MAS VRM50A Portable Universal Radial Drilling Machine

Name: MAS VRM50A Portable Universal Radial Drilling Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

MAS VRM50A Portable Universal Radial Drilling Machine Specification

Features
Portable, Universal Radial Arm, Precision machining, Rugged build, Easy controls

Cutting Area
Adjustable via radial arm

Diameter
Max drilling diameter 50 mm

Dimension (L*W*H)
2300 x 900 x 2600 mm

Motor Power
3 HP

Frequency
50 Hz

Table Size
500 x 420 mm

Spindle Speed
32 - 1600 rpm

Machine Type
Radial Drilling Machine

Noise Level
<75 dB

Condition
New

Product Type
Portable Universal Radial Drilling Machine

Material
Cast Iron, Steel

Computerized
No

Automatic Grade
Semi-Automatic

CNC Or Not
No

Control System
Manual

Voltage
415 V

Power
3 HP

Power Source
Electric

Weight (kg)
1450 kg

Capacity
50 mm (Drilling)

Color
Green

Usage & Applications
Drilling, Tapping, Reaming for metal fabrication, workshop, and manufacturing

Distance Spindle to Column
400 - 1600 mm

Distance Spindle to Base
1250 mm

Taper in Spindle
Morse Taper No. 4

Column Diameter
250 mm

Coolant System
Inbuilt

Number of Spindle Speeds
12

Spindle Travel
300 mm

Base Size
1300 x 750 mm

Arm Length
1600 mm

MAS VRM50A Portable Universal Radial Drilling Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About MAS VRM50A Portable Universal Radial Drilling Machine

Make - MAS (Czech Republic)

Model - VRM50A

Drilling Capacity - 65 mm

Spindle Diameter - 80 mm

Cross-Rail Horizontal Travel (Longitudinal) - 900 mm

Vertical Travel of the Arm - 1250 mm

Travel of Column on the Base - 1225 mm

Max. Distance between Spindle Center to Vertical Column - 2050 mm

Max. Height between Spindle to Floor - 1570 mm

Spindle Taper - MT 5

Spindle Feed Travel - 350 mm

Spindle Rotation on Vertical Axis - 180 degree to -180 degree

Spindle Rotation on Horizontal Axis - 105 degree to -105 degree

Spindle Speeds - 16 rpm to 800 rpm

Spindle Feed Rates - 0.05 mm/rev to 0.50 mm/rev

Column Rotation - 360 degree

- It is a 7-Axis Universal Radial Arm type Drilling Machine.

- Electrical Drawings of the Machine is available.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/WnUENmcIUeg

Precision Drilling with Universal Application

The MAS VRM50A Radial Drilling Machine delivers exceptional precision for drilling, tapping, and reaming tasks. Its advanced radial arm and adjustable spindle offer flexibility, covering a spectrum of drilling positions and angles, making it suitable for varied workshop and manufacturing needs.

Engineered for Durability and Efficiency

Constructed from robust cast iron and steel, this machine ensures stability and longevity. With an inbuilt coolant system, semi-automatic operation, and an electric-powered 3 HP motor, it maintains high performance while minimizing noise and operational fatigue.

User-Friendly Controls and Versatile Design

Manual controls and a universal radial arm make operation straightforward, enabling quick adjustments to fit different materials and task requirements. The spacious base and table accommodate sizeable workpieces, supporting both small-scale and industrial-level projects.

FAQ's of MAS VRM50A Portable Universal Radial Drilling Machine:

Q: How does the adjustable radial arm benefit the drilling process on the MAS VRM50A?

A: The adjustable radial arm allows the machine to position the drilling spindle at various points over the workpiece, offering flexibility for reaching different drilling locations and accommodating larger or irregularly shaped items.

Q: What types of metalworking applications is the MAS VRM50A suitable for?

A: This machine is ideal for drilling, tapping, and reaming in metal fabrication, workshops, and manufacturing units, supporting versatile industrial processes with its sturdy build and precision controls.

Q: Where can the MAS VRM50A be effectively installed and used?

A: It is best suited for professional environments such as fabrication workshops, manufacturing facilities, and repair centers where versatile, heavy-duty drilling equipment is required.

Q: What is the process for adjusting spindle speed on this machine?

A: The MAS VRM50A has 12 spindle speeds ranging from 32 to 1600 rpm. Spindle speed can be easily adjusted via manual controls, enabling users to match the speed to their specific drilling requirements.

Q: What power supply is required for operating this radial drilling machine?

A: The machine operates on a 415 V electrical power supply and requires 3 HP with a frequency of 50 Hz, making it compatible with most industrial electrical systems.

Q: What are the main benefits of using the MAS VRM50A Radial Drilling Machine?

A: Users benefit from its portability, sturdy construction, broad drilling area, inbuilt coolant system, low noise level, and user-friendly manual operation, all contributing to precise and efficient metalworking.
