm x 500 mm

Spindle Speed
Up to 6000 rpm

Axial Choice
X, Y, Z Axis

Dimension (L*W*H)
3500 mm x 3000 mm x 2500 mm

Feature
High Productivity, Precision Machining

Color
White & Blue

About Kia 500 x 500 Horizontal Machining Center

Make - Kia (South Korea)

Model - H50

Pallet Size - 500 mm x 500 mm

Longitudinal Travel - 760 mm

Vertical Travel - 705 mm

Transversal Travel - 650 mm

Spindle Taper - BT 50

CNC Control - Fanuc 18-M

Spindle Speeds - 20 rpm to 4,500 rpm

Bi-Directional Automatic Tool Changer - 60 Positions

Rapid Travel of Axis - 20,000 mm/min

Year of Make - December 2000

- Coolant through Spindle.

- 2 Pallet Automatic Changer System.

- Electrical Drawings, Operating Manuals, etc. are available.

- Equipped with a probe to measure the tool length.

- With Step-Down Transformer & High-Pressure Coolant System.

- With Chip Conveyor, Coolant Tank, all covers etc.

- Machine is in excellent working condition.

Video link - https://youtu.be/eT-y6PuBzDo

High Precision and Productivity

Achieve superior accuracy with a positioning precision of 0.005 mm and repeatability of 0.003 mm. Designed for smooth and rapid production, the machines up to 6000 rpm spindle speed and efficient automatic chip removal contribute to high productivity, making it ideal for continuous industrial operations and reducing downtime during manufacturing.

Robust Construction and Advanced Features

Built with a heavy-duty cast iron body and hardened steel components, this horizontal machining center ensures durability and structural rigidity. Features like the full splash guard enclosure, high-pressure coolant system, and integrated automatic pallet changer promote safe usage and efficient workflow, supporting intensive metalworking processes.

Flexible Control and Operation

Equipped with reliable CNC controllers from Fanuc, Siemens, or Mitsubishi, the Kia 500 x 500 can be tailored to specific application needs. The integrated hydraulic system manages quick tool and pallet changes, while the computerized PLC controls facilitate automation, enabling fully automatic operation for consistent, high-quality machining results.

FAQs of Kia 500 x 500 Horizontal Machining Center:

Q: How does the Kia 500 x 500 Horizontal Machining Center enhance manufacturing precision?

A: The Kia 500 x 500 achieves high manufacturing precision with positioning accuracy of 0.005 mm and repeatability of 0.003 mm, enabled by its robust cast iron body, advanced servo motors, and computerized control systems. This ensures consistent, accurate machining for complex industrial components.

Q: What types of controllers can be used with this machining center?

A: Operators can choose between Fanuc, Siemens, or Mitsubishi controllers based on their production requirements. These CNC controllers provide reliable and customizable operation, supporting integration with a wide range of industrial automation systems.

Q: When should the integrated high-pressure coolant system be utilized?

A: The high-pressure coolant system should be used during machining of materials that generate significant heat or require superior chip evacuation, such as metals. It ensures tool longevity, maintains machining accuracy, and supports continuous high-speed operations.

Q: Where can the Kia 500 x 500 be installed for optimal performance?

A: It is best installed in industrial environments like manufacturing plants or metalworking workshops with suitable electrical power (415 V, 20 kVA) and ample space for its dimensions (3500 x 3000 x 2500 mm). This ensures smooth operation and accessibility for maintenance.

Q: What benefits does the automatic twin pallet system provide?

A: The twin pallet system allows the operator to load and unload workpieces while machining is in progress, minimizing downtime between tasks. This automated feature improves workflow efficiency and boosts overall productivity, especially in batch production scenarios.

Q: How can operators use the tool magazine and automatic tool changer?

A: Operators can program the CNC system to select from up to 40 tools stored in the magazine. The automatic tool changer completes tool swaps in just 3 seconds, enabling seamless transitions between operations and supporting complex multi-tool machining routines.

Q: What processes is this machining center suitable for?

A: The Kia 500 x 500 is ideal for precision machining, high-volume part production, and heavy-duty metalworking processes. Its featuressuch as high speed, rigidity, and automated systemsmake it effective for mass manufacturing, component fabrication, and other industrial applications.
