TOS 2UD 1000 mm Universal Cylindrical Grinder Machine

Name: TOS 2UD 1000 mm Universal Cylindrical Grinder Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

TOS 2UD 1000 mm Universal Cylindrical Grinder Machine Specification

Product Type
Universal Cylindrical Grinder Machine

General Use
Precision external and internal grinding of cylindrical and conical surfaces

Material
Cast Iron (Base and Main Parts)

Type
Manual / Hydraulic

Capacity
1000 mm Between Centers

Weight (kg)
Approx. 3100 kg

Computerized
No

Automatic
Semi-Automatic

Control System
Manual Controls with Hydraulic Operation

Drive Type
Gear / Belt Driven Motor

Grinding Diameter
8 mm to 290 mm

Grinding Length
1000 mm

Spindle Speed
28/50/90/160 RPM (Workhead variable through Pulley)

Grinding Wheel Size
350 mm Diameter x 50 mm Width x 127 mm Bore

Voltage
415 V, 3 Phase, 50 Hz

Dimension (L*W*H)
2800 mm x 1800 mm x 1500 mm (approx.)

Feature
High Precision, Rigid Construction, Universal Workhead Swivelling, Internal & External Grinding

Color
Light Blue / Grey

Cross Feed Travel
285 mm (approx.)

Taper Adjustment
Workhead swivels +/- 90°, Wheelhead swivels 30°

Internal Grinding Spindle Speed
16000 RPM

Main Motor Power
3 kW / 4 HP

Coolant System
Provided, with Pump and Tank

Chuck Size
200 mm (optional accessory)

Table Traverse
1120 mm

Lubrication System
Automatic

Maximum Weight of Job Between Centers
130 kg

Centre Height
145 mm

TOS 2UD 1000 mm Universal Cylindrical Grinder Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

TOS 2UD 1000 mm Universal Cylindrical Grinder Machine About

Make - TOS - Hostivar (Czech Republic)

Model - 2Ud / 1000

Center Height - 150 mm

Max. Diameter of Job - 290 mm

Length of Job - 1000 mm

Grinding Wheel Size - Diameter 350 mm x 50 mm Width

Work-Head Speeds - 38 rpm to 380 rpm

- Equipped with Internal Grinding Attachment.

- Features like Auto-Cut, Plunge Grinding, Delay etc.

- Equipped with Hydraulic Tail-Stock.

- Complete with Job Steady, Dresser, Chuck, Centers etc.

- Complete with Coolant Tank & Pump.

- Operating Manual & Electrical Drawings are available.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/_aEHok207c0

Versatile Grinding Capability

The TOS 2UD 1000 mm Universal Cylindrical Grinder allows users to perform both external and internal grinding, accommodating workpieces of varying shapes and dimensions. The universal swiveling workhead and adjustable wheelhead facilitate precise grinding of conical and cylindrical forms, ensuring adaptability for a wide range of machining tasks.

Robust Construction for Precision

Constructed from premium cast iron, the machine offers outstanding rigidity and vibration dampening, essential for high-precision grinding. This foundation, combined with automatic lubrication, ensures long-term durability and consistent performance, making it suitable for heavy-duty industrial use.

Efficient Operations and User Control

With manual controls paired with hydraulic operations, users benefit from an intuitive interface and smooth table movements. The automatic lubrication system and the integrated coolant system further enhance usability by minimizing maintenance and keeping operational temperatures stable during extended use.

FAQ's of TOS 2UD 1000 mm Universal Cylindrical Grinder Machine:

Q: How can I adjust the TOS 2UD grinder for taper grinding?

A: The TOS 2UD Universal Cylindrical Grinder features a workhead that swivels 90 and a wheelhead that swivels up to 30. To grind tapers, simply adjust the workhead to the desired angle, ensuring precise alignment for the required taper on cylindrical or conical surfaces.

Q: What types of materials can this cylindrical grinder handle?

A: While the machine is designed with a robust cast iron base and components for durability, it is capable of grinding a wide range of metallic materials, particularly various grades of steel and alloy components, making it suitable for parts in automotive, aerospace, and general engineering industries.

Q: When is the coolant system used, and what are its benefits?

A: The included coolant system, complete with pump and tank, is used during grinding operations to minimize heat generation, reduce thermal deformation, and achieve superior surface finish. It helps in achieving higher accuracy, prolongs grinding wheel life, and protects the workpiece from thermal stress.

Q: Where can this grinder be installed, and what are its space requirements?

A: Thanks to its standard industrial dimensions of approximately 2800 mm (L) x 1800 mm (W) x 1500 mm (H), the TOS 2UD can be installed in most medium to large workshops. A stable and level floor is essential, with sufficient space reserved for safe operation and maintenance access.

Q: What is the usage process for internal versus external grinding?

A: For external grinding, mount the workpiece securely between centers and select the appropriate wheel and speeds. For internal grinding, use the dedicated spindle (16000 RPM) and internal grinding accessories, ensuring the part is properly supported and the spindle is aligned with the bore axis to achieve precise results.

Q: How does the automatic lubrication system benefit daily operations?

A: The automatic lubrication system continuously delivers lubricant to critical moving parts, reducing friction and wear, thus ensuring smoother movements, minimal maintenance, and extended machine life without frequent manual intervention.

Q: What are the main advantages of using the TOS 2UD 1000 mm Universal Cylindrical Grinder?

A: This machine offers high precision, robust construction, ease of control with manual and hydraulic operation, flexibility for grinding a variety of surfaces and tapers, and dependable cooling/lubrication. It's well-suited for manufacturers, exporters, and traders seeking dependable, versatile grinding capabilities.
