Kondia Spain Vertical Turret Milling Machine
Kondia Spain Vertical Turret Milling Machine

Kondia Spain Vertical Turret Milling Machine

Price 100000 INR/ Piece

MOQ : 1 Piece

Kondia Spain Vertical Turret Milling Machine Specification

  • Model
  • Kondia FV-1
  • Rotation
  • 360 Degree Swivel Head
  • Product Type
  • Vertical Turret Milling Machine
  • General Use
  • Industrial Milling Operations
  • Material
  • Cast Iron
  • Type
  • Milling Machine
  • Capacity
  • Large
  • Weight (kg)
  • 1300 kg
  • Computerized
  • No
  • Automatic
  • No
  • CNC Or Not
  • Not CNC
  • Control System
  • Manual
  • Table Size
  • 1210 mm x 230 mm
  • Table Slide Way
  • Box Type
  • Floor Space
  • 1700 mm x 1500 mm
  • Spindle Speed
  • 60-4300 rpm
  • Power
  • 2 HP
  • Voltage
  • 415 V
  • Dimension (L*W*H)
  • 1700 mm x 1500 mm x 2100 mm
  • Feature
  • High Precision, Rigid Structure
  • Color
  • Standard Industrial
  • Number of T-Slots
  • 3
  • Longitudinal Travel (X)
  • 860 mm
  • Travel (X/Y/Z)
  • 860 mm x 370 mm x 406 mm
  • Ram Travel
  • 540 mm
  • T-Slot (Width x Distance)
  • 16 mm x 65 mm
  • Coolant Pump
  • Provided
  • Quill Travel
  • 127 mm
  • Spindle Taper
  • ISO 40
  • Main Motor Type
  • 3 Phase
  • Feed Motor
  • 0.5 HP
  • Max. Distance from Spindle Nose to Table
  • 406 mm
  • Vertical Travel (Z)
  • 406 mm
  • Cross Travel (Y)
  • 370 mm
  • Lubrication Type
  • Centralized Lubrication


Kondia Spain Vertical Turret Milling Machine Trade Information

  • Minimum Order Quantity
  • 1 Piece
  • Main Domestic Market
  • All India


About Kondia Spain Vertical Turret Milling Machine

Make - Kondia (Spain)

Model - Powermill FV-1

Table Size - 1070 mm x 230 mm

Longitudinal Travel - 650 mm

Cross Travel - 350 mm

Spindle Speeds (Infinitely Variable) - 60 rpm to 4250 rpm

Spindle Taper - ISO 40

Spindle Travel - 125 mm

Spindle Diameter - 86 mm

- Equipped with a 2-Axis DRO.

- Motorised Rapid Vertical Travels of the Table.

- Machine is in excellent working condition.


Video of The Machine -

https://youtu.be/iP1MmVrRQLE



Exceptional Travel and Capacity for Optimal Milling

The Kondia FV-1 offers extensive travel on all axes (X: 860 mm, Y: 370 mm, Z: 406 mm), accommodating large and complex workpieces. Its rigid structure and precise table slide ways ensure stability and accuracy even during demanding milling tasks. Designed for heavy-duty industrial use, the machine delivers consistent results in various manufacturing scenarios.


Versatile Operation and Convenient Features

Equipped with features like a 360-degree swivel head, ISO 40 spindle taper, centralized lubrication, and coolant pump, this milling machine facilitates diverse machining processes. Manual control provides flexibility for skilled operators, and the standardized 3-phase motor ensures reliable power delivery for consistent operation.


Precision Engineering Meets Robust Construction

Constructed from durable cast iron and designed for high precision, the Kondia FV-1 resists vibration and deformation. The box type table slide ways and generous table size allow for stable clamping and handling of large components, increasing machining quality and operator confidence in every task.

FAQ's of Kondia Spain Vertical Turret Milling Machine:


Q: How does the Kondia FV-1 ensure high precision during milling operations?

A: The Kondia FV-1 features a rigid cast iron construction, box type table slide ways, and a high-precision spindle taper (ISO 40), all of which contribute to accurate and stable milling. Centralized lubrication further ensures smooth movement and minimal wear, maintaining consistent results over time.

Q: What types of materials can be processed with this vertical turret milling machine?

A: This machine is designed primarily for industrial applications, and its robust build allows it to process a wide range of materials including steel, aluminum, cast iron, and non-ferrous metals. Its large table and stable platform make it suitable for both roughing and finishing operations.

Q: When should manual control be preferred over CNC in milling operations?

A: Manual control suits situations where intricate, custom, or low-volume jobs are required, or where experienced operators can leverage the flexibility of direct adjustment. The Kondia FV-1, being non-CNC, offers straightforward control, ideal for prototyping, repair work, and unique part fabrication.

Q: Where is the Kondia FV-1 commonly utilized?

A: This vertical turret milling machine is widely used in manufacturing plants, metalworking shops, and industrial facilities. It's a favorite among exporters, importers, manufacturers, and suppliers for its reliability, capacity, and adaptability across varied production requirements.

Q: What is the process for maintaining the Kondia FV-1?

A: Routine maintenance involves cleaning chips and debris, regularly checking and refilling the centralized lubrication system, inspecting T-slots for wear, and monitoring spindle performance. Scheduled servicing of the electrical and mechanical components helps ensure longevity and optimum performance.

Q: How does the machine's 360-degree swivel head benefit industrial users?

A: The 360-degree swivel head offers versatile positioning for the spindle, allowing users to perform complex angular milling, drilling, and boring operations. This flexibility increases the range of machinable features and simplifies setups for multiple operations on a single workpiece.

Q: What advantages does the large table size provide during milling?

A: The 1210 mm x 230 mm table enables users to mount large or multiple workpieces securely, enhancing productivity and enabling the machining of bigger components. The ample T-slot arrangement supports robust clamping, which improves precision and safety during demanding milling tasks.
