Schaudt Long Table Internal Grinder

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Schaudt Long Table Internal Grinder Specification

Rotation
Clockwise/Counterclockwise

Model
Schaudt Long Table Internal Grinder

Product Type
Internal Grinder

General Use
Internal grinding of cylindrical and conical surfaces

Material
Cast iron, precision ground

Type
Long Table Internal Grinder

Capacity
Heavy Duty

Weight (kg)
Approx. 6500 kg

Computerized
No

Automatic
No

CNC Or Not
Not CNC

Control System
Manual

Table Size
Long Table

Table Slide Way
Dovetail/Box type

Magnetic Chuck Size
Standard (on request)

Grinding Wheel Size
Approx. 300 mm diameter

Grinding Wheel Speed
Up to 3000 RPM

Grinding Length
1000 mm

Floor Space
Approx. 5200 mm x 1800 mm

Fuel Tank Capacity
Integrated lubrication tank

Spindle Speed
Variable, up to 10000 RPM

Power
7.5 kW

Voltage
415 V

Dimension (L*W*H)
Approx. 5200 x 1800 x 1800 mm

Feature
High precision, long table, robust construction

Color
Industrial Grey

Schaudt Long Table Internal Grinder Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Schaudt Long Table Internal Grinder

Make - Schaudt (Germany)

Center Height - 175 mm

Max. Swing Diameter of Job - 350 mm

Max. Table Travel - 800 mm

Least Count - 1 Micron (0.001 mm)

Internal Grinding Spindle Diameter - 60 mm

Table Rotation - +10 degree to -7 degree

Work-Head Speeds - 19 rpm to 480 rpm

- With Hydraulic Rapid Travel of the Wheel-Head.

- Features like Auto-Cut, Delay, Plunge Grinding etc.

- Complete with 3-point Steady & Coolant Pump.

- Machine is in excellent working condition.

Video of the Machine -

https://youtu.be/qLZeIeVgRfw

Precision Grinding for Demanding Applications

Engineered for heavy-duty tasks, the Schaudt Long Table Internal Grinder offers reliable, repeatable performance for internal grinding operations. Its long table, high workpiece capacity (up to 350 mm diameter), and robust cast structure support precise machining of large components. The machines direct drive and thermal overload protection give peace of mind in continuous operations. Centralized lubrication and an effective coolant system further ensure consistent performance and reduced maintenance downtime.

User-Friendly Manual Operation

Despite its industrial power, this grinder maintains a straightforward, manual control system via a basic analog operator panel. No complicated CNC programming is needed, which allows skilled machinists to quickly adapt to the system and focus on quality work. Adjustable speeds and standard control elements provide flexibility for a variety of internal grinding tasks.

FAQs of Schaudt Long Table Internal Grinder:

Q: How does the automatic recirculation coolant system benefit the grinding process?

A: The automatic recirculation coolant system actively cools both the grinding wheel and the workpiece during operation, minimizing thermal expansion and maintaining high tolerance accuracy. This system also helps extend the life of the grinding wheel and reduces maintenance frequency by keeping grinding debris away from critical components.

Q: What types of workpieces can be handled by this internal grinder?

A: The Schaudt Long Table Internal Grinder is designed for cylindrical and conical surfaces, accommodating workpieces with diameters up to 350 mm and grinding lengths up to 1000 mm. It is ideally suited for heavy-duty industrial applications requiring precision internal grinding.

Q: When should the central lubrication system be maintained?

A: The centralized lubrication system is designed for minimal intervention, but regular checks should be scheduled according to heavy use cycles or manufacturers recommendations. Maintaining adequate lubrication reduces wear and keeps the machine running smoothly, prolonging component life.

Q: Where is the Schaudt Long Table Internal Grinder ideally installed?

A: This machine is best suited for factory environments or workshops handling large precision components. Its substantial floor space requirement (approximately 5200 x 1800 mm) and heavy-duty design make it ideal for industrial settings with adequate space and lifting equipment.

Q: What safety features are integrated into this grinder?

A: Operator safety is prioritized through features like thermal overload relays for motor protection, integrated earth and circuit breakers for electrical safety, and robust mechanical construction. These safeguards help prevent accidents and equipment damage during operation.

Q: How is the machine operated and controlled?

A: The grinder uses a manual control system with a basic analog operator panel. There is no CNC or computerized control, so all adjustments and operations are performed by the machinist using traditional levers, dials, and switches on the panel.
