Lizzini 600 mm Cylindrical Grinding Machine

Name: Lizzini 600 mm Cylindrical Grinding Machine
Brand: Liberty Metal & Machines Private Limited
Price: 35000 INR
Availability: InStock

Price 35000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Lizzini 600 mm Cylindrical Grinding Machine Specification

Product Type
Cylindrical Grinding Machine

General Use
Industrial, Precision Grinding

Material
Cast Iron, Steel Components

Type
Universal

Capacity
600 mm (Grinding Length)

Weight (kg)
Approx. 2500 kg

Computerized
No

Automatic
Semi-Automatic

Control System
Electric Panel / Manual

Drive Type
Belt Driven

Grinding Diameter
8 mm to 200 mm

Grinding Length
600 mm

Spindle Speed
Up to 1450 RPM

Grinding Wheel Size
Ø 350 x 127 x 32 mm

Voltage
415 V, 3 Phase, 50 Hz

Dimension (L*W*H)
2100 x 1350 x 1600 mm

Feature
High Precision, Robust Construction, Low Vibration

Color
Green / White

Work Headstock
Fixed and Rotating (with Chuck/Face Plate)

Bed Material
High Grade Cast Iron, Hardened & Ground

Headstock Speed Range
20 - 150 RPM variable

Max Swing Over Bed
230 mm

Traverse Speed
0.1 - 6 m/min

Manual/Automatic Feed
Both Available

Available Accessories
Internal Grinding Attachment, Wheel Balancing Stand, Diamond Dresser

Wheel Head Power
3 HP

Min-Max Center Height
130 mm

Tailstock
Yes, with Micro Adjustment

Chuck Size
160 mm

Grinding Accuracy
Within 0.002 mm

Coolant System
Provided

Lubrication System
Centralized Automatic Lubrication

Application
External & Internal Cylindrical Grinding

About Lizzini 600 mm Cylindrical Grinding Machine

Make - Lizzini (Italy)

Model - RUL 60-M2

Center Height - 150 mm

Max. Length of Job - 600 mm

Grinding Wheel Size - Diameter 400 mm x 50 mm Width

Work-Head Speeds - 60 rpm to 650 rpm

Least Count - 2.5 microns

Table Rotation - -9 Degree to +9 Degree

- Equipped with Internal Grinding Attachment.

- Features like Auto-Cut, Auto-Compensation, & Plunge Grinding.

- With Wheel Dresser, Coolant Tank, Pump & spare wheels.

- Machine is in excellent working condition

Video link - https://youtu.be/nTemYozPlfo

Precision and Robust Design

Built with a high-grade, hardened and ground cast iron bed, the Lizzini cylindrical grinding machine offers outstanding stability and low vibration, which are critical for achieving high-precision grinding. The robust construction ensures a long service life, maintaining performance standards in demanding industrial environments. The machines capability to deliver results within 0.002 mm accuracy makes it ideal for applications that depend on fine tolerances.

Versatile Grinding Applications

The machine supports both external and internal cylindrical grinding, handling components from 8 mm up to 200 mm in diameter and lengths up to 600 mm. Provided accessories, such as the internal grinding attachment, wheel balancing stand, and diamond dresser, expand the machines application scope. With both manual and automatic feed options, users can tailor operations for unique production needs, ensuring adaptability across industries.

User-Friendly Operation and Maintenance

Featuring a semi-automatic control system via electric panel or manual operation, this machine is designed for intuitive use. The fixed and rotating work headstock, variable traverse and headstock speeds, and centralized automatic lubrication facilitate smooth execution and reduced downtime. Additionally, the integrated coolant system helps maintain grinding performance, protecting the workpiece and extending tool life.

FAQs of Lizzini 600 mm Cylindrical Grinding Machine:

Q: How does the Lizzini 600 mm Cylindrical Grinding Machine ensure high precision in grinding applications?

A: The machines bed, crafted from specially hardened and ground cast iron, dampens vibration and provides structural rigidity, assisting in delivering grinding accuracies within 0.002 mm. Variable spindle and traverse speeds, a robust 3 HP wheel head, and both manual and automatic feeds allow precise control over the grinding process.

Q: What materials and part sizes can be processed with this cylindrical grinding machine?

A: It is engineered to grind cast iron and steel components, suitable for part diameters ranging from 8 mm up to 200 mm and lengths up to 600 mm. Its universal design supports both external and internal cylindrical grinding applications.

Q: When is it optimal to use the manual versus automatic feed modes?

A: Manual feed is best suited for fine-tuning or one-off grinding tasks where precise operator control is preferred. Automatic feed is optimal for repetitive or batch production, delivering consistent results and increasing efficiency.

Q: Where is this machine most commonly used within the industry?

A: This grinding machine is ideal for factories and workshops focusing on industrial, precision, and general-purpose cylindrical grinding. It is especially valuable for manufacturers, exporters, importers, and suppliers requiring flexibility in operations and high accuracy.

Q: What is the recommended process for maintaining the machines performance and longevity?

A: Regularly check the centralized automatic lubrication system to ensure proper function, maintain coolant levels, balance the grinding wheels using the provided stand, and keep the bed and working areas clean. Adhering to these practices helps sustain high precision and minimizes wear.

Q: How does the coolant and lubrication system benefit the grinding operation?

A: The provided coolant system helps cool the workpiece and grindstone during operations, reducing heat-related distortion and extending tool life. The centralized automatic lubrication system ensures continuous lubrication of critical components, reducing friction, wear, and maintenance efforts.
