TOS FA5U Heavy Duty Universal Milling Machine

Name: TOS FA5U Heavy Duty Universal Milling Machine
Brand: Liberty Metal & Machines Private Limited
Price: 21000 INR
Availability: InStock

Price 21000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

TOS FA5U Heavy Duty Universal Milling Machine Specification

Model
FA5U

Rotation
Horizontal/Vertical Spindle

Product Type
Heavy Duty Universal Milling Machine

General Use
Industrial Metal Milling

Material
Cast Iron/Steel Construction

Type
Universal Milling Machine

Capacity
Max load 900 kg on table

Weight (kg)
Approx. 3200 kg

Computerized
No

Automatic
Manual with auto-feed options

CNC Or Not
Not CNC

Control System
Manual

Table Size
1600 x 400 mm

Table Slide Way
Hardened and Ground

Floor Space
2800 x 2570 mm

Spindle Speed
12 steps, 28-1400 rpm

Power
7.5 kW

Voltage
415 V, 3 Phase

Dimension (L*W*H)
Approx. 2800 x 2570 x 1800 mm

Feature
Swiveling Table, Hardened Ways, Heavy Duty Build

Color
Standard Industrial Grey/Green

Cross Traverse (Y-Axis)
315 mm

Milling Spindle Taper
ISO 50

Feed Range (mm/min)
20-1000

Coolant System
Integrated

Lubrication System
Centralized

Rapid Traverse (X/Y/Z)
2500 mm/min

Swivel Angle of Table
±45°

Vertical Traverse (Z-Axis)
450 mm

Overarm Diameter
120 mm

Number of Feeds (X/Y/Z)
18

Longitudinal Traverse (X-Axis)
1120 mm

Max Distance Spindle Nose to Table
500 mm

Universal Table Rotation
±45° horizontal

TOS FA5U Heavy Duty Universal Milling Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About TOS FA5U Heavy Duty Universal Milling Machine

Make - TOS (Czech Republic)

Model - FA5U

Table Size - 2000 mm x 400 mm

XYZ Travels - 1250 mm x 400 mm x 400 mm

Spindle Speeds - 18 rpm to 1400 rpm

Spindle Taper - ISO 50

Table Feed Rates - 10 mm/min to 1250 mm/min

Rotary Table Diameter - 500 mm

- Automatic Rotary Table with Feed and Rapid Rotations.

- With Arbour & Bracket for Horizontal Milling operations.

- With Vertical Milling Head for Vertical Milling operations.

- Rotating type Universal Table.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/zNKIM8RH4nc

Precision Engineering for Industrial Milling

The FA5U is designed for precise and versatile milling operations in the manufacturing sector. Its hardened, ground slide ways and heavy-duty construction ensure accuracy and stability under maximum loads. The swiveling table and multiple feed rates enable efficient production, making it suitable for workshops, factories, and job shops seeking reliable machining capabilities.

Advanced Features for Enhanced Performance

Equipped with a powerful motor, rapid traverse options, and centralized lubrication, the FA5U ensures seamless operation and minimal downtime. The integrated coolant system keeps tools and workpieces at optimal temperatures, while the auto-feed modes simplify repetitive milling tasks. Its universal ability to rotate in both horizontal and vertical spindle configurations adds greater flexibility to your machining process.

FAQs of TOS FA5U Heavy Duty Universal Milling Machine:

Q: How do I adjust the milling spindle speed on the TOS FA5U?

A: The FA5U milling machine offers 12 spindle speed steps ranging from 28 to 1400 rpm. You can manually select the desired speed using the control levers situated on the machine, adjusting based on your tooling and the material being milled.

Q: What types of workpieces can the FA5U accommodate?

A: The machine is suitable for industrial metal milling and can handle a maximum table load of 900 kg, with a spacious 1600 x 400 mm table. Common workpieces include steel, cast iron, and other metals, making it ideal for fabrication and manufacturing environments.

Q: When is auto-feed used on this universal milling machine?

A: Auto-feed options are typically used during consistent, repeatable milling operations to ensure smoother finishes and uniform feed rates. This feature is beneficial for production runs, reducing manual labor and increasing operational efficiency.

Q: Where is the FA5U universal milling machine commonly installed?

A: Due to its size (approx. 2800 x 2570 x 1800 mm) and robust construction, the FA5U is predominantly found in industrial manufacturing facilities, machine shops, and metalworking plants, where heavy-duty milling is required.

Q: What benefit does the swiveling table feature provide?

A: The tables ability to swivel 45 horizontally and vertically allows for complex angular milling without repositioning the workpiece. This significantly expands the versatility of operations and reduces setup time for advanced machining tasks.

Q: How does the centralized lubrication system enhance machine longevity?

A: The machines centralized lubrication system delivers consistent lubrication to all essential components, minimizing wear and extending overall lifespan. This also simplifies maintenance and ensures stable, reliable performance.

Q: What is the process for engaging the integrated coolant system during operation?

A: The coolant system is activated via manual controls before starting the milling process. It continuously supplies coolant to the cutting zone, reducing heat buildup, improving tool life, and maintaining optimal machining accuracy.
