TOS BU 16 Precision Universal Cylindrical Grinder

Send Inquiry

Request To Call Back

TOS BU 16 Precision Universal Cylindrical Grinder

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

TOS BU 16 Precision Universal Cylindrical Grinder Specification

Product Type
Universal Cylindrical Grinder

General Use
External and Internal Cylindrical Grinding

Material
Cast Iron, Steel

Type
Precision Grinding Machine

Capacity
200 mm (Swing over table)

Weight (kg)
1,300 kg

Computerized
No

Automatic
No

Control System
Manual

Drive Type
Electric

Grinding Diameter
2 mm to 160 mm

Grinding Length
320 mm

Spindle Speed
253,000 rpm

Grinding Wheel Size
350 x 40 x 127 mm

Voltage
380 V

Dimension (L*W*H)
2,150 x 1,370 x 1,400 mm

Feature
Precision, Sturdy Construction, Versatile Use

Color
Grey / Blue

Table Swivel
± 7°

Longitudinal Table Traverse
400 mm

Distance between Centers
400 mm

Internal Grinding Spindle Speed
12,000 rpm

Coolant System
Included

Maximum Workpiece Weight between Centers
50 kg

Wheelhead Swivel
± 30°

Main Motor Power
2.2 kW

Workhead Center Taper
Morse 4

Tailstock Center Taper
Morse 3

Crossfeed
200 mm

TOS BU 16 Precision Universal Cylindrical Grinder Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About TOS BU 16 Precision Universal Cylindrical Grinder

Make - TOS-Hostivar (Czech Republic)

Model - BU 16

Center Height - 85 mm

Max. Diameter of Job - 160 mm

Grinding Length of Job - 320 mm

Max. Length of Job between Centers - 350 mm

Grinding Wheel Size - Diameter 300 mm x 40 mm Width

Work-Head Speeds - 100 rpm to 1000 rpm

Least Count of the Machine - 1 Micron (0.001 mm)

- Equipped with Internal Grinding Attachment.

- Features like Auto-cut, Plunge and Auto-Compensation.

- Features like Auto-Slow of Table and Wheel Auto-Retraction etc.

- Micro-Feed Adjustments in both - Table Travel and in Wheel-Head Travel.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/-2wHlmrHj8M

Engineered for Precision and Versatility

The TOS BU 16 is purpose-built for external and internal cylindrical grinding operations. Its spindle speed range of 253,000 rpm and internal grinding spindle speed of 12,000 rpm support a wide array of machining applications on cast iron and steel. The machines substantial 1,300 kg weight and robust construction ensure vibration-free operation and long-lasting accuracy.

Intuitive, Manual Operation for Skilled Machinists

Designed for manual control, the BU 16 offers machinists full command over grinding parameters. Longitudinal table traverse of 400 mm and crossfeed of 200 mm facilitate processing of large and complex workpieces. With electric drive, a user-friendly layout, and reliable coolant system, operators can achieve precise finishes every cycle.

Adaptable Design for Industrial Demands

The BU 16 accommodates workpieces up to 200 mm in diameter and 320 mm in grinding length, making it suitable for both small-batch production and specialized tasks. Its Morse tapers, diverse spindle speeds, and manual adjustability make it a dependable solution for tool rooms, maintenance shops, and production environments alike.

FAQs of TOS BU 16 Precision Universal Cylindrical Grinder:

Q: How can the TOS BU 16 Precision Grinder be utilized for both internal and external grinding?

A: The TOS BU 16 is designed with versatile wheelheads that allow both external and internal grinding on a single setup. By adjusting the wheelhead position and using the internal grinding spindle (up to 12,000 rpm), operators can efficiently switch between processes, making the machine suitable for a wide range of cylindrical grinding tasks.

Q: What materials can be processed using the BU 16 cylindrical grinder?

A: This machine is primarily intended for grinding cast iron and steel components. Its precision engineering and powerful spindle enable accurate machining of these materials, delivering high-quality results for general engineering, manufacturing, and toolmaking applications.

Q: When is it beneficial to use a manual cylindrical grinder like the BU 16 instead of an automatic or computerized model?

A: Manual cylindrical grinders like the BU 16 are ideal when custom, one-off, or small batch production requires operator skill and flexibility. They enable machinists to make real-time adjustments for complex or high-precision work, making them especially valuable in tool rooms, maintenance operations, or specialized manufacturing.

Q: Where is the BU 16 typically installed and for what processes in a workshop?

A: This grinder is most often found in workshops focusing on toolmaking, repair, precision engineering, and production of cylindrical parts. It is used for processes such as shaft, sleeve, and pin grinding, as well as for internal bores requiring tight tolerances and fine finishes.

Q: How does the coolant system improve the grinding process?

A: The included coolant system minimizes heat build-up during grinding, which helps maintain dimensional accuracy and extends the life of both the grinding wheel and workpiece. This ensures consistently high surface quality and safe operation throughout extended grinding sessions.

Q: What are the key benefits of the TOS BU 16s robust construction?

A: With a 1,300 kg cast iron body and sturdy construction, the BU 16 offers stable operation with reduced vibration, resulting in exceptional surface finishes and long-term accuracy. This durability translates to lower maintenance needs and a longer service life, offering excellent value for workshops and manufacturers.
