FIL Universal Bed Milling Machine

Get a Price/Quote

MOQ : 1 Piece

FIL Universal Bed Milling Machine Specification

Model
FIL Universal Bed Milling Machine

Rotation
360-degree table rotation

Product Type
Universal Bed Milling Machine

General Use
Industrial milling and machining operations

Material
Cast Iron & Alloy Steel

Type
Bed Type Universal Milling

Capacity
Heavy Duty

Weight (kg)
Approx. 2400 kg

Computerized
No

Automatic
No

CNC Or Not
No

Control System
Manual

Table Size
300 x 1000 mm

Table Slide Way
Hardened & ground

Magnetic Chuck Size
300 x 1000 mm

Grinding Wheel Size
250 x 25 x 76.2 mm

Grinding Wheel Speed
1450 RPM

Grinding Length
1000 mm

Floor Space
2200 x 1800 x 1800 mm

Fuel Tank Capacity
70 Liters

Spindle Speed
Variable (up to 2000 RPM)

Power
3 HP

Voltage
415 V

Dimension (L*W*H)
2200 x 1800 x 1800 mm

Feature
High precision, robust construction, easy operation

Color
Industrial Blue & White

Distance from Spindle Nose to Table
125-575 mm

Quill Travel
125 mm

Number of T-Slots
3

Coolant System
Built-in, electric pump

T-Slot Size
16 mm

Vertical Travel
450 mm

Table Feed
Manual/mechanical, variable

Lubrication System
Automatic centralized lubrication

Paint Finish
Epoxy powder coated

Table Longitudinal Travel
1050 mm

Table Cross Travel
340 mm

Main Motor
3 HP, 3-Phase

Spindle Drive
Geared head

Max. Table Load
300 kg

Spindle Taper
ISO 40

About FIL Universal Bed Milling Machine

FIL Universal Bed Milling Machine

Make - FIL (Italy)
Table Size - 1625 mm x 490 mm
X Travel - 1250 mm
Y Travel - 650 mm
Z Travel - 700 mm
Vertical Spindle Speeds - 24 rpm to 1600 rpm
Horizontal Spindle Speeds - 25 rpm to 1200 rpm
Table Feed Rates - 5 mm/min to 1000 mm/min
Spindle Tapers - ISO 50
Table is rotating table type.
Machine is equipped with 3-Axis DRO.
Horizontal & Vertical Spindles can be used simultaneously.
Equipped with Coolant pump etc.
Machine is in excellent working condition.

Heavy-Duty Precision Engineering

Crafted for industrial use, the FIL Universal Bed Milling Machine comes with robust construction and a cast iron and alloy steel body. The 3 HP main motor and 360-degree table rotation elevate the machines capacity, making it ideal for handling complex milling and grinding operations that demand both strength and accuracy.

Advanced Features for Enhanced Productivity

Equipped with a variable speed geared spindle, automatic lubrication, manual/mechanical feed options, and a built-in coolant system, this mill is designed to maximize workflow efficiency. Its ISO 40 taper and sizable 16 mm T-slots allow compatibility with a variety of tooling, boosting its operational versatility on the shop floor.

Easy Operation and Maintenance

This milling machine blends straightforward manual control with automated lubrication, ensuring low maintenance needs. The ergonomic table height, epoxy powder-coated finish, and centralized controls make setup, operation, and adjustments user-friendly, securing productivity gains over long-term industrial usage.

FAQs of FIL Universal Bed Milling Machine:

Q: How do I operate the FIL Universal Bed Milling Machine for optimal results?

A: To achieve optimal results, familiarize yourself with manual controls and adjust spindle speeds according to your workpiece material. Use the mechanical or manual table feed as needed and ensure the coolant and lubrication systems are functioning before starting operations for sustained accuracy and reliability.

Q: What are the primary benefits of using this machine in industrial applications?

A: The main advantages include heavy-duty capacity (up to 300 kg), high precision due to robust construction and ground slide ways, flexible milling/grinding through multi-degree table rotation, and efficient workflow features like an integrated coolant system and centralized lubrication.

Q: When should the automatic lubrication system be checked or maintained?

A: Inspect the automatic centralized lubrication system weekly or according to your companys maintenance schedule to verify it is delivering oil to all key components. Regular checks prevent excessive wear and ensure smooth machine operation.

Q: Where is the FIL Universal Bed Milling Machine ideally used?

A: This machine is suited for industrial environments such as manufacturing plants, fabrication workshops, and machining centers where high precision, versatility, and reliability are required for milling and grinding large or heavy components.

Q: What is involved in the process of changing the spindle speed?

A: The geared head spindle allows for variable speed adjustment up to 2000 RPM. Select the desired speed manually at the control panel, referencing the recommended settings for the material you are processing to ensure efficient milling or grinding.

Q: How does the built-in coolant and lubrication system improve machine usage?

A: The built-in electric pump coolant system and automatic centralized lubrication minimize heat buildup, reduce friction, and extend tool life, thus maximizing productivity and reducing downtime for maintenance or tool replacement.

Q: What safety precautions should be observed when using this machine?

A: Always ensure the workpiece is securely clamped on the magnetic chuck, verify guards and covers are in place, and wear appropriate PPE. Check that the coolant and lubrication systems are operational before use, and never operate the machine without proper training.
