Torgim 3 meter Lathe Machine

Get a Price/Quote

MOQ : 1 Piece

Torgim 3 meter Lathe Machine Specification

Product Type
Heavy Duty Centre Lathe Machine

Material
Cast Iron Body, Hardened Bed Ways

Cutting Thickness
Up to 32 mm

Cutting Speed
Up to 2000 RPM (variable)

CNC Or Not
No (Conventional Lathe)

Automatic Grade
Semi-automatic

Control System
Manual

Max. Swing Diameter
650 mm above bed

Voltage
415 V, 3 phase

Weight (kg)
Approx. 3200 kg

Dimension (L*W*H)
Approx. 4300 mm x 1200 mm x 1450 mm

Capacity
3000 mm (3 meter) between centers

Feature
Robust Construction, Precision Ground Bed, Hardened Gears and Shafts

Color
Industrial Green & Grey

Spindle Bore
80 mm

Power of Main Motor
7.5 HP

Number of Spindle Speeds
12

Distance Between Centers
3000 mm

Type of Drive
Geared Head

Leadscrew Diameter
32 mm

Tailstock Quill Travel
200 mm

Bed Width
400 mm

Chuck Size
315 mm

Reverse Forward Switch
Provided

Coolant System
Included

Threads per Inch
Range 2 - 40 TPI

Application
Turning, Facing, Threading, Drilling, Boring on Metalwork

About Torgim 3 meter Lathe Machine

Make - Torgim (Italy)

Center Height - 370 mm

Length of Job - 3000 mm

Max. Diameter of Job over Bed - 740 mm

Max. Diameter of Job Over Cross-Slide - 500 mm

4-Jaw Chuck Diameter - 550 mm

Bed Width - 415 mm

Spindle Speeds - 23 rpm to 1000 rpm

Spindle Bore - 80 mm

- Complete with reverse jaws, centers, drill chuck, handles etc.

- Bed of the machine is completely scratch-less.

- Machine is in excellent working condition.

Video link- https://youtu.be/Ji0_Wwzw9X0

Engineered for Precision and Durability

Designed with a cast iron body, hardened gears and shafts, and precision-ground bed, this lathe guarantees long-lasting performance and consistent results across demanding metalwork projects. The 7.5 HP motor and 12-speed geared head provide versatility for a wide range of operations.

Versatile Metalworking Capabilities

Suitable for operations such as turning, facing, threading, drilling, and boring, the Torgim 3 Meter Lathe is equipped with an 80 mm spindle bore and a spacious 400 mm bed width, offering flexibility for various metalwork applications up to a cutting thickness of 32 mm.

Enhanced User Safety and Control

A manual, semi-automatic design, this lathe features a reverse-forward switch, efficient coolant system, and easy-to-use controls for operator safety. Its industrial-grade construction ensures stable operation and low vibration during high-speed machining.

FAQs of Torgim 3 meter Lathe Machine:

Q: How does the Torgim 3 meter lathe machine support long and heavy workpieces?

A: With a 3-meter (3000 mm) distance between centers, a 650 mm swing over bed, and a heavy-duty cast iron construction, the Torgim lathe securely accommodates lengthy and substantial metal pieces, enabling precise operations without compromising stability.

Q: What are the primary applications of this lathe machine?

A: The Torgim 3 meter lathe is designed for turning, facing, threading, drilling, and boring on metalwork, making it suitable for workshops, manufacturing units, and metal fabrication environments.

Q: When should I use the variable cutting speed feature?

A: The variable speed (up to 2000 RPM) allows operators to match the optimum speed to different materials and machining processes, enhancing cutting efficiency and producing smoother finishes, especially when dealing with various metals or thread pitches.

Q: Where is the Torgim 3 meter lathe typically installed and used?

A: This lathe is ideal for installation in industrial workshops, manufacturing plants, and technical institutes where robust and accurate metalworking is required for medium to large parts.

Q: What is the process for threading different pitches on this lathe?

A: The lathe features a leadscrew with a diameter of 32 mm and allows for thread cutting across a 240 TPI range. By adjusting the gears and selecting the appropriate leadscrew settings, users can machine multiple thread pitches efficiently.

Q: How does the coolant system contribute to machine operation?

A: The included coolant system helps dissipate heat generated during cutting, extends tool life, and maintains workpiece accuracy by preventing overheating during prolonged machining sessions.
