Nolaf France Universal Cylindrical Grinder Machine

Name: Nolaf France Universal Cylindrical Grinder Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Nolaf France Universal Cylindrical Grinder Machine Specification

Product Type
Universal Cylindrical Grinder Machine

General Use
Industrial Grinding Applications

Material
Cast Iron, Steel

Type
Manual and Semi-Automatic

Capacity
Up to 200mm diameter

Weight (kg)
Approx. 1500 kg

Computerized
No

Automatic
Optional

Control System
Hand-operated/PLC (optional)

Drive Type
Electric Motor Driven

Grinding Diameter
6 mm to 200 mm

Grinding Length
Up to 800 mm

Spindle Speed
303000 rpm

Grinding Wheel Size
350 mm x 40 mm x 127 mm

Voltage
415V 3 Phase

Dimension (L*W*H)
2200 mm x 1250 mm x 1500 mm

Feature
Precision Grinding, Sturdy Construction, Adjustable Table, High Accuracy

Color
White & Blue

Coolant System
Integrated

Lubrication
Automatic

Installation
On-site available

Tailstock Taper
MT3

Surface Finish
Ra 0.2 m

Wheel Head Motor
3 HP

Work Head Taper
MT4

Table Traverse
900 mm

Safety Features
Overload protection, Emergency stop button

Machine Bed
High-grade Meehanite casting

Max Load on Table
200 kg

Chuck Size
Up to 200 mm

Nolaf France Universal Cylindrical Grinder Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Nolaf France Universal Cylindrical Grinder Machine

Make - Nolaf (France)

Center Height - 130 mm

Max. Job Diameter - 250 mm

Max. Length of Job - 500 mm

Grinding Wheel Size - Diameter 300 mm x 40 mm Width

Table Rotation - 8 degree to -8 degree

- Equipped with Internal Grinding Attachment.

- Features like Automatic Plunge Grinding and Delay Feature.

- Table & Wheel-Head both have Hydraulic Travels.

- Complete with Wheel Dresser, Coolant Tank and Pump.

- Machine is in excellent working condition.

Video of the Machine -

https://youtu.be/n4JbIQBBwAE

Precision and Versatility for Industrial Needs

The Nolaf France Universal Cylindrical Grinder excels at producing high-accuracy components across a wide range of industrial settings. With an adjustable table, hand-operated or optional PLC control, and a grinding diameter capacity from 6 mm to 200 mm, this machine suits both custom and standardized jobs. Its sturdy construction, reliable mechanics, and safety infrastructure meet varied production requirements.

Integrated Systems and Operator Safety

This grinding machine incorporates advanced features like a fully integrated coolant system and an automatic lubrication system, ensuring smooth operation and reduced downtime. Overload protection and an emergency stop button guarantee operator safety. The high-grade Meehanite casting ensures the machine remains stable even during demanding grinding tasks.

Efficient On-site Installation and Support

Nolaf France provides on-site installation for hassle-free setup, ensuring your machine is properly calibrated and ready for operation. The machine's dimensions and accessible layout allow for easy integration into existing workshop floors, while clear documentation streamlines the installation process.

FAQ's of Nolaf France Universal Cylindrical Grinder Machine:

Q: How is the Nolaf France Universal Cylindrical Grinder installed?

A: On-site installation is available for the Nolaf France Universal Cylindrical Grinder. Trained technicians set up the machine, calibrate it for immediate use, and provide comprehensive operational training as needed.

Q: What materials can be processed with this grinder machine?

A: This universal cylindrical grinder is designed for processing cast iron, steel, and other similar industrial materials, offering reliable precision across various applications.

Q: When should automatic lubrication be checked or refilled?

A: The automatic lubrication system is designed for continuous operation but should be checked periodically as recommended in the machine's maintenance guide. Regular inspections help maintain optimal performance and prevent wear.

Q: Where can this machine be used effectively?

A: This grinding machine is ideal for industrial workshops, manufacturing plants, and any facility requiring high-precision cylindrical grinding. Its size and robust build accommodate diverse grinding tasks in both small and large-scale operations.

Q: What safety features does the machine have?

A: Key safety features include overload protection and a prominent emergency stop button, providing quick shutdown in case of any operational anomalies, ensuring operator safety at all times.

Q: How does the integrated coolant system benefit the grinding process?

A: The integrated coolant system maintains optimal temperatures during grinding, minimizing thermal distortion, improving surface finish, and extending grinding wheel life for consistent quality results.

Q: What are the maximum load and grinding dimensions supported?

A: The machine supports a maximum table load of 200 kg, accepts work head tapers up to MT4, and can grind diameters from 6 mm up to 200 mm, with grinding lengths up to 800 mm.
