MAS VR4 Radial Drill

Get a Price/Quote

MOQ : 1 Piece

MAS VR4 Radial Drill Specification

Condition
New

Dimension (L*W*H)
2300 x 1070 x 2720 mm

Cutting Area
Adjustable, up to swing 1600 mm

Noise Level
Low

Machine Type
Radial Drilling Machine

Features
High precision, sturdy construction, smooth operation, easy to use

Frequency
50 Hz

Spindle Speed
75 - 1225 RPM

Diameter
Drilling Capacity 50 mm

Table Size
800 x 630 mm

Motor Power
3 HP

Product Type
Radial Drill Machine

Material
Cast Iron

Computerized
No

Automatic Grade
Semi-Automatic

CNC Or Not
No

Control System
Manual

Voltage
415V

Power
3 HP

Power Source
Electric

Weight (kg)
2250 kg

Capacity
50 mm

Color
Blue & White

Usage & Applications
Used for drilling, tapping, reaming and boring operations in metal and engineering industries.

About MAS VR4 Radial Drill

MAS VR4 Radial Drill

Make - MAS (Czech)
Model - VR4
Capacity - 50 mm
Spindle Diameter - 70 mm
Arm Length - 1500 mm
Spindle Speeds - 45 rpm to 2000 rpm
Spindle Downward Travel - 310 mm
Vertical Travel of Arm - 700 mm
Clamping Type - Manual
Complete with Coolant pump etc.
Machine is in excellent working condition.
2 similar Machines available.

Engineered for Precision and Durability

Constructed from premium cast iron, the MAS VR4 Radial Drill is built to withstand rigorous industrial use while delivering high precision. Its sturdy design minimizes vibration, ensuring consistent and accurate results across a wide range of drilling and boring tasks. The machines large arm length and column diameter provide excellent stability and reach for versatile workshop applications.

Versatile Operations with Adjustable Features

With adjustable spindle speeds, a wide feed range, and an extensive swing of up to 1600 mm, the MAS VR4 offers remarkable flexibility. These features enable users to tackle diverse metalworking operations including tapping, reaming, and boring. Its compatibility with manual and automatic clamping further enhances user convenience and operational efficiency.

User-friendly Controls and Low Noise Operation

Operating on a simple manual control system, the MAS VR4 is straightforward to use, even for less experienced operators. Its semi-automatic grade and low noise level contribute to a comfortable and efficient working environment, making it an ideal choice for busy workshops in engineering and manufacturing sectors.

FAQs of MAS VR4 Radial Drill:

Q: How does the MAS VR4 Radial Drill improve production efficiency in workshops?

A: The MAS VR4 Radial Drill streamlines metalworking tasks through its high precision, multiple spindle speeds, and adjustable feed range, reducing setup times and enabling consistent, accurate drilling. Its robust construction and smooth operation minimize downtime and maintenance requirements, thus enhancing overall productivity.

Q: What materials can be processed using the MAS VR4 Radial Drill?

A: This machine is designed primarily for metalworking and can handle various ferrous and non-ferrous metals. Its sturdy cast iron construction and powerful 3 HP motor make it suitable for engineering industries where demanding drilling, tapping, and reaming operations are required.

Q: When should I choose manual clamping versus automatic clamping on this machine?

A: Manual clamping is ideal for smaller, less frequent operations where quick adjustments are necessary, while automatic clamping is recommended for repetitive tasks or when higher consistency and reduced operator involvement are desired during high-volume production runs.

Q: Where can the MAS VR4 be installed, considering its size and weight?

A: Given its dimensions (2300 x 1070 x 2720 mm) and weight (2250 kg), the MAS VR4 should be installed on a solid, even floor in workshops or factories with sufficient ceiling height and space for safe operation. Ensure there is adequate electrical infrastructure for the 415V power supply.

Q: What is the process for maintaining the MAS VR4 Radial Drill?

A: Regular maintenance involves checking and lubricating moving components, inspecting the spindle, ensuring tightness of bolts and nuts, and servicing the coolant pump. Reviewing the control system and cleaning the machine after each use help prolong its lifespan and maintain optimal performance.

Q: How is the cutting area adjusted for different workpiece sizes?

A: The cutting area can be adjusted by altering the arm position and selecting appropriate spindle speeds and feed rates. This flexibility allows the MAS VR4 to accommodate various workpiece sizes, up to a swing of 1600 mm, making it ideal for both small parts and large components.

Q: What are the main benefits of using the MAS VR4 Radial Drill?

A: Key benefits include high precision, sturdy build, versatile operations, easy-to-use controls, and low noise levels. The machines adjustable settings and efficient coolant system further improve safety, productivity, and quality of finished parts in industrial environments.
