Klingelnberg AGW 231 Hob Sharpening Machine

Get a Price/Quote

MOQ : 1 Piece

Klingelnberg AGW 231 Hob Sharpening Machine Specification

Gear Type
N/A (Sharpening Machine)

Material
High-grade Cast Iron and Alloy Steel

Processing Type
Gear Hob Sharpening

Gear Tooth Profile
Straight & Helical

Gearing Arrangement
N/A (Sharpening Machine)

Direction
Universal

Rated Power
3 kW

Input Speed
1450 rpm

Output Speed
Variable, up to 80 rpm

Voltage
400 V, 3 Phase

Efficiency
High, up to 90%

Coolant System
Integrated

Max Workpiece Diameter
250 mm

Centre Height
125 mm

Max Grinding Wheel Diameter
250 mm

Max Workpiece Length
350 mm

Swivelling Range of Table
+90 / -90

Application
Sharpening of Gear Hobs, Worm Cutters, and Similar Tools

Machine Weight
Approx. 3500 kg

Control System
Manual / Semi-Automatic

Model
AGW 231

Klingelnberg AGW 231 Hob Sharpening Machine Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cheque

Supply Ability
100 Pieces piece Per Month

Delivery Time
1 Days

Packaging Details
Standard

Main Export Market(s)
Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa, Asia

Main Domestic Market
All India

About Klingelnberg AGW 231 Hob Sharpening Machine

By utilizing sophisticated production methods, we are providing the finest quality Hob Sharpening Machine. It is an affordable solution for hob sharpening and in-house tool maintenance. Equipped with a HSK spindle, this is ideal for repetitive jobs without changes in setup, particularly during the manufacturing and re-sharpening of straight and spiral gash hobs, dish, shank and helical gear shaper cutters as well as a wide range of round tools. This machine is manufactured in tune with set industry standards by utilizing the finest grade materials under the observation of our team. Additionally, our quality inspectors examine this Hob Sharpening Machine on well-defined parameters to dispatch a quality assured range at user end.

Features:

Long service life
Automatic in functionality
High in efficiency
Make - Klingelnberg (Germany)
Model - AGW 231
Max. Diameter of Hob (Helical flutes) - 230 mm
Max. Diameter of Hob (Straight flutes) - 250 mm
Max. Grinding Slide Stroke - 475 mm
Max. Depth of flute - 50 mm
Max. Lead Angle - 45 degree
Max. / Min. Grinding Wheel Diameter - 250 mm / 150 mm
Wheel Speed - 1500 - 2700 rpm
- Electrical drawings, manuals etc. available with the machine.

Superior Performance and Versatility

Designed for universal application, the AGW 231 excels at sharpening gear hobs, worm cutters, and similar tools, thanks to its robust construction and advanced features. The machine accommodates varied workpieces and offers a comprehensive swiveling range, ensuring adaptability to complex sharpening tasks in industrial settings.

Integrated Coolant System for Efficient Operation

Equipped with an internal coolant system, the AGW 231 maintains optimal temperatures during grinding, enhancing tool life and precision. This reduces downtime from overheating and allows for continuous operation, supporting high productivity and quality results.

Precision Engineering with Manual or Semi-Automatic Control

The AGW 231 is equipped with manual and semi-automatic controls, providing operators with flexibility for intricate sharpening requirements. The variable output speed and ergonomic design contribute to effortless handling and precise tool reconditioning.

FAQs of Klingelnberg AGW 231 Hob Sharpening Machine:

Q: How does the Klingelnberg AGW 231 sharpen gear hobs and similar tools?

A: The AGW 231 uses a 250 mm grinding wheel, controlled manually or semi-automatically, to restore sharp cutting edges on gear hobs, worm cutters, and similar tools. The integrated coolant system prevents overheating, maintaining precision and enhancing tool longevity.

Q: What types of gear tooth profiles can be sharpened with this machine?

A: The AGW 231 is designed to efficiently sharpen both straight and helical gear tooth profiles, ensuring compatibility with a diverse range of industrial cutting tools.

Q: When should gear hobs be sharpened?

A: Gear hobs should be sharpened when there is noticeable wear or a decline in cutting accuracy. Regular reconditioning with the AGW 231 ensures extended tool life and consistent, high-quality gear production.

Q: Where is the Klingelnberg AGW 231 most commonly used?

A: This sharpening machine is widely utilized in gear manufacturing facilities, maintenance workshops, and tool reconditioning centers, especially by exporters, importers, manufacturers, suppliers, and traders in India.

Q: What is the process of sharpening on the AGW 231?

A: The operator secures the tool in place, sets the desired table angle, selects manual or semi-automatic mode, and allows the grinding wheel to restore the cutting edge while the integrated coolant system maintains ideal operational temperatures.

Q: What are the main benefits of using the AGW 231 Hob Sharpening Machine?

A: The AGW 231 offers high sharpening efficiency, universal adaptability, robust engineering, and precision control. It extends the service life of cutting tools while ensuring consistent and accurate sharpening results, leading to lower tooling costs and improved manufacturing output.
