Rambaudi Versamill Bed Type Milling Machine

Name: Rambaudi Versamill Bed Type Milling Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Rambaudi Versamill Bed Type Milling Machine Specification

Rotation
Spindle rotation both directions

Model
Versamill

Product Type
Bed Type Milling Machine

General Use
Industrial, Metalworking, Heavy duty milling

Material
Cast Iron

Type
Horizontal / Universal

Capacity
Suitable for medium to heavy duty milling operations

Weight (kg)
Approx. 2500 kg

Computerized
No

Automatic
No, manual operation

CNC Or Not
Manual

Control System
Lever/Handwheel operated

Table Size
1300 x 360 mm

Table Slide Way
Hardened and ground

Floor Space
Approx. 2200 x 2000 mm

Spindle Speed
30 - 1800 rpm (variable)

Power
5.5 kW

Voltage
415 V

Dimension (L*W*H)
2200 x 2000 x 1600 mm

Feature
Robust structure, precision slideways, universal head

Color
Standard Machine Grey (as per Image)

Table Load Capacity
700 kg

Standard Accessories
Milling arbors, drawbar, wrench set

Cross Traverse (Y-axis)
360 mm

Maximum Distance Spindle Nose to Table
500 mm

Vertical Traverse (Z-axis)
400 mm

Noise Level
Low (as per industrial standards)

Lubrication System
Centralized lubricating system

Coolant System
Fitted

Spindle Taper
ISO 50

Head Type
Universal swivelling head

Longitudinal Traverse (X-axis)
900 mm

Warranty Coverage
Covers main motor and mechanical assembly for 6 months

Working Speed
Mechanical, based on spindle speed and feed rate

Feeds
Multiple mechanical feed rates

Rambaudi Versamill Bed Type Milling Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Rambaudi Versamill Bed Type Milling Machine

Make - Rambaudi (Italy)

Model - Versamill

Table Size - 1600 mm x 510 mm

XYZ Travel of Table - 1200 mm x 700 mm x 900 mm

Spindle Taper - ISO 50

Spindle Speeds - 22 rpm to 2000 rpm

Feed Rate of Travels - 0 mm/min to 2000 mm/min (Continuously Variable)

Vertical Spindle Travel - 150 mm

Max. Height between Table Top to Vertical Spindle - 650 mm

Over-Arm Travel of Milling Head - 400 mm

- Vertical Milling Head can be removed to do Horizontal Milling.

- Automatic Feed Spindle Travels in Vertical Milling Head for Boring Operations.

- Equipped with 3-Axis DRO.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/j3tpkIG7104

Universal Swivelling Head for Versatility

The Rambaudi Versamill comes equipped with a universal swivelling head, allowing you to set up both horizontal and angled machining operations with ease. This flexibility maximizes the machine's utility in complex milling tasks, particularly in industrial and metalworking environments where adaptability is crucial.

Precision Slideways and Robust Structure

Engineered with precision-hardened, ground slideways and a cast iron body, the Versamill ensures both accuracy and longevity. Its robust construction supports a table load of up to 700 kg, minimizing vibration and maintaining stability during demanding medium to heavy-duty milling operations.

Centralized Lubrication and Coolant Systems

The centralized lubricating system and fitted coolant system keep the Versamill's moving parts optimally maintained. These features reduce wear, increase tooling life, and improve overall milling efficiency, making the machine suitable for long, continuous industrial use.

FAQ's of Rambaudi Versamill Bed Type Milling Machine:

Q: How does the Rambaudi Versamill Milling Machine operate for heavy-duty milling?

A: The Rambaudi Versamill uses manual lever and handwheel controls for precise movements and adjustments. Its mechanical feed rates, robust cast iron construction, and universal swivelling head make it suitable for heavy-duty industrial applications, delivering stable and reliable machining results.

Q: What materials and workpieces can the Versamill handle?

A: The Versamill is designed for industrial metalworking and can mill a variety of medium to heavy-duty metal workpieces, thanks to its 700 kg table load capacity. Its hardened slideways and robust build ensure consistent performance on cast iron, steel, and other metals.

Q: When should the centralized lubrication system be checked or refilled?

A: It is recommended to check the centralized lubrication system before each work shift or according to your facility's maintenance schedule. Keeping the system properly filled and functioning helps reduce component wear and ensures smooth operation.

Q: Where can the Versamill be installed within an industrial workspace?

A: This milling machine requires a floor space of approximately 2200 x 2000 mm. It should be placed on a solid, level surface in a well-ventilated workshop to ensure safe operation and easy access to maintenance points.

Q: What process is used to adjust spindle speed on this bed type milling machine?

A: Spindle speed adjustment is carried out mechanically by selecting the appropriate speed setting. The spindle operates in both directions, ranging from 30 to 1800 rpm, allowing the user to match speed to the material and milling operation.

Q: How is the coolant system utilized during operation?

A: The fitted coolant system is used to keep the workpiece and tooling at optimal temperature during milling, preventing overheating, improving finish quality, and extending tool life. Operators should ensure the system is filled and operational before beginning work.

Q: What are the main benefits of choosing a Rambaudi Versamill for industrial applications?

A: Key benefits include robust structural integrity, high table load capacity, versatile machining with a universal head, precise slideways, low industrial noise levels, and reliable manual controls, making the Versamill ideal for demanding metalworking operations.
