Mazak Slant Turn 50 x 3100 CNC Lathe Machine

Price 200000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Mazak Slant Turn 50 x 3100 CNC Lathe Machine Specification

Product Type
CNC Lathe Machine

General Use
Turning and machining of large, heavy components

Material
Suitable for steel, cast iron, and non-ferrous metals

Type
Horizontal

Capacity
Max Turning Diameter: 900 mm, Max Turning Length: 3100 mm

Weight (kg)
Approx. 18000 kg

Computerized
Yes

Automatic
Yes

PLC Control
Yes

Bar Feeder
Not Included

Power Source
Electric

Power Consumption
Approx. 37 kW

Rigidity
High rigidity with heavy-duty box construction

Voltage
400 V, 3 Phase

Motor
Main Spindle Motor 37 kW

Table Size
Max Swing over Bed: 900 mm

Spindle Speed
5 2000 rpm

Axial Choice
2 Axis (X, Z)

Dimension (L*W*H)
6900 x 2400 x 2600 mm

Feature
Large swing and long machining length for heavy-duty part production

Color
Standard Mazak Grey/White

About Mazak Slant Turn 50 x 3100 CNC Lathe Machine

Make - Mazak (Japan)

Model - Slant Turn 50

Max. Diameter over Bed - 810 mm

Max. Diameter over Saddle - 598 mm

Max. Working Length - 3100 mm

Max. Spindle Speed - 1600 rpm

Chuck Diameter - 380 mm

CNC Control - Mazatrol Cam T-2

- 2 x Steadies = 1 X Hydraulic type of Dia. 49 to 210 mm and 1 x Dia. 530 mm

- Complete with Chip Conveyor.

- Operating Manual, Electrical Drawings etc. are available.

- Machine is in complete working condition.

Versatile Heavy-Duty Machining

Designed for exceptional rigidity, the Mazak Slant Turn 50 x 3100 accommodates large workpieces with up to 3000 kg load on the chuck and a swing over bed of 900 mm. Its heavy-duty box construction minimizes vibration and maximizes precision, making it well-suited for industries needing robust turning and machining of components such as shafts and housings.

Advanced Control with MAZATROL CNC

The integrated MAZATROL CNC control system enables computerized and automated operation, simplifying program setup and repeatability. With rapid traverse rates and a 12-station turret, users experience reduced cycle times and enhanced process efficiency for a wide range of turning tasks.

Efficient and Reliable Performance

The machines automatic lubrication, precision ground ballscrew, and fitted coolant system contribute to smooth, precise operation and consistent part quality. With a main spindle motor of 37 kW and support for 400 V, 3-phase electric power, it delivers dependable performance for high-volume production environments.

FAQs of Mazak Slant Turn 50 x 3100 CNC Lathe Machine:

Q: How does the Mazak Slant Turn 50 x 3100 CNC Lathe machine benefit heavy-duty parts production?

A: The Mazak Slant Turn 50 x 3100 offers high rigidity and large machining capacity, enabling efficient turning and machining of heavy, oversized components. Its robust construction and 24-inch chuck allow secure handling of parts up to 3000 kg, making it ideal for demanding industrial applications.

Q: What materials can be processed with this CNC lathe machine?

A: This lathe is suitable for machining steel, cast iron, and non-ferrous metals, making it versatile for various industries such as automotive, energy, and general manufacturing.

Q: Where can this lathe machine be installed, and what are its space requirements?

A: The machine is designed for installation in facilities with adequate electrical supply and a minimum space requirement of approximately 8 x 3 x 3 meters. Its dimensions (6900 x 2400 x 2600 mm) should be considered when planning the layout within manufacturing plants.

Q: What is the process for operating the machines MAZATROL CNC control system?

A: Operators set up machining programs using the user-friendly MAZATROL CNC interface, allowing for quick configuration and adjustment of cutting parameters. The system supports efficient workflow management for both one-off and repeat production tasks.

Q: When is the coolant and lubrication system used during operation?

A: The coolant and automatic lubrication systems are engaged during machining cycles to maintain optimal temperature, reduce wear on components, and ensure consistent performance, especially during extended or heavy-duty operations.

Q: What is the maximum turning length and diameter the machine can handle?

A: The Mazak Slant Turn 50 x 3100 can accommodate parts with a maximum turning diameter of 900 mm and a maximum turning length of 3100 mm, supporting the production of large, complex components.

Q: How does the precision ground ballscrew contribute to machine performance?

A: The precision ground ballscrew ensures accurate linear movement of the axes, reducing backlash and increasing machining precision for high-quality output.
