TOS BU 16 Universal Cylindrical Grinder

Price 80000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

TOS BU 16 Universal Cylindrical Grinder Specification

Product Type
Universal Cylindrical Grinder

General Use
External and internal cylindrical grinding

Material
Cast Iron Body, Steel Components

Type
Manual

Capacity
320 mm to 500 mm center distance

Weight (kg)
Approximately 1800 kg

Computerized
No

Automatic
No

Control System
Manual Controls

Drive Type
Belt Driven

Grinding Diameter
200 mm

Grinding Length
320 mm

Spindle Speed
40 to 2,000 rpm (variable)

Grinding Wheel Size
350 x 40 x 127 mm

Voltage
415 V / 3 Phase / 50 Hz

Dimension (L*W*H)
2100 x 1400 x 1300 mm

Feature
Swivelling Wheelhead, Internal Grinding Attachment, Precision Spindle

Color
Machine Gray/Green

Max. Distance Between Centers
500 mm

Headstock Swivel
90

Lubrication System
Manual Lubrication

Tailstock Quill Travel
40 mm

Surface Finish (Ra)
0.32 m

Chuck Size
Up to 160 mm

Main Motor Power
2.2 kW

Internal Grinding Attachment
Optional

Coolant System
Provided

Max. Weight of Workpiece
40 kg

Table Swivel
7

About TOS BU 16 Universal Cylindrical Grinder

Make - TOS-Holice (Czech Republic)

Model - BU 16

Center Height - 85 mm

Max. Diameter of Job - 160 mm

Grinding Length of Job - 320 mm (350 mm)

Grinding Wheel Size - Diameter 300 mm x 40 mm Width

Work-Head Speeds - 100 rpm to 1000 rpm

Least Count of the Machine - 1 Micron

- With Internal Grinding Attachment.

- Features like Auto-cut, Plunge, Auto-Compensation, Auto-Slow etc.

- Micro-Feed Adjustments in both - Table Longitudinal Travel and in Wheel-Head Travel.

- Complete with Wheel Dresser, magnetic coolant filtration unit, coolant tank & pump.

- Machine is in excellent working condition.

Video link - https://youtu.be/sx9RM48Q4eA

Exceptional Versatility and Precision

The TOS BU 16 is tailored for shops that require both internal and external precision grinding. With a swiveling table (7) and headstock (90), users can achieve optimal grinding angles. The addition of an optional internal grinding attachment further expands its capability, enabling users to tackle various intricate configurations and complex parts with confidence.

Durable Construction for Longevity

Built with a heavy-duty cast iron body and durable steel components, this machine offers excellent vibration dampening, steady operation, and an enhanced service life. Its robust architecture, paired with manual lubrication, ensures minimal wear and long-term reliability for high-frequency operations.

User-Friendly Manual Controls

The grinders manual control system provides tactile feedback and direct oversight over every grinding operation. Whether adjusting spindle speeds, table angle, or tailstock quill travel, operators maintain precise command, making the TOS BU 16 an excellent choice for skilled machinists valuing craftsmanship and control.

FAQs of TOS BU 16 Universal Cylindrical Grinder:

Q: How do I operate the manual controls on the TOS BU 16 Universal Cylindrical Grinder?

A: Operation is straightforward through the grinders ergonomic manual controls. Adjust spindle speed, table swivel, headstock rotation, and tailstock quill using dedicated hand levers and dials, allowing for accurate and reproducible results during both external and internal grinding processes.

Q: What types of workpieces are suitable for this grinder?

A: The TOS BU 16 is designed for external and internal cylindrical grinding of components up to 500 mm between centers and 40 kg in weight. Its suitable for a wide variety of materials, including steel, and is ideal for precision engineering applications due to its high surface finish capability (Ra 0.32 m).

Q: When should I use the internal grinding attachment?

A: The optional internal grinding attachment should be used when precise grinding of internal surfaces is required, such as on bushings or bearing housings. It expands the grinders utility for workshops that frequently handle complex or multi-task jobs.

Q: Where is the TOS BU 16 manufactured and distributed?

A: This machine is manufactured in the Czech Republic and is available worldwide through various exporters, importers, manufacturers, suppliers, and traders specializing in high-precision grinding equipment.

Q: What is the process for maintaining the lubrication system?

A: The machine features a manual lubrication system. Operators should regularly lubricate specified points using appropriate oil to maintain smooth operation, reduce friction, and extend the life of mechanical components.

Q: How does the TOS BU 16 benefit my workshop?

A: The grinders combination of manual control, robust construction, and versatile grinding capabilities enables shops to achieve superior precision and excellent surface finishes, making it an asset for small-batch production, tool rooms, and maintenance environments.
