TOS 2Ud P2 750 mm Universal Cylindrical Grinder

Name: TOS 2Ud P2 750 mm Universal Cylindrical Grinder
Brand: Liberty Metal & Machines Private Limited
Price: 3500 INR
Availability: InStock

Price 3500 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

TOS 2Ud P2 750 mm Universal Cylindrical Grinder Specification

Product Type
Universal Cylindrical Grinder

General Use
External and internal cylindrical grinding of various materials

Material
High-grade cast iron and steel

Type
Surface Grinding Machine

Capacity
Center distance 750 mm

Weight (kg)
Approx. 2600 kg

Computerized
No

Automatic
Semi-Automatic

Control System
Manual

Drive Type
Electric

Grinding Diameter
8 mm to 290 mm

Grinding Length
750 mm

Spindle Speed
30 to 350 RPM

Grinding Wheel Size
350 x 50 x 127 mm

Voltage
415 V

Dimension (L*W*H)
Approx. 2600 x 1800 x 1400 mm

Feature
High precision, Rigid construction, Adjustable table

Color
Green

Table Traverse Speed
0.1 to 4 m/min

Workhead Speed
40 to 400 RPM

Tailstock Quill Travel
35 mm

Minimum Grinding Length
2 mm

Lubrication System
Automatic

Coolant System
Provided

Wheelhead Infeed
0.001 mm graduation

Chuck Size (for internal grinding)
80 mm

Internal Grinding Spindle Speed
12000 RPM

Swing Over Table
290 mm

Max. Weight of Work Piece Between Centers
100 kg

Main Motor Power
3 kW

About TOS 2Ud P2 750 mm Universal Cylindrical Grinder

Make - TOS-Hostivar (Czech Republic)

Model - 2Ud P2

Center Height - 150 mm

Max. Length of Job - 750 mm

Max. Diameter of Job - 290 mm

Grinding Wheel Size - 350 mm Diameter x 50 mm Width

Work-Head Speeds - 38 rpm to 380 rpm

- With Internal Grinding Attachment.

- Features like Automatic Depth Adjustment "Auto-Cut", Plunge Grinding etc.

- Features like Delay Feature & Hydraulic Tail-Stock.

- Complete with Wheel Dresser, Magnetic Coolant Filtration Unit, Coolant tank & pump.

- Machine is in excellent working conditi

Video link - https://youtu.be/72XhdqXc0Rc

High Precision Grinding Performance

Engineered for meticulous results, the TOS 2Ud P2 grinder achieves exceptional surface finishes and consistent accuracy. The combination of a 0.001 mm wheelhead infeed, adjustable table, and versatile grinding diameters makes it suitable for both internal and external applications on a variety of materials.

Robust and User-Friendly Design

The grinder features a sturdy high-grade cast iron and steel frame for optimum rigidity and reduced vibration. Semi-automatic controls, an integrated coolant system, and automatic lubrication facilitate smoother operations and reduced maintenance, ensuring user convenience even during intensive grinding cycles.

Versatility and Adaptability

Capable of handling components weighing up to 100 kg and grinding lengths up to 750 mm, the TOS 2Ud P2 is well-suited for diverse industrial environments. Its adjustable speeds, multiple spindle options, and compatibility with various materials make it a valuable addition for exporters, importers, manufacturers, and suppliers alike.

FAQs of TOS 2Ud P2 750 mm Universal Cylindrical Grinder:

Q: How does the TOS 2Ud P2 universal cylindrical grinder accommodate different workpiece sizes?

A: The grinder offers a center distance of 750 mm and a swing over table of 290 mm, allowing it to process workpieces with diameters from 8 mm up to 290 mm and weights up to 100 kg between centers, making it suitable for both small and medium-sized components.

Q: What materials can be processed with this grinder?

A: This machine is designed for both external and internal cylindrical grinding of various materials, including ferrous and non-ferrous metals, thanks to its robust construction and adaptable grinding capabilities.

Q: When is the integrated coolant system used during operation?

A: The coolant system is automatically provided during the grinding process to maintain optimal temperatures, reduce thermal deformation, and ensure consistent surface finishes on the workpiece.

Q: Where is the TOS 2Ud P2 typically utilized?

A: It is widely used in manufacturing, engineering workshops, restoration facilities, and metalworking industries, particularly by exporters, importers, suppliers, and traders handling high-precision cylindrical components.

Q: What is the benefit of the automatic lubrication system?

A: The automatic lubrication system ensures consistent and adequate lubrication of critical moving parts, reducing maintenance requirements and extending machine life by minimizing wear and tear.

Q: How is grinding accuracy maintained on this machine?

A: High precision is achieved through the machines rigid construction, fine wheelhead infeed with 0.001 mm graduation, adjustable table movement, and advanced spindle speeds for both external and internal grinding operations.
