Tiger FU-140 Heavy-Duty Universal Milling Machine
Tiger FU-140 Heavy-Duty Universal Milling Machine

Tiger FU-140 Heavy-Duty Universal Milling Machine

Price 100000 INR/ Piece

MOQ : 1 Piece

Tiger FU-140 Heavy-Duty Universal Milling Machine Specification

  • Model
  • FU-140
  • Rotation
  • Universal (Swiveling head available)
  • Product Type
  • Universal Milling Machine
  • General Use
  • Heavy-duty milling operations
  • Material
  • Cast Iron
  • Type
  • Horizontal / Universal
  • Capacity
  • Up to 200 mm
  • Weight (kg)
  • 1850 kg
  • Computerized
  • No
  • Automatic
  • Semi-Automatic (manual feed with power support)
  • CNC Or Not
  • Not CNC
  • Control System
  • Manual
  • Table Size
  • 1400 x 320 mm
  • Table Slide Way
  • Box type
  • Floor Space
  • 2000 x 1700 mm
  • Spindle Speed
  • 40 - 1300 RPM (12 steps)
  • Power
  • 3 HP
  • Voltage
  • 415 V
  • Dimension (L*W*H)
  • 2000 x 1700 x 1700 mm
  • Feature
  • Heavy-Duty, High Precision, Box Table
  • Color
  • Standard (variable by batch, typical: Grey/Blue)
  • Machine Condition
  • New
  • Coolant Pump
  • Yes
  • Vertical Table Travel
  • 400 mm
  • Lubrication
  • Centralized automatic lubrication
  • T Slot Size
  • 14 mm
  • Longitudinal Table Travel
  • 900 mm
  • Spindle Bore
  • 32 mm
  • Working Speed
  • Stepless (geared head)
  • Feed Motor
  • 0.75 HP
  • Main Motor
  • 3 HP (2.2 kW)
  • Cross Table Travel
  • 300 mm
  • Number of T Slots
  • 3


Tiger FU-140 Heavy-Duty Universal Milling Machine Trade Information

  • Minimum Order Quantity
  • 1 Piece
  • Main Domestic Market
  • All India


About Tiger FU-140 Heavy-Duty Universal Milling Machine

Make - Tiger (Italy)

Model - FU-140

Table Size - 1500 mm x 340 mm

XYZ Travels - 1150 mm x 300 mm x 470 mm

Spindle Speeds - 25 rpm to 1400 rpm

Spindle Taper - ISO 50

Feed Rates of Travels - 8 mm/min to 1030 mm/min

Spindle Motor - 15 HP

- Equipped with 3-Axis DRO.

- With Infinitely Variable Feed Rates of Travels.

- Complete with many Cutters and Tool Holders.

- Rotating Type Universal Table.

- Vertical Head can be removed to do Horizontal Milling.

- Machine is in excellent working condition.


Video of The Machine -

https://youtu.be/jEdL5Sv1q38



Versatile Heavy-Duty Milling

The Tiger FU-140 is engineered for heavy-duty industrial applications. Its universal, swiveling head, strong frame, and large table capacity enable the precise milling of complex and sizable components. The sturdy cast iron build and high-precision box-type table slideways provide stability and long-term durability, supporting extended production runs.


Precision and Control

Operators benefit from the FU-140's manual control system and stepless geared head. With 12 spindle speed steps (40-1300 RPM) and a high-capacity 3 HP motor, machinists can dial in the optimal speed for every material and operation. Automatic lubrication ensures smooth movements, reducing wear and increasing the machine's service life.


Designed for Operator Efficiency

The FU-140 combines semi-automatic features with manual finesse, making it accessible yet powerful for skilled users. Power support for feeds, a reliable coolant pump, and centralized lubrication allow for longer machining cycles and less downtime, boosting overall productivity in busy workshop environments.

FAQ's of Tiger FU-140 Heavy-Duty Universal Milling Machine:


Q: How is the Tiger FU-140 milling machine operated and controlled?

A: The Tiger FU-140 is designed with a manual control system, meaning operators manually manage axis feeds and machining operations. However, power support is available for some feed movements, blending manual precision with efficiency.

Q: What types of milling operations can this machine perform?

A: This machine is suitable for a wide range of heavy-duty milling operations, including face milling, slotting, drilling, and contouring. Its universal head allows for horizontal and angular cuts, making it versatile for complex engineering applications.

Q: When should I use the FU-140's stepless speed feature?

A: The stepless (geared head) spindle speed feature allows you to adjust the spindle speed across 12 steps, ranging from 40 to 1300 RPM. Use lower speeds for tough materials or large-diameter cutters, and higher speeds for lighter cuts and smaller tools to ensure optimal machining results.

Q: Where is this machine most effectively utilized?

A: The Tiger FU-140 is ideal for job shops, manufacturing plants, and tool rooms engaged in heavy-duty and precision milling work. Its performance is especially beneficial where large, heavy components require precise, repeatable operations.

Q: What is the process for maintaining the FU-140?

A: The machine is equipped with centralized automatic lubrication, which ensures all moving parts receive consistent lubrication during operation. Routine checks of the system, as well as general cleanliness and coolant level monitoring, are recommended to maintain peak performance.

Q: How does the machine benefit my operation compared to CNC alternatives?

A: While not CNC, the FU-140 offers high reliability and precision for users who prefer manual control with semi-automatic support. It's a cost-effective solution for shops needing flexibility, hands-on machining, and easy setup changes without complex programming.
