Vernier 3A Universal Milling Machine

Name: Vernier 3A Universal Milling Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Vernier 3A Universal Milling Machine Specification

Model
Vernier 3A

Rotation
Reversible motor/Spindle both directions

Product Type
Universal Milling Machine

General Use
Industrial metalworking and machining

Material
Cast Iron & Alloy Steel

Type
Horizontal & Vertical Milling

Capacity
Heavy Duty, 300-500 Kg material

Weight (kg)
Approx. 1800 kg

Computerized
No

Automatic
No

CNC Or Not
Not CNC

Control System
Manual

Table Size
1250 mm x 250 mm

Table Slide Way
Precision ground and hardened

Floor Space
1800 mm x 1700 mm

Spindle Speed
40 2000 RPM (12/18 steps)

Power
3 HP (2.2 kW)

Voltage
415 V, 3 Phase

Dimension (L*W*H)
Approx. 1800 x 1700 x 1600 mm

Feature
Universal swivelling table, geared feeds, robust construction

Color
Industrial grey/green

Spindle Taper
ISO 40

T-Slot Size & Number
14 mm width, 3 slots

Vertical Travel (Z-Axis)
400 mm

Swivelling Universal Table
±45 degrees both axes

Cross Travel (Y-Axis)
300 mm

Longitudinal Travel (X-Axis)
900 mm

Lubrication System
Manual lubrication pump

Main Motor RPM
1440 RPM

Overarm Diameter
105 mm

Max Distance Spindle to Table
430 mm

Arbor Support
Yes, adjustable

Coolant System
Fitted with pump and tank

Vernier 3A Universal Milling Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Vernier 3A Universal Milling Machine

Make - Vernier (France)

Model - 3A - FV-300E

Table Size - 1200 mm x 300 mm

XYZ Travels - 900 mm x 300 mm x 475 mm

Spindle Taper - ISO 40

Spindle Speeds - 38 rpm to 2000 rpm

Feed Rates of Travel - 6.3 mm/min to 800 mm/min

- With Bracket for Horizontal Milling operations.

- With a Double-Swivel type Vertical Milling Head.

- Equipped with a Heidenhain make 3-Axis DRO.

- Machine is in excellent working condition.

Video of the machine -

https://youtu.be/uUvF8E6X5PI

Heavy-Duty Milling for Industrial Applications

Built with cast iron and alloy steel, the Vernier 3A offers industrial-grade strength and stability. The precision-ground slideways and 3 HP motor make it suitable for continuous and intensive machining operations. Its heavy-duty capacity enables efficient handling of large components and high-volume batches within industrial metalworking environments.

Universal Swivelling Table and Flexible Operation

The machine's universal swivelling table allows adjustment up to 45 degrees on both axes, supporting a wide range of milling functions. Its dual horizontal and vertical operation, combined with reversible spindle rotation and multiple spindle speeds, delivers flexibility for diverse machining requirements, from simple slots to complex geometries.

Manual Control and Easy Maintenance

Operated manually, the Vernier 3A is easy to set up and control, making it ideal for skilled machinists who require tactile operation. The built-in coolant system with pump and tank, along with a manual lubrication pump, ensures smooth functioning and prolongs machine life, while straightforward maintenance supports reliable long-term performance.

FAQ's of Vernier 3A Universal Milling Machine:

Q: How is the Vernier 3A Universal Milling Machine typically used in industrial settings?

A: This milling machine is designed for heavy-duty metalworking tasks, including both horizontal and vertical milling. Users rely on its precise table movements, swiveling table, and robust construction for cutting, shaping, slotting, and finishing complex parts in manufacturing facilities and workshops.

Q: What benefits does the universal swivelling table offer for machining operations?

A: The universal swivelling table allows adjustments of up to 45 degrees in both axes, enabling versatile positioning of workpieces. This flexibility makes it easier to create angled holes, slots, and intricate shapes, improving productivity and extending the range of machining capabilities.

Q: What materials can the Vernier 3A handle, and what is its load capacity?

A: Constructed with cast iron and alloy steel, the Vernier 3A can process a wide variety of metals including steel, aluminum, and cast iron, supporting heavy components with a material capacity ranging from 300 to 500 kilograms.

Q: How is lubrication managed on this milling machine?

A: The Vernier 3A features a manual lubrication pump system. Operators periodically use this pump to apply lubricant to critical moving parts and slideways, ensuring smooth operation and reducing wear for extended machine life.

Q: When would manual control be preferable over CNC for this milling machine?

A: Manual control is ideal for experienced machinists who need tactile feedback and hands-on adjustments, especially when working with unique or prototype parts. It provides direct oversight of machining processes and is beneficial for custom jobs that require flexible setups.

Q: Where is the Vernier 3A primarily manufactured and available?

A: The Vernier 3A is manufactured in France and available worldwide through authorized exporters, importers, manufacturers, suppliers, and traders. It's particularly popular in industrial workshops needing durable and flexible milling solutions.

Q: What process is involved in adjusting the spindle speed or table positioning?

A: Operators can select from 12 to 18 spindle speed steps ranging from 40 to 2000 RPM via geared feeds. Table movement adjustments for longitudinal, cross, and vertical travel are performed manually using handwheels and control levers, achieving precise placements for the workpiece.
