G. Dufour 61 Universal Milling Machine

Price 21000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

G. Dufour 61 Universal Milling Machine Specification

Model
G. Dufour 61

Rotation
360 table rotation

Product Type
Universal Milling Machine

General Use
Precision metal milling operations

Material
Cast Iron & Steel

Type
Horizontal & Vertical Universal

Capacity
Heavy Duty

Weight (kg)
2250 kg approx.

Computerized
No

Automatic
No

CNC Or Not
No

Control System
Manual

Table Size
1300 x 300 mm

Table Slide Way
Dovetail

Floor Space
2000 x 1960 mm approx.

Spindle Speed
402000 rpm (variable)

Power
5 HP

Voltage
415 V

Dimension (L*W*H)
2000 x 1960 x 1780 mm approx.

Feature
Swiveling table, feed auto, high precision

Color
Industrial Grey & Green

Spindle Taper
ISO 40

Max Distance Spindle Center to Column
355 mm

Coolant Pump Motor
0.15 kW

Longitudinal Travel
900 mm

Cross Travel
300 mm

Number of T-slots
3

T-slot Size
16 mm

Condition
Used/Good Working

Feed Motor
1 HP

Quill Movement
120 mm

Working Speed
Variable

Table Feed
15 Speed - 22 to 450 mm/min

Max Distance Spindle Nose to Table
470 mm

Vertical Travel
420 mm

Main Motor
3.7 kW

Overarm Diameter
105 mm

G. Dufour 61 Universal Milling Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About G. Dufour 61 Universal Milling Machine

Make - G. Dufour (France)

Model - 61

Table Size - 1100 mm x 275 mm

XYZ Travels - 700 mm x 250 mm x 500 mm

Spindle Speeds - 21 rpm to 1600 rpm

Spindle Taper - ISO 40

Table Feed Rates - 10 mm/min to 375 mm/min

- With Bracket (Arbour Support) for Horizontal Milling.

- Equipped with 3-Axis DRO and a foot-operated brake.

- Double Swivel type Vertical Milling Head.

- Rotating type Table.

- Operating Manual of the Machine is available.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/pQBMriUmwRw

Durability and Construction

Manufactured from sturdy cast iron and steel, the G. Dufour 61 offers excellent longevity and resilience for continuous operation. Its 2250 kg weight and solid build assure minimal vibrations and precise results during heavy-duty milling work.

Versatile Milling Capabilities

This universal milling machine supports both horizontal and vertical milling, thanks to its swiveling table and 360 table rotation. Adjustable spindle speeds from 40 to 2000 rpm and a spacious table accommodate a diverse array of milling processes for intricate and large-scale components.

Operator Control and Precision

The G. Dufour 61 runs with a manual control system, making it intuitive for seasoned machinists. Auto feed options, high-precision dovetail ways, and variable working speed together ensure remarkable accuracy and repeatable performance in every operation.

FAQs of G. Dufour 61 Universal Milling Machine:

Q: How is the G. Dufour 61 Universal Milling Machine typically used in industrial applications?

A: The machine is mainly utilized for precision metal milling, including shaping, slotting, drilling, and cutting operations on medium to large workpieces, due to its universal design and robust build.

Q: What are the key benefits of the swiveling and 360 rotating table?

A: The swiveling and fully rotatable table allows for easier positioning of workpieces, enabling complex angle milling, multi-face machining, and facilitating more efficient setups for diverse tasks.

Q: Where can this milling machine be installed, considering its dimensions and weight?

A: With dimensions approximately 2000 x 1960 x 1780 mm and a weight of 2250 kg, the machine is best suited for spacious workshops or industrial settings with reinforced flooring capable of supporting heavy equipment.

Q: What is the process for adjusting the spindle speed and table feed rates?

A: Operators can adjust spindle speeds between 40 and 2000 rpm using the variable speed controls, while the table feed offers 15 selectable speeds ranging from 22 to 450 mm/min, allowing precise control over milling operations.

Q: When should regular maintenance be performed on the G. Dufour 61?

A: Routine maintenancesuch as lubricating moving parts, inspecting the dovetail ways, checking the coolant pump, and ensuring the feed mechanisms functionshould occur as recommended in the manual or after every 100 hours of operation.

Q: What materials can be processed with this universal milling machine?

A: It can effectively mill a variety of metalsincluding steel, cast iron, and alloysthanks to its powerful 5 HP motor and sturdy construction, making it suitable for both light and heavy-duty tasks.

Q: How does the manual control system benefit the operator?

A: Manual controls offer experienced machinists direct command over milling settings, fostering maximum adaptability and real-time adjustments for high-precision, custom work not easily attainable with automatic or CNC controls.
