Picco Italy Horizontal Slot Milling Machine

Name: Picco Italy Horizontal Slot Milling Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Picco Italy Horizontal Slot Milling Machine Specification

Model
Picco Italy HSM-225

Rotation
Horizontal

Product Type
Horizontal Slot Milling Machine

General Use
Precision horizontal slot milling operations

Material
Heavy duty cast iron

Type
Slotting machine

Capacity
Precision slots up to 12 mm width

Weight (kg)
1200 kg

Computerized
No

Automatic
No

CNC Or Not
Not CNC

Control System
Manual

Table Size
225 mm x 620 mm

Table Slide Way
Double V and flat

Magnetic Chuck Size
200 mm x 400 mm

Grinding Wheel Size
200 mm

Grinding Wheel Speed
2800 rpm

Grinding Length
400 mm

Floor Space
1750 mm x 1200 mm x 1650 mm

Fuel Tank Capacity
30 litres

Spindle Speed
1400 rpm

Power
2 HP

Voltage
415 V

Dimension (L*W*H)
1750 mm x 1200 mm x 1650 mm

Feature
Long operational life, robust design

Color
Blue & white

Working Speed
Variable (manual) adjustment

Machine Accuracy
±0.02 mm

Lubrication
Automatic lubrication system

Table Traverse (Longitudinal)
400 mm

Noise Level
<75 dB

Operation Mode
Hand-operated

Maximum Slot Depth
60 mm

Table Traverse (Cross)
180 mm

Chuck Type
Magnetic

Coolant System
Integrated

Picco Italy Horizontal Slot Milling Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Picco Italy Horizontal Slot Milling Machine

Make - Picco (Italy)

Model - FC-18

Max. Width of Slot - 18 mm

Max. Length of Slot - 200 mm + Tool Diameter

Max. Length of Slot by using Table Travel - 800 mm

Table Size - 1010 mm x 230 mm

XYZ Travel of Travel - 600 mm x 190 mm x 300 mm

Spindle Speeds - 290 rpm to 2250 rpm

Spindle Taper - MT 3

Rate of Automatic Depth - 0.05 mm/stroke to 0.50 mm/stroke

Head Travel Speeds - 3 strokes/minute to 22 strokes/minute

- Complete with Vice, Coolant Pump and other accessories.

- Very Suitable for Milling of Keyways, Slots, Notches, Groves, etc.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/dHpwf6SvQZI

Precision Slot Milling Excellence

Engineered for horizontal slot milling operations, the Picco Italy HSM-225 achieves accurate results with its sturdy double V and flat table slide way. Offering an adjustable working speed, it accommodates diverse slotting requirements while maintaining tight tolerances and reduced noise. Its heavy-duty design and automatic lubrication contribute to extended operational life and consistent output quality.

User-Friendly and Efficient Design

The machine features a magnetic chuck for secure hold of workpieces, and the working table's generous traverse ensures adaptability across various applications. Integrated coolant and automatic lubrication minimize downtime, promoting smooth milling processes. With manual controls, operators retain full command during slot creation, making it suitable for jobs demanding precision and reliability.

FAQ's of Picco Italy Horizontal Slot Milling Machine:

Q: How does the Picco Italy HSM-225 Horizontal Slot Milling Machine maintain slotting accuracy?

A: The machine delivers precision slotting with an accuracy of 0.02 mm, supported by its rigid cast iron construction, stable double V and flat slide ways, and consistent spindle speed. Automatic lubrication further ensures smooth, wear-free movement and optimal performance.

Q: What are the benefits of the integrated coolant and lubrication systems in this milling machine?

A: Integrated coolant ensures temperature stability during extended slotting sessions, reducing thermal stresses on components. The automatic lubrication system minimizes friction and wear, extending machine life and maintaining machining accuracy over time.

Q: When should the magnetic chuck be utilized in the slotting process?

A: Use the magnetic chuck when working with ferrous materials or precision components requiring secure positioning. It reliably holds the workpiece in place, preventing slippage during longitudinal and cross traverses and aiding in consistent results.

Q: Where can this horizontal slot milling machine be effectively operated or installed?

A: Suited for manufacturing workshops, tool rooms, and milling centers, the machine requires a floor space of 1750 mm x 1200 mm x 1650 mm. Its sturdy build and safety features make it adaptable across facilities engaged in precision slotting or grinding.

Q: What is the process for manual speed adjustment during slot milling operations?

A: The working speed is manually set by the operator, allowing tailored adjustments to suit the material type, desired slot width, and depth. This flexibility enhances control and ensures optimal results for various machining requirements.

Q: How does the Picco Italy HSM-225 ensure long operational life and robust performance?

A: Its heavy-duty cast iron construction, automatic lubrication, integrated coolant system, and durable table slide way design contribute to sustained reliable performance, reduced maintenance needs, and fewer operational interruptions.
