Send InquiryMAS VO 50 Radial Drilling Machine
Price 100000 INR/ Piece
MOQ : 1 Piece
MAS VO 50 Radial Drilling Machine Specification
- Condition
- New
- Dimension (L*W*H)
- 2700 x 1070 x 3000 mm
- Machine Type
- Radial Arm Drilling
- Diameter
- 50 mm (Max Drilling Diameter)
- Motor Power
- 3 HP
- Cutting Area
- Large working area suitable for large workpieces
- Noise Level
- Low
- Table Size
- 800 x 630 mm
- Spindle Speed
- 452000 rpm
- Frequency
- 50 Hz
- Features
- Robust Construction, High Precision, Adjustable Arm
- Product Type
- Radial Drilling Machine
- Material
- Cast Iron
- Computerized
- No
- Automatic Grade
- Semi-Automatic
- CNC Or Not
- Normal
- Control System
- Manual
- Voltage
- 415 V
- Power
- 3 HP
- Power Source
- Electric
- Weight (kg)
- 3500 kg
- Capacity
- 50 mm Drilling Capacity
- Color
- Standard (Blue / Grey)
- Usage & Applications
- Heavy Duty Drilling, Tapping, Boring in Workshops and Factories
- Quill Diameter
- 90 mm
- Drilling Head Travel
- 1300 mm
- Column Diameter
- 320 mm
- Max Distance Spindle to Base
- 1250 mm
- Arm Length
- 1600 mm
- Spindle Travel
- 315 mm
- Coolant System
- Equipped
- Model
- VO 50
- Number of Spindle Speeds
- 8
- Rotating Arm
- 360 degrees
- Main Drive Type
- V-belt driven
- Clamping Type
- Manual/Electromechanical
- Spindle Taper
- MT5
MAS VO 50 Radial Drilling Machine Trade Information
- Minimum Order Quantity
- 1 Piece
- Main Domestic Market
- All India
About MAS VO 50 Radial Drilling Machine
Make - MAS (Czech Republic)
Model - VO 50
Drilling Capacity - 60 mm
Spindle Diameter - 85 mm
Arm Length - 1370 mm
Spindle Speeds - 28 rpm to 2500 rpm
Spindle Taper - MT 5
Spindle Feed Travel - 310 mm
Spindle Feed Rate of Travel - 0.05 mm/rev to 2.00 mm/rev
Vertical Travel of Arm - 750 mm
Table Size - 550 mm x 545 mm
Clamping Type - Hydraulic
- Complete with Coolant Tank & Pump.
- Electrical Drawings are available.
- Machine is in excellent working condition.
Video of The Machine -
Robust Engineering for Heavy-Duty Applications
The MAS VO 50 Radial Drilling Machine is meticulously built from premium cast iron, ensuring stability and long service life. Its impressive drilling capacity of up to 50 mm and a large arm length make it suitable for demanding industrial environments. Whether drilling, tapping, or boring, this machine is engineered to handle heavy workloads with ease, providing high accuracy and repeatability for various applications.
Advanced Features for Precision and Efficiency
Equipped with a rotating arm, adjustable arm length, and a heavy-duty MT5 spindle taper, the MAS VO 50 ensures precise alignment and flexibility for working on a wide range of workpiece sizes. Eight spindle speeds and a robust V-belt drive offer optimal torque for different materials. The integrated coolant system enhances tool life and maintains accuracy during prolonged operations.
Versatile and User-Friendly Operation
Designed for semi-automatic use, the VO 50 combines electromechanical and manual controls for ease of operation. The spacious table and generous drilling head travel allow users to process large components efficiently. Safety is enhanced with reliable clamping systems, and low noise levels make it suitable for all-day use in busy workshops or factory environments.
FAQs of MAS VO 50 Radial Drilling Machine:
Q: How does the MAS VO 50 accommodate large and heavy workpieces?
A: The MAS VO 50 features a 1600 mm arm length and a 1300 mm drilling head travel, allowing it to operate across a sizable working area. Its sturdy cast iron construction and 3500 kg weight provide exceptional stability, making it ideal for handling large and heavy workpieces with ease.Q: What benefits does the 360-degree rotating arm offer?
A: The 360-degree rotating arm gives operators the flexibility to position the drilling head precisely where needed without moving the workpiece. This feature streamlines processes, reduces setup time, and supports complex machining on large or irregularly shaped components.Q: When is the MAS VO 50 best suited for use?
A: This machine excels in workshops and factories engaged in heavy-duty drilling, tapping, and boring operations. It is particularly well-suited for industries that require high precision and frequent handling of sizable or dense materials.Q: Where can the MAS VO 50 be installed and used?
A: Given its robust size and weight, the MAS VO 50 is designed for professional industrial environments such as manufacturing floors, fabrication workshops, and repair factories. It requires adequate floor space and proper electrical supply for safe operation.Q: What is the usage process for the VO 50 Radial Drilling Machine?
A: To use the machine, secure the workpiece on the table, adjust the arm and head to the desired position, select an appropriate spindle speed, and clamp components using manual or electromechanical controls. The machines semi-automatic functions and coolant system then facilitate smooth and efficient drilling.Q: How does the V-belt drive enhance performance?
A: The V-belt main drive provides consistent power transfer to the spindle, supports eight variable speeds (from 45 to 2000 rpm), and ensures smooth operation for different drilling tasks. This design improves the machines adaptability to various materials and drilling requirements.
