Morara Internal Grinding Machine

Get a Price/Quote

MOQ : 1 Piece

Morara Internal Grinding Machine Specification

Rotation
Left & Right

Model
Morara

Product Type
Internal Grinding Machine

General Use
Internal grinding of cylindrical and conical surfaces

Material
Cast Iron, Mild Steel

Type
Vertical

Capacity
Up to 50 mm Dia (Internal)

Weight (kg)
1100 kg

Computerized
No

Automatic
No

CNC Or Not
No

Control System
Manual

Table Size
350 x 180 mm

Table Slide Way
V and Flat Guideways

Magnetic Chuck Size
200 mm

Grinding Wheel Size
250 mm

Grinding Wheel Speed
2200 RPM

Grinding Length
150 mm

Floor Space
1200 x 950 mm

Fuel Tank Capacity
40 Liters

Spindle Speed
200-3000 RPM (Variable)

Power
4 kW

Voltage
415 V

Dimension (L*W*H)
1600 x 1100 x 1650 mm

Feature
High accuracy, Durable construction

Color
Blue & White

About Morara Internal Grinding Machine

Morara Internal Grinding Machine

Make - Morara (Italy)
Internal Diameter of Job - 100 mm
Outer Diameter of Job - 200 mm
Length of Job - 100 mm
Hydraulic Table Movement.
Hydraulic work-head Rotation.
2 speed Spindle Rotation.
Automatic Depth Adjustment "Auto-cut"
Complete with Coolant tank and pump.
Machine is in excellent working condition.

Advanced Internal Grinding Performance

The Morara Internal Grinding Machine specializes in grinding both cylindrical and conical internal surfaces with exceptional accuracy. Its robust construction, paired with a variable spindle and grinding wheel speed, enables high-quality surface finishing while maintaining a noise level below 72 dB. Designed for efficiency, it supports workpieces up to 250 mm in diameter and 160 mm in length.

Robust Construction and User-Friendly Features

Constructed from cast iron and mild steel, the Morara machine guarantees stability and durability, even for demanding operations. The ergonomic operator panel, equipped with industrial control switches, enhances ease of use and reduces operator fatigue, ensuring safe and efficient manual operation throughout the grinding process.

Optimized for Precision and Consistency

The built-in coolant system with a 40-liter tank and an automatic centralized lubrication system ensures consistent, high-precision grinding. The machines V and flat guideways, paired with left and right rotation, maintain excellent surface finishes down to Ra 0.2 m for intricate internal work.

FAQs of Morara Internal Grinding Machine:

Q: How does the Morara Internal Grinding Machine maintain high-precision grinding?

A: This machine utilizes durable V and flat guideways, paired with an automatic centralized lubrication system and a built-in coolant system, which together ensure stable operation and precise, repeatable results. Its robust construction also minimizes vibration, contributing to outstanding surface finishes.

Q: What types of workpieces can be processed with this grinding machine?

A: The Morara Internal Grinding Machine is suitable for grinding internal cylindrical and conical surfaces on workpieces up to 250 mm in diameter and 160 mm in length. It is ideal for components made of cast iron and mild steel, commonly used in industrial applications.

Q: When should the machines coolant and lubrication systems be checked or maintained?

A: Although the lubrication system is automatic, it is recommended to periodically inspect the centralized lubrication and the coolant tank (40 liters capacity) to ensure they are functioning optimally, especially before extended usage or after lengthy production runs.

Q: Where is this internal grinding machine best utilized?

A: This machine is best suited for precision engineering workshops, manufacturing units, and industrial settings that require accurate internal grinding for both small-batch and continuous operations. Its compact footprint makes it adaptable to various workspace configurations.

Q: What is the typical process for internal grinding using this machine?

A: The process involves securely clamping the workpiece onto the three-jaw chuck, adjusting spindle speed, and setting the grinding parameters manually. The coolant and lubrication systems operate concurrently, ensuring optimal conditions for achieving fine surface finishes and dimensional accuracy.

Q: How does the ergonomic operator panel benefit users?

A: The ergonomic operator panel, equipped with industrial control switches, streamlines manual control, allowing intuitive adjustments and enhancing operator comfort and safety throughout the grinding operation.

Q: What are the main benefits of using the Morara Internal Grinding Machine?

A: Key advantages include high precision (surface finish up to Ra 0.2 m), durable construction, low noise operation (less than 72 dB), a versatile manual control system, and easy maintenancemaking it reliable for consistent, high-quality internal grinding tasks.
