TOS BH-40 / 2000 Heavy-Duty Cylindrical Grinder
TOS BH-40 / 2000 Heavy-Duty Cylindrical Grinder

TOS BH-40 / 2000 Heavy-Duty Cylindrical Grinder

Price 100000 INR/ Piece

MOQ : 1 Piece

TOS BH-40 / 2000 Heavy-Duty Cylindrical Grinder Specification

  • Product Type
  • Heavy-Duty Cylindrical Grinder
  • General Use
  • Precision grinding of cylindrical workpieces, suitable for industrial and toolroom applications
  • Material
  • Cast Iron (base, bed and major components)
  • Type
  • CNC / Conventional
  • Capacity
  • 2000 mm between centers
  • Weight (kg)
  • Approx. 6000 kg
  • Computerized
  • Optional
  • Automatic
  • Semi-automatic / manual
  • Control System
  • Electromechanical (with manual and hydraulic controls)
  • Drive Type
  • Electric motor driven spindle
  • Grinding Diameter
  • Max. 400 mm
  • Grinding Length
  • Max. 2000 mm
  • Spindle Speed
  • 10 2500 rpm (variable)
  • Grinding Wheel Size
  • 500 mm x 80 mm x 203 mm
  • Voltage
  • 3-phase, 400 V / 50 Hz
  • Dimension (L*W*H)
  • 4200 mm x 1850 mm x 1650 mm
  • Feature
  • Heavy-duty construction, high precision, rigid bed
  • Color
  • Industrial Grey / Blue
  • Table Traverse Speed
  • 0.1 6 m/min
  • Tailstock
  • Manually operated with taper adjustment
  • Max Load Between Centers
  • Approx. 500 kg
  • Tailstock Quill Travel
  • 50 mm
  • Work Head Swivel Range
  • 90
  • Grinding Wheel Peripheral Speed
  • 35 m/s
  • Work Head Motor Power
  • 4 kW
  • Centre Height
  • 200 mm
  • Wheel Head Swivel Range
  • 30
  • Chuck Size
  • Option for 3-jaw, up to 400 mm
  • Surface Finish
  • Up to Ra 0.2 m
  • Coolant System
  • Integrated coolant tank and pump
  • Wheel Head Motor Power
  • 7.5 kW
  • Internal Grinding Attachment
  • Optional
  • Lubrication
  • Automatic centralized lubrication


TOS BH-40 / 2000 Heavy-Duty Cylindrical Grinder Trade Information

  • Minimum Order Quantity
  • 1 Piece
  • Main Domestic Market
  • All India


About TOS BH-40 / 2000 Heavy-Duty Cylindrical Grinder

Make - TOS - Hostivar (Czech Republic)

Model - BH-40

Center Height - 205 mm

Max. Diameter of Job - 400 mm

Max. Length of Job - 2000 mm

Grinding Wheel Size - Diameter 750 mm x 80 mm Width

Least Count - 1 Micron (0.001 mm)

Work-Head Speed - 12 rpm to 400 rpm

- Features like Delay, Auto-Slow, Plunge Grinding, Rapid Travel of Table etc.

- Features like Auto-Cut, Auto-Compensation, Hydraulic Tail-Stock etc.

- Equipped with a Top-Mounted Hydraulic Wheel Dresser.

- With 5 pcs x Job Steady, Wheel Dresser, Centers, Wheel Flanges etc.

- With Magnetic Type Coolant Filtration Unit, Coolant Tank and Pump.

- Operating Manual and Electrical Drawings are available.

- Machine is in excellent working condition.


Video of The Machine -

https://youtu.be/QyeM-qOT6bE



Precision and Power for Demanding Applications

Designed for superior accuracy, the TOS BH-40 / 2000 grinder delivers consistent performance across a range of cylindrical grinding tasks. Its heavy-duty construction, advanced drive systems, and highly adjustable components enable precise machining of both large and small workpieces, making it suitable for a variety of industrial applications.


Flexible Operation and User-Friendly Controls

Operators benefit from a blend of manual and semi-automatic controls, complemented by an easy-to-use electromechanical interface. Features such as the automatic centralized lubrication system, adjustable table traverse speeds, and optional computerized controls enhance efficiency and reduce maintenance requirements, providing a seamless workflow.

FAQ's of TOS BH-40 / 2000 Heavy-Duty Cylindrical Grinder:


Q: How does the TOS BH-40 / 2000 maintain high precision during heavy-duty operations?

A: The grinder's cast iron base and bed ensure rigidity and stability, while automatic centralized lubrication and integrated coolant systems reduce thermal expansion and friction, maintaining accuracy and surface finish, even during extended use.

Q: What types of workpieces can be processed with this cylindrical grinder?

A: The TOS BH-40 / 2000 is designed to grind cylindrical workpieces up to 2000 mm in length, 400 mm in diameter, and weighing up to approximately 500 kg, making it ideal for shafts, rolls, and other precise industrial components.

Q: When should I consider using the internal grinding attachment?

A: The optional internal grinding attachment is recommended when you need to finish inner surfaces such as bores or holes inside cylindrical workpieces, offering versatility for both external and internal grinding applications.

Q: Where is the TOS BH-40 / 2000 typically utilized?

A: This grinder is widely used in industrial manufacturing, large-scale toolroom applications, and precision engineering facilities, especially where high accuracy and the capability to handle heavy, long, or large-diameter parts are essential.

Q: What is the process for switching between manual and semi-automatic modes?

A: Operators can easily switch via the machine's electromechanical controls. Manual settings are selected for detailed adjustments, while semi-automatic function streamlines repetitive tasks to improve productivity and consistency.

Q: How does the machine benefit production operations?

A: With its combination of robust structure, precision controls, integrated cooling and lubrication, and adaptability (manual, semi-auto, optional CNC), the TOS BH-40 / 2000 maximizes uptime, reduces operator fatigue, and ensures consistent, high-quality grinding results.
