TOS FA5V Vertical Milling Machine

Price 19000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

TOS FA5V Vertical Milling Machine Specification

Model
TOS FA5V

Rotation
Spindle Rotation

Product Type
Vertical Milling Machine

General Use
Industrial Metal Machining

Material
Cast Iron

Type
FA5V

Capacity
High

Weight (kg)
3500 kg

Computerized
No

Automatic
No

CNC Or Not
Not CNC

Control System
Manual

Table Size
1600 mm x 400 mm

Table Slide Way
Box type

Floor Space
2600 mm x 2240 mm

Spindle Speed
351600 rpm

Power
7.5 kW

Voltage
380415 V / 3 phase

Dimension (L*W*H)
2600 mm x 2240 mm x 2000 mm

Feature
Heavy Duty, Precision Milling

Color
Grey/Blue

Lubrication
Centralized

WorkingSpeed
Variable

Coolant System
Integrated

Feed Rate
Automatic & Manual

Table Swivel
45

Rapid Traverse
3000 mm/min

Longitudinal Travel
1250 mm

Number of Speeds
18

Machine Construction
Rigid One-Piece Bed

Quill Stroke
120 mm

Spindle Taper
ISO 50

Max. Load on Table
800 kg

Electrical System
Standard Three Phase

Distance Spindle Nose To Table
30480 mm

Cross Travel
400 mm

Vertical Travel
450 mm

TOS FA5V Vertical Milling Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About TOS FA5V Vertical Milling Machine

Make - TOS (Czech Republic)

Model - FA5V

Table Size - 2000 mm x 425 mm

XYZ Travel - 1400 mm x 450 mm x 450 mm

Spindle Taper - ISO 50

Spindle Speeds - 18 rpm to 1400 rpm

Table Feed Rates - 10 mm/min to 1250 mm/min

Head Swivel Angle - +45 degree to -45 degree

Spindle Quill Diameter - 210 mm

- Machine is in excellent working condition.

Video of The Machine-

https://youtu.be/4w_DSqtqlmw

Engineered for Industrial Excellence

Designed with a rigid one-piece cast iron bed, the TOS FA5V ensures maximum stability and vibration resistance. Its large workspace, accommodating up to 800 kg on the table, is complemented by a comprehensive speed range and superb feed options. These features together guarantee a superior machining experience for demanding industrial environments.

Precision and Versatility in Every Detail

With travel distances of 1250 mm longitudinal, 400 mm cross, and 450 mm vertical, the FA5V offers exceptional versatility. The machines 45 swivel table and variable working speed accommodate complex machining tasks, while the ISO 50 spindle and box-type slide way deliver reliable accuracy and repeatable performance for precision work.

Efficient Operation and Rugged Durability

Integrated coolant and centralized lubrication systems help maintain machine integrity, extending operational life and reducing maintenance needs. With rapid traverse at 3000 mm/min and a robust electrical system, the FA5V supports efficient workflows typical in industrial metalworking settings. Its manual controls provide intuitive operation for skilled machinists.

FAQs of TOS FA5V Vertical Milling Machine:

Q: How is the TOS FA5V Vertical Milling Machine used in industrial metal machining?

A: The TOS FA5V is designed for a variety of heavy-duty and precision milling operations in industrial settings. Its combination of high load capacity, versatile table movement, and adjustable speed control allows users to efficiently machine large metal components with high precision.

Q: What benefits does the integrated coolant and centralized lubrication system offer?

A: The integrated coolant system keeps workpieces and tools at optimal temperatures, reducing wear and maintaining machining accuracy. The centralized lubrication ensures all critical components are well-oiled, enhancing performance and extending the longevity of the milling machine.

Q: When should the spindle speed and feed rates be adjusted?

A: Operators should adjust spindle speed (351600 rpm) and feed rates depending on the material, desired finish, and cutting tool used. Lower speeds might be used for harder materials, while faster speeds suit softer metals. Choice of feed rate also depends on the level of precision and surface quality required.

Q: Where is the TOS FA5V primarily utilized?

A: This milling machine is typically used in industrial workshops, manufacturing plants, and metalworking facilities requiring high-precision, heavy-duty milling. Its robust construction and high capacity make it suitable for demanding applications in various industries.

Q: What is the process for changing the table position and angles?

A: The table can be moved longitudinally (1250 mm), crosswise (400 mm), and vertically (450 mm). Additionally, the table can be swiveled 45, allowing for angular milling. All table movements are adjusted manually using the provided feed controls.

Q: How does the rigid one-piece bed contribute to machining performance?

A: The cast iron one-piece bed reduces machine vibration and flexing, ensuring greater stability during operation. This construction enhances accuracy, allows for heavy workpieces, and extends machine life by minimizing wear caused by structural movements.
