TOS BHU 32/1500 Cylindrical Grinding Machine

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

TOS BHU 32/1500 Cylindrical Grinding Machine Specification

Product Type
Cylindrical Grinding Machine

General Use
Precision external and internal cylindrical grinding

Material

Type
Horizontal

Capacity
Suitable for workpieces up to 1500 mm length

Weight (kg)
Approx. 4000 kg

Computerized
No

Automatic
Semi-Automatic

Control System
Traditional manual controls (mechanical/electric)

Drive Type
Electric

Grinding Diameter
Up to 320 mm

Grinding Length
1500 mm

Spindle Speed
28 to 350 rpm (workhead)

Grinding Wheel Size
400 x 50 x 127 mm

Voltage
380-415 V, 3 Phase

Dimension (L*W*H)
Approx. 3700 x 2000 x 1700 mm

Feature
High rigidity construction, precision-ground guideways, tailstock with micro adjustment

Color
Industrial Grey/Green

Longitudinal Table Traverse
1700 mm

Made In
Czech Republic

Center Height
180 mm

Surface Finish Accuracy
Ra 0.32 m possible

Lubrication
Centralized manual lubrication system

Chuck Type
Three-jaw chuck option for workhead

Tailstock Quill Travel
40 mm

Max. Internal Grinding Depth
125 mm

Wheel Peripheral Speed
35 m/s

Max. Internal Grinding Diameter
80 mm

Table Swivel
7

Max. Workpiece Weight (Between Centers)
500 kg

Coolant System
Integrated

TOS BHU 32/1500 Cylindrical Grinding Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About TOS BHU 32/1500 Cylindrical Grinding Machine

Make - TOS - Hostivar (Czech Republic)

Model - BHU 32 / 1500

Center Height - 165 mm

Max. Diameter of Job - 320 mm

Max. Length of Job - 1500 mm

Grinding Wheel Size - Diameter 500 mm x 100 mm Width

Least Count - 1 Micron (0.001 mm)

Work-Head Speed - 12 rpm to 400 rpm

- Features like Delay, Auto-Slow, Plunge Grinding, Hydraulic Tail-Stock.

- Features like Auto-Cut, Auto-Compensation, Auto-Cycle.

- With 2 x Job Steady, Wheel Dressers, spare Wheel & Flange.

- Complete with magnetic coolant filtration unit, tank and pump.

- Machine is in excellent working condition.

Video of the Machine -

https://youtu.be/y22e85hZuaw

Precision Cylindrical Grinding Capability

The TOS BHU 32/1500 delivers accuracy and surface finish excellence for both external and internal grinding tasks. Its robust engineering allows handling of heavy workpieces and precise positioning, making it a preferred choice for industries requiring tight tolerances and superior finishes on components made from steel, cast iron, and other alloys.

Robust Construction and Intelligent Features

Built with high-rigidity materials and a traditional control system, this machine combines strength and user-friendly operation. Features like the precision-ground guideways and tailstock micro adjustments offer operators enhanced control for achieving desired grinding outcomes while maintaining machine durability.

FAQs of TOS BHU 32/1500 Cylindrical Grinding Machine:

Q: How is the maximum workpiece weight and size supported by the TOS BHU 32/1500?

A: The machine can handle workpieces weighing up to 500 kg, with a maximum grinding length of 1500 mm and diameter up to 320 mm, making it suitable for large-scale cylindrical grinding tasks.

Q: What materials can be processed on this cylindrical grinding machine?

A: It is designed to grind a variety of materials, including cast iron, steel, and other alloys, ensuring versatility across general and specialized grinding applications.

Q: When should the centralized manual lubrication system be operated?

A: The centralized manual lubrication system should be engaged prior to and during operation, as specified in the maintenance schedule, to ensure all moving parts are adequately lubricated for smooth machine performance.

Q: Where is the TOS BHU 32/1500 manufactured and what is its typical application environment?

A: This model is made in the Czech Republic and is often utilized in precision engineering workshops, manufacturing floors, and export-oriented industrial settings where high-precision cylindrical grinding is required.

Q: What process enhancements does the integrated coolant system provide?

A: The built-in coolant system dissipates heat and removes debris during grinding, which helps achieve better surface finishes and extends both wheel and workpiece life.

Q: How does the semi-automatic, traditional control system benefit operators?

A: The semi-automatic controls with mechanical and electric mechanisms offer precise manual adjustments, allowing users to fine-tune grinding operations for optimal results without the complexity of fully computerized systems.

Q: What are the main benefits of using the TOS BHU 32/1500 for precision grinding?

A: Operators benefit from its rugged design, precise micro-adjustment features, high surface finish accuracy (Ra 0.32 m), and reliable operation, making it ideal for demanding grinding needs and consistent production quality.
