Schlumberger RF6 Radial Drilling and Tapping Machine

Name: Schlumberger RF6 Radial Drilling and Tapping Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Schlumberger RF6 Radial Drilling and Tapping Machine Specification

Motor Power
1.5 kW

Dimension (L*W*H)
1170 x 720 x 1880 mm

Table Size
500 x 400 mm

Features
Heavy duty, precision machining, adjustable arm, multiple speed settings

Machine Type
Radial Type Drilling/Tapping

Condition
New

Frequency
50 Hz

Noise Level
Low

Spindle Speed
70-2000 RPM (Variable)

Diameter
Max Drilling 50 mm

Cutting Area
Large working envelope

Product Type
Radial Drilling and Tapping Machine

Material
Cast Iron Body, Hardened Steel Components

Computerized
No

Automatic Grade
Semi-Automatic

CNC Or Not
No

Control System
Manual

Voltage
415 V

Power
2 HP

Power Source
Electric

Weight (kg)
950 kg

Capacity
Drilling: 50 mm, Tapping: 30 mm

Color
Green

Usage & Applications
Drilling and tapping in steel, cast iron, non-ferrous metals

Coolant System
Provision Available

Column Diameter
170 mm

Quill Diameter
75 mm

Drilling Head Traverse
800 mm

Clamping Type
Manual Clamping

T-Slot Size
16 mm

Arm Length
1000 mm

Minimum Distance Spindle to Base
350 mm

Number of Spindle Speeds
12 Steps

Max Spindle Travel
250 mm

Maximum Distance Spindle to Base
1350 mm

Schlumberger RF6 Radial Drilling and Tapping Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Schlumberger RF6 Radial Drilling and Tapping Machine

Make - Schlumberger (France)

Model - RF 6

Drilling Capacity - 50 mm

Spindle Diameter - 90 mm

Spindle Speeds - 35 rpm to 1800 rpm

Spindle Taper - MT 4

Spindle Feed Rate - 0.06 mm/min to 0.60 mm/min

Spindle Feed Travel - 355 mm

Max. Height between Spindle to Table Top - 945 mm

Max. Height between Spindle to Base Clamping Table - 1370 mm

Min. Distance between Spindle Center to Pillar - 125 mm

Max. Distance between Spindle Center to Pillar - 900 mm

Table Size - 1000 mm x 710 mm

Base Clamping Table Size (Back-Side) - 920 mm x 640 mm

Vertical Clamping Table Size - 800 mm x 790 mm

Head Rotation - 360 degree

Clamping Type - Automatic ; Hydraulic

- With Automatic Tapping Feature.

- Complete with Vice, Tool Holder, & Coolant Pump.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/bc8ZXLhJho0

Versatile Radial Arm for Flexible Machining

The adjustable 1000 mm arm and 800 mm drilling head traverse of the RF6 radial drilling and tapping machine allow users to process a wide range of workpieces, from small components to larger assemblies. Its robust design enhances productivity in applications including drilling and tapping across various materials such as steel, cast iron, and non-ferrous metals.

Precision Engineering and Heavy-Duty Build

Constructed from a sturdy cast iron base and hardened steel components, the RF6 delivers durability and exceptional stability. Its 75 mm quill diameter, manual clamping, and precise spindle control empower operators to achieve high-accuracy results even during intensive drilling and tapping cycles. The machine's large worktable (500 x 400 mm) accommodates demanding tasks with ease.

Multiple Speed Settings for Optimum Performance

Equipped with twelve spindle speeds ranging from 70 to 2000 RPM, the RF6 enables users to adjust drilling and tapping parameters for optimal tool life and material compatibility. This versatility supports high-quality results in both production shops and maintenance facilities, all while maintaining low noise levels during operation.

FAQ's of Schlumberger RF6 Radial Drilling and Tapping Machine:

Q: How does the Schlumberger RF6 accommodate different workpiece sizes?

A: The RF6 features a 1000 mm radial arm and a drilling head traverse of 800 mm, which allows operators to position the spindle over larger workpieces or reach various drilling and tapping points without repositioning the material, providing flexibility across diverse applications.

Q: What applications is the RF6 radial drilling and tapping machine best suited for?

A: This machine excels in heavy-duty drilling and tapping operations in workshops, manufacturing units, and production lines. It handles steel, cast iron, and non-ferrous metals with ease, making it valuable for industries that require precise, high-capacity machining.

Q: When should I use the variable spindle speed feature?

A: Variable spindle speeds, ranging from 70 to 2000 RPM, should be selected based on the material type and the required drilling or tapping operation. Choosing the right speed improves cutting performance, tool life, and the finish quality of the machined parts.

Q: Where can the Schlumberger RF6 be installed?

A: With its compact footprint (1170 x 720 x 1880 mm) and electric operation at 415 V, the RF6 can be installed in workshops or industrial environments in France and globally. It is suitable for suppliers, manufacturers, exporters, and importers seeking reliable heavy-duty machines.

Q: What is the process for clamping and setting up a workpiece on this machine?

A: The machine uses a manual clamping system, allowing operators to securely fasten the workpiece before adjusting the arm and spindle position. This setup process ensures safety and precision during drilling and tapping operations.

Q: How does the coolant system benefit the machining process?

A: The provision for a coolant system allows operators to maintain appropriate temperatures during drilling and tapping, reducing tool wear, improving surface finish, and increasing overall process efficiency.
