Nomo Italy 2500 mm x 600 mm Bed Milling Machine

Name: Nomo Italy 2500 mm x 600 mm Bed Milling Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Nomo Italy 2500 mm x 600 mm Bed Milling Machine Specification

Model
Nomo Italy 2500 x 600

Rotation
Spindle - Horizontal

Product Type
Bed Milling Machine

General Use
Industrial Bed Milling Operations

Material
Heavy Duty Cast Iron & Alloy Steel

Type
Horizontal

Capacity
Heavy Duty, Max Workpiece Weight approx. 2200 kg

Weight (kg)
Estimated 4300 kg

Computerized
No

Automatic
No

CNC Or Not
Not CNC

Control System
Manual

Table Size
2500 mm x 600 mm

Table Slide Way
Box Type

Floor Space
Approximately 3500 mm x 2200 mm

Spindle Speed
Variable, up to 1800 RPM

Power
7.5 kW

Voltage
415 V, 3 Phase

Dimension (L*W*H)
Approx. 3500 mm x 2200 mm x 1700 mm

Feature
Manual operation, robust design, precision slideways

Color
Standard Industrial Grey

Handwheel Graduation
0.02 mm/div

Spindle Motor
7.5 kW 3 Phase Induction

Table Travel (Cross)
620 mm

Safety Features
Emergency stop, overload protection

T-Slot Size
22 mm

Number of T-Slots
5

Table Travel (Longitudinal)
2200 mm

Coolant Pump Capacity
60 L/min

Spindle Bore
ISO 50 Taper

Electrical Cabinet
Included, IP54

Max Distance Spindle to Table
650 mm

Rapid Traverse
Yes, for X and Y axis

Working Speed
Feed Rate up to 1000 mm/min

Lubrication System
Integrated automatic lubrication

Nomo Italy 2500 mm x 600 mm Bed Milling Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Nomo Italy 2500 mm x 600 mm Bed Milling Machine

Make - Nomo (Italy)

Model - F.B.F. 2200

Table Size - 2500 mm x 600 mm

XYZ Travel - 2180 mm x 680 mm x 800 mm

Horizontal Spindle Taper - ISO 50

Horizontal Spindle Speeds - 30 rpm to 1450 rpm

Vertical Spindle Taper - ISO 50

Vertical Spindle Speeds - 25 rpm to 1500 rpm

Feed Rates of Travel - 5 mm/min to 1000 mm/min (Infinitely Variable)

Over-Arm Travel of the Vertical Milling Machine - 650 mm

Horizontal Spindle Motor - 11 kW

Vertical Spindle Motor - 7.5 kW

Max. Distance between Table Top & Vertical Spindle - 865 mm

- Equipped with a 3-Axis DRO.

- Electrical Drawings & Operating Manuals are available.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/A-Hj4eiqXR0

Heavy-Duty Performance for Demanding Tasks

Built with heavy-duty cast iron and alloy steel, the Nomo Italy 2500 x 600 Bed Milling Machine delivers exceptional strength and stability for rigorous industrial operations. Its large working table, robust design, and high spindle power enable you to handle extensive milling jobs with precision.

Superior Precision and Versatility

The manual controls, precision slideways, and a 0.02 mm/div handwheel graduation provide excellent operational control. Capable of variable spindle speeds up to 1800 RPM and a feed rate up to 1000 mm/min, this milling machine adapts seamlessly to different materials and milling requirements.

Reliable Safety and Maintenance Features

Equipped with emergency stop, overload protection, integrated automatic lubrication, and an IP54 electrical cabinet, the Nomo Italy 2500 x 600 ensures operator safety and machine longevity. Routine maintenance is straightforward, thanks to its accessible design and efficient lubrication system.

FAQs of Nomo Italy 2500 mm x 600 mm Bed Milling Machine:

Q: How do I operate the Nomo Italy 2500 x 600 Bed Milling Machine for industrial milling processes?

A: The machine is manually operated, featuring handwheels with 0.02 mm/division graduations for precise adjustments. Simply use the manual controls to set table movement (longitudinal and cross), spindle speed (up to 1800 RPM), and feed rate. The machines rapid traverse feature on X and Y axes streamlines workflows during setup and adjustments.

Q: What materials and workloads is this milling machine best suited for?

A: This model is engineered for heavy-duty, industrial milling operations and is constructed from cast iron and alloy steel. It supports workpieces up to approximately 2200 kg, making it ideal for machining large metal components in manufacturing, fabrication, and maintenance settings.

Q: When should I use the integrated automatic lubrication system?

A: The integrated automatic lubrication system is designed to function continuously during machine operation, minimizing wear and tear. No manual intervention is required, but periodic checks (as per the maintenance schedule) ensure smooth system performance and extend machine life.

Q: Where can I install the Nomo Italy 2500 x 600 in my facility?

A: Given its floor space requirement of around 3500 mm x 2200 mm, the machine should be installed in a spacious, leveled area with access to 415 V, 3-phase electrical supply. Ensure proper clearance for loading/unloading workpieces and for routine maintenance.

Q: What is the typical process flow when using this bed milling machine?

A: Begin by securely mounting your workpiece on the 5 T-slot table. Adjust table movement, set spindle speed and feed rate manually. Engage the spindle, and proceed with milling operations, utilizing rapid traverse for efficient table movement. Emergency stop and overload protections ensure safety during operation.

Q: How does this machine benefit my industrial operations compared to CNC models?

A: While not CNC, this bed milling machine offers robust manual control for skilled operators, ensuring flexibility in custom operations and one-off tasks. Its heavy-duty build and precision lead to reliable results, lower upfront investment, and simpler maintenance compared to more complex computerized systems.

Q: What are the key safety features included with the Nomo Italy 2500 x 600?

A: The machine incorporates emergency stop, overload protection, and an IP54-rated electrical cabinet. These features collectively enhance operator safety, safeguarding both personnel and equipment during demanding milling procedures.
