G. Dufour 1100 mm x 250 mm Universal Milling Machine

Send Inquiry

Request To Call Back

G. Dufour 1100 mm x 250 mm Universal Milling Machine

Price 70000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

G. Dufour 1100 mm x 250 mm Universal Milling Machine Specification

Rotation
Reversible Spindle Rotation

Model
G. Dufour 1100 x 250

Product Type
Universal Milling Machine

General Use
Milling, Drilling, Boring & Universal Machining

Material
Cast Iron

Type
Horizontal / Universal

Capacity
Medium Duty

Weight (kg)
Approx. 1700 kg

Computerized
No

Automatic
No

CNC Or Not
Conventional (Non-CNC)

Control System
Manual

Table Size
1100 mm x 250 mm

Table Slide Way
Dovetail

Floor Space
Approx. 1700 mm x 1750 mm

WorkingSpeed
Variable, as per spindle speed selection

Spindle Speed
18 Speeds, 40 2000 RPM

Power
3 HP

Voltage
415 V, 3 Phase

Dimension (L*W*H)
Approx. 1700 mm x 1750 mm x 1700 mm

Feature
Heavy Duty, Precision Table, Hardened Guideways

Color
Machine Grey / Green

Maximum Longitudinal Travel of Table
800 mm

Main Motor Type
Induction (TEFC)

Table Swivel (Horizontal)
45

Arbor Diameter
25 mm

Safety Features
Electrical interlock, Overload protection

Lubrication System
Centralized automatic

Maximum Cross Travel of Table
250 mm

Vertical Travel of Table
400 mm

T-Slots on Table
3 slots, 14 mm width

Overarm Diameter
110 mm

Feed Range (X, Y, Z)
10 - 500 mm/min

Coolant System
Provided

Accessories Included
Standard Arbor, Draw Bar, Wrenches, Oil Gun

G. Dufour 1100 mm x 250 mm Universal Milling Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About G. Dufour 1100 mm x 250 mm Universal Milling Machine

Make - G. Dufour (France)

Model - 53

Table Size - 1100 mm x 250 mm

XYZ Travels - 690 mm x 250 mm x 400 mm

Spindle Speeds - 21 rpm to 1600 rpm

Spindle Taper - ISO 40

Table Feed Rates - 10 mm/min to 375 mm/min

- With Bracket (Arbour Support) for Horizontal Milling.

- Equipped with 3-Axis DRO.

- Double Swivel type Vertical Milling Head.

- Rotating type Table.

- Machine is in excellent working condition.

Video of the Machine -

https://youtu.be/88os2yCvk18

High-Precision Universal Milling Capabilities

The G. Dufour Milling Machine excels in medium-duty milling, drilling, and boring. With its reversible spindle, variable speeds, and 45 table swivel, it adapts to a multitude of machining tasks. Precision is guaranteed with hardened guideways and a heavy-duty construction, while the dovetail table slide way ensures consistent accuracy.

Built for Efficiency and Operator Safety

Fitted with a centralized automatic lubrication system and a dedicated coolant system, the G. Dufour 1100 x 250 is designed to minimize maintenance requirements and maximize uptime. Comprehensive safety features, including electrical interlock and overload protection, make it suitable for workshop or industrial use.

Versatile Workspace and Accessories

Offering a generous table size with ample travel range, this machine can handle a wide variety of part dimensions. Standard accessories like arbors, draw bar, wrenches, and oil gun allow for immediate setup. The machine occupies a balanced floor space relative to its capacity, allowing placement in assorted manufacturing settings.

FAQs of G. Dufour 1100 mm x 250 mm Universal Milling Machine:

Q: How does the G. Dufour 1100 x 250 Universal Milling Machine enhance operational control during machining?

A: Thanks to its manual control system, precise dovetail slide ways, and 18 changeable spindle speeds (402000 RPM), operators can delicately adjust parameters for various materials and job requirements, ensuring accuracy and versatility in each application.

Q: What are the safety mechanisms included with this universal milling machine?

A: The machine is equipped with electrical interlock systems and overload protection, both of which help prevent unintentional startups and protect against excess mechanical strain, making operator safety a priority.

Q: When should you select a universal (non-CNC) milling machine like this model?

A: A universal manual milling machine is ideal when your operations require flexibility, hands-on adjustments, and the ability to switch between milling, drilling, and boring on medium-duty workpieces without complex CNC programming.

Q: Where can this milling machine be effectively utilized?

A: It fits well in industrial workshops, toolrooms, repair shops, educational institutes, or manufacturing units that need reliable, flexible milling for medium-sized components, thanks to its balanced footprint and robust build.

Q: What process steps are supported by the G. Dufour 1100 x 250 Universal Milling Machine?

A: The machine accommodates a range of processes, including face milling, slotting, drilling, boring, and angular machining with its reversible spindle and horizontal/vertical table swivel adjustments. Its T-slots and accessory package enable easy workpiece mounting and tool changes.

Q: How do the lubrication and coolant systems benefit machine performance?

A: Centralized automatic lubrication reduces wear on moving parts, ensuring smooth movement and extended service life, while the integrated coolant system helps maintain workpiece and tool temperatures for consistent high-precision results.

Q: What accessories and features optimize setup and usage?

A: Included accessories such as the standard arbor, draw bar, and wrenches make switching operations straightforward. Hardened guideways and a precision table further enable stability and accuracy throughout machining cycles.
