Saimp Italy Vertical Turret Milling Machine

Name: Saimp Italy Vertical Turret Milling Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Saimp Italy Vertical Turret Milling Machine Specification

Model
Saimp (Italy) Standard Turret Model

Rotation
360 (Vertical/Horizontal Head Swivel)

Product Type
Vertical Turret Milling Machine

General Use
Industrial Milling Operations

Material
Cast Iron & Steel

Type
Turret Milling

Capacity
Heavy Duty/Medium-Large Batch

Weight (kg)
Approx. 2000 kg

Computerized
No

Automatic
No (Manual Feed)

CNC Or Not
Not CNC (Conventional Machine)

Control System
Manual

Table Size
1270 x 254 mm

Table Slide Way
Dovetail

Floor Space
1700 x 1500 mm

Spindle Speed
70 4200 RPM (Variable)

Power
3 HP (approx.)

Voltage
415V / 3 Phase

Dimension (L*W*H)
1700 x 1500 x 2100 mm (approx.)

Feature
Vertical head swivels left and right, accurate feed, easy operation, intensive-duty

Color
Standard Machine Grey with Blue accents

Coolant System
Integrated

Cross Table Travel
350 mm

Max Distance from Spindle Nose to Table
450 mm

Number of T-Slots
3

Spindle Taper
ISO 40

Min Distance from Spindle Nose to Table
40 mm

Ram Travel
400 mm

Lighting
Fitted Work Lamp

Lubrication
Centralized/Lubrication Pump

Feed
Manual & Power (X/Y Axis)

Quill Travel
120 mm

T-Slot Size
16 mm

Application
Precision Milling, Slotting, Drilling and Boring Operations

Longitudinal Table Travel
900 mm

Vertical Knee Travel
400 mm

Saimp Italy Vertical Turret Milling Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

Saimp Italy Vertical Turret Milling Machine About

Make - Saimp (Italy)

Table Size - 1020 mm x 255 mm

Longitudinal Travel - 700 mm

Cross Travel - 250 mm

Spindle Speeds - 135 rpm to 2720 rpm

Spindle Travel - 140 mm

Spindle Taper - ISO 30

Spindle Diameter - 89 mm

- Many accessories including Boring Head, Tool Holder, Collets etc.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/kPJf6ks-2PM

Robust Design and Performance

Engineered with cast iron and steel for superior durability, the Saimp Italy Vertical Turret Milling Machine is built to deliver precise results even under intensive workloads. Its heavy-duty construction stabilizes the machine during operation, ensuring accuracy for industrial milling, drilling, slotting, and boring jobs. The dovetail slideways provide reliable table movement, and the centralized lubrication pump protects vital components against wear.

Versatile Machining Capabilities

With a 900 mm longitudinal and 350 mm cross table travel, and 400 mm vertical knee movement, this machine accommodates a wide range of workpieces. The ISO 40 spindle taper and variable spindle speed (70-4200 RPM) support diverse tooling and material requirements, while the 360 swiveling head enhances operational flexibility. Whether for precision component production or complex slotting, the Saimp turret milling machine is a versatile tool for any workshop.

User-Friendly Features for Efficiency

The integrated coolant system, centralized lubrication, fitted work lamp, and manual/power feed options for X and Y axes make operation both convenient and efficient. The spacious table, clear controls, and quick set-up enable operators to handle medium to large batches with ease. Designed for manual operation, this machine is ideal for users seeking reliable, hands-on control and straightforward maintenance.

FAQ's of Saimp Italy Vertical Turret Milling Machine:

Q: How does the Saimp Italy Vertical Turret Milling Machine improve milling accuracy?

A: The machine's robust cast iron and steel construction minimizes vibration, while dovetail slideways and a precise feed system ensure stable and accurate table movement. The centralized lubrication system maintains smooth operation, supporting tight tolerances required in milling, drilling, and boring tasks.

Q: What types of machining operations can this turret mill perform?

A: This machine is suitable for precision milling, slotting, drilling, and boring. Its vertical head can swivel 360, enabling complex cutting angles and versatile application for medium to large batch production in industrial settings.

Q: When should I choose this conventional turret milling machine over a CNC model?

A: Select this non-CNC machine when your operations require manual control, flexibility in small to medium batch sizes, or when operator expertise allows for efficient handling without advanced programming. It's ideal for custom jobs, repair work, and workshops valuing hands-on milling precision.

Q: Where is the Saimp Italy turret milling machine typically installed?

A: This machine is commonly installed in industrial workshops, tool rooms, maintenance departments, and manufacturing plants where operational space measures approximately 1700 x 1500 mm. Its heavy-duty build makes it well-suited to environments requiring reliable, high-accuracy milling capabilities.

Q: What is the process for changing tools and adjusting speed on this machine?

A: Tool changes are performed manually using the ISO 40 spindle taper, ensuring compatibility with a wide range of tools. Spindle speed adjustment is variable and can be easily set via the control panel, allowing adaptation to different materials and machining requirements.

Q: How does the integrated coolant and lubrication system benefit machine operation?

A: The integrated coolant system keeps workpieces and tools at optimal temperatures, reducing wear and thermal distortion. The centralized lubrication pump automatically delivers oil to vital components, extending machine life and reducing maintenance frequency.

Q: What unique features make the Saimp turret milling machine user-friendly?

A: This machine offers a fitted work lamp for enhanced visibility, fitted controls for easy adjustments, manual and power-assisted feed for convenience, and a swiveling vertical head, allowing operators to efficiently perform complex operations with minimal set-up time.
