Ribon RUR 1500 Universal Cylindrical Grinder

Name: Ribon RUR 1500 Universal Cylindrical Grinder
Brand: Liberty Metal & Machines Private Limited
Price: 21000 INR
Availability: InStock

Price 21000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Ribon RUR 1500 Universal Cylindrical Grinder Specification

Product Type
Universal Cylindrical Grinder

General Use
Precision Grinding of External and Internal Cylinders

Material
Cast Iron Body, Hardened Steel Components

Type
Universal

Capacity
1500 mm

Weight (kg)
2700 kg

Computerized
No

Automatic
No

Control System
Manual

Drive Type
Electric Motor Drive

Grinding Diameter
320 mm

Grinding Length
1500 mm

Spindle Speed
501400 RPM

Grinding Wheel Size
350 x 127 x 50 mm

Voltage
415 V, 3 Phase

Dimension (L*W*H)
2700 x 1450 x 1600 mm

Feature
Precision Work, Rigid Bed Construction, Adjustable Table

Color
Green

Coolant System
Included

Frequency
50 Hz

Chuck Size
200 mm

Tailstock Quill Travel
30 mm

Table Swivel
7

Max. Workpiece Weight
350 kg

Internal Grinding Attachment
Available

Wheelhead Motor Power
3.7 kW

Cross Traverse
190 mm

Ribon RUR 1500 Universal Cylindrical Grinder Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Ribon RUR 1500 Universal Cylindrical Grinder

Make - Ribon (Italy)

Model - RUR 1500

Center Height - 160 mm

Max. Job Diameter - 320 mm

Max. Length of Job - 1500 mm

Grinding Wheel Size - Diameter 400 mm x 50 mm Width

Work-Head Speeds - 35 rpm to 310 rpm

Least Count of Wheel-Head - 1 Micron (0.001 mm)

Type - Semi-Hydraulic

- Equipped with Internal Grinding Attachment.

- Equipped with 2-Axis Digital Readout (DRO).

- Features like Hydraulic Rapid Travel of Wheel-Head etc.

- Micro-Feed Adjustments in Wheel-Head Travels.

- Complete with Coolant Tank & Pump.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/JyMNrxHX9x0

Versatile Precision Engineering

The Ribon RUR 1500 is engineered for both internal and external cylindrical grinding, making it suitable for a wide range of applications in tool rooms and production environments. Its universal design and maximal table swivel of 7 enable flexible setup and accommodate complex grinding tasks with efficiency and repeatability.

Rugged Construction, Italian Craftsmanship

Built with a solid cast iron base and hardened steel elements, this machine ensures longevity and minimizes vibration. Italian manufacturing guarantees meticulous attention to detail and high production standards, while the green finish reflects its industrial heritage and durability.

Enhanced Operator Control and Safety

Manual control provides the operator full oversight during grinding operations. Safety and precision are further assured through a rigid bed, stable 3-phase electric motor drive, and integrated coolant system, all contributing to reliable, high-quality results even under demanding workloads.

FAQs of Ribon RUR 1500 Universal Cylindrical Grinder:

Q: How do you operate the Ribon RUR 1500 Universal Cylindrical Grinder?

A: Operation is manual and straightforward. The operator secures the workpiece (up to 350 kg) using the appropriate chuck or fixture, sets up the grinding parameters, adjusts the table swivel as needed (7), and engages the electric motor drive. Supervision during grinding ensures precision and safety, aided by the built-in coolant system.

Q: What types of materials and workpieces can this machine handle?

A: The Ribon RUR 1500 is designed for machining a variety of cylindrical workpieces, both internal and external, primarily using hardened steel and similar robust materials. It accommodates pieces up to 1500 mm long and 320 mm in diameter, making it suitable for shafts, rollers, and bushings.

Q: When should the internal grinding attachment be used?

A: The internal grinding attachment is used when there is a requirement for precise internal diameter operations, such as honing bores or finishing cylindrical holes. It is easy to install as needed for specific jobs, maximizing the grinders versatility.

Q: Where is the Ribon RUR 1500 manufactured, and what sets its build apart?

A: This grinder is manufactured in Italy, adhering to stringent engineering standards. Its cast iron construction and high-grade steel components provide exceptional rigidity, stability, and consistent accuracy, minimizing vibrations and enhancing the finish of precision workpieces.

Q: What is the process for adjusting the table or tailstock during operation?

A: Adjustments can be made manually while the machine is idle. The table can swivel within 7, optimizing orientation relative to the grinding wheel. The tailstock quill allows up to 30 mm of travel for fine-tuning alignment with the workpiece. Secure all settings before commencing grinding to ensure accuracy.

Q: What are the major benefits of choosing the RUR 1500 for your grinding operations?

A: Major benefits include its high precision, durable construction, adaptability to various workpiece sizes, and reliability in continuous use. The manual controls allow for customization and careful oversight, essential for intricate or high-value components. Additionally, the machines integrated coolant and rigid frame contribute to superior surface finishes.
