Tiger UF3 Universal Milling Machine

Price 4200 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Tiger UF3 Universal Milling Machine Specification

Product Type
Universal Milling Machine

General Use
Universal milling operations

Material
Cast Iron

Type
Manual

Capacity
Standard

Weight (kg)
800 kg

Computerized
No

Automatic
No

CNC Or Not
Not CNC

Control System
Manual

Table Size
1200x300 mm

Table Slide Way
Precision ground

Floor Space
Compact

Spindle Speed
Variable up to 1500 RPM

Power
5 HP

Voltage
380V 3-phase

Dimension (L*W*H)
1500x800x1200 mm

Feature
Heavy-duty design

Color
Green

Warranty
6 months

About Tiger UF3 Universal Milling Machine

Tiger (Italy) make Universal Milling Machine in excellent working condition. The model of the machine is UF3 and the Table Size is 1525 mm x 305 mm. The technical details are as follows -

Make - Tiger (Italy)
Model - UF3
Table Size - 1525 mm x 305 mm
XYZ Travel - 1050 mm x 280 mm x 475 mm
Spindle Taper - ISO 50
Spindle Speeds - 27 rpm to 1600 rpm
Table Feed Travel Rate - 9 mm/min to 500 mm/min
With 2 x Brackets, 1 x Arbour, 1 x Support for Horizontal Milling.
Rotating type Universal Table.
Machine is in excellent working condition.

FAQs of Tiger UF3 Universal Milling Machine:

Q: What is the floor space requirement for the Tiger UF3 Universal Milling Machine?

A: The Tiger UF3 Universal Milling Machine has a compact floor space design.

Q: What is the power capacity of the Tiger UF3 Universal Milling Machine?

A: The Tiger UF3 Universal Milling Machine has a 5 HP power capacity.

Q: Is the Tiger UF3 Universal Milling Machine computerized?

A: No, the Tiger UF3 Universal Milling Machine is not computerized.

Q: What is the warranty period for the Tiger UF3 Universal Milling Machine?

A: The Tiger UF3 Universal Milling Machine comes with a 6-month warranty.

Q: What is the material used for the Tiger UF3 Universal Milling Machine?

A: The Tiger UF3 Universal Milling Machine is made of cast iron.
