TOS FA4AV Pure Vertical Milling machine

Name: TOS FA4AV Pure Vertical Milling machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

TOS FA4AV Pure Vertical Milling machine Specification

Model
TOS FA4AV

Rotation
Spindle - Vertical

Product Type
Pure Vertical Milling Machine

General Use
Industrial Vertical Milling Operations

Material
Cast Iron & Steel

Type
Milling Machine

Capacity
Industrial Duty

Weight (kg)
Approx. 3600 kg

Computerized
No

Automatic
No, Manual

CNC Or Not
Not CNC

Control System
Manual

Table Size
1600 x 400 mm

Table Slide Way
Box Type

Floor Space
2400 x 2500 mm

Spindle Speed
28 - 1400 RPM (16 Steps)

Power
7.5 kW

Voltage
380 V

Dimension (L*W*H)
2500 x 2400 x 2300 mm

Feature
Rigid Construction, Precision Milling, Adjustable Table, Hardened & Ground Slideways

Color
Light Grey & Blue

Max. Distance Spindle Nose to Table
470 mm

Coolant System
Provided

Working Speed
Varies per Operation (Feed: 8-800 mm/min)

T-Slot Number & Size
3 Slots, 14 mm

Lubrication System
Centralized

Spindle Taper
ISO 50

Main Motor
7.5 kW (10 HP)

Longitudinal Travel (X-Axis)
1120 mm

Table Feed (Longitudinal/Cross)
8-800 mm/min

Rapid Traverse Rate
2000 mm/min

Cross Travel (Y-Axis)
400 mm

Vertical Travel (Z-Axis)
420 mm

TOS FA4AV Pure Vertical Milling machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

TOS FA4AV Pure Vertical Milling machine About

Make - TOS (Czech Republic)

Model - FA4A-V

Table Size - 1600 mm x 350 mm

XYZ Travels - 1000 mm x 350 mm x 425 mm

Spindle Taper - ISO 50

Spindle Speeds - 32 rpm to 1400 rpm

Table Feed Rates - 10 mm/min to 1250 mm/min

Max. Height between Table to Spindle - 550 mm

Spindle Motor - 7.5 kW

Vertical Head Rotation - +45 degree to -45 degree

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/fvoSXhRcWh0

Precision and Capacity

The TOS FA4AV stands out for its precision engineering and substantial industrial capacity, with hardened and ground slideways that ensure consistent accuracy. The adjustable table supports complex operations, while its box-type slideway structure reinforces stability. This combination of rigid construction and advanced features makes it suitable for high-demand milling projects.

Flexible Operation and User-Friendly Controls

Operated manually, the FA4AV lets users fine-tune feeds and speeds for various materials and cutting tasks. With a rapid traverse rate of 2000 mm/min and selectable spindle speeds, operators have the control to optimize for each job. Its centralized lubrication and integrated coolant system simplify maintenance, promoting long-term reliability.

FAQ's of TOS FA4AV Pure Vertical Milling machine:

Q: How can I adjust the feed rate on the TOS FA4AV milling machine?

A: You can adjust the feed rate using the manual control system. The table feed (longitudinal or cross) ranges from 8 mm/min to 800 mm/min, allowing for precise control based on your desired cutting operation and material.

Q: What types of industrial applications is the TOS FA4AV milling machine designed for?

A: This machine is developed primarily for vertical milling operations in industrial settings, including precise shaping, slotting, and surface milling on cast iron, steel, and similar materials. Its robust build supports heavy-duty tasks typically encountered in manufacturing and fabrication.

Q: When should I utilize the coolant system provided with the milling machine?

A: The coolant system should be used during prolonged milling operations or when working with materials that generate substantial heat. Continuous coolant flow helps to prolong tool life, maintain accuracy, and ensure a high-quality surface finish.

Q: Where is the TOS FA4AV manufactured and who supplies it?

A: The TOS FA4AV milling machine is manufactured in the Czech Republic and is available through exporters, importers, manufacturers, suppliers, and traders worldwide.

Q: What is the process for routine maintenance on the FA4AV milling machine?

A: Routine maintenance involves regular inspection of hardened and ground slideways, lubrication via the centralized system, checking the spindle's alignment, and ensuring the coolant system is functioning. These steps help maintain the machine's precision and longevity.

Q: What are the benefits of manual control over CNC on this milling machine?

A: Manual control offers operators direct feedback and flexibility for custom, one-off jobs or adjustments during operation. It's especially beneficial for workshops where experienced machinists make frequent tool or operation changes, prioritizing adaptability over automation.

Q: How does the rigid construction and adjustable table improve milling performance?

A: The rigid construction ensures minimal vibration, while the adjustable table allows precise positioning and support for workpieces. Together, they contribute to higher accuracy, smoother finishes, and consistent milling quality even in demanding industrial environments.
