TOS BUA 16A Precision Cylindrical Grinding Machine

Send Inquiry

Request To Call Back

TOS BUA 16A Precision Cylindrical Grinding Machine

Name: TOS BUA 16A Precision Cylindrical Grinding Machine
Brand: Liberty Metal & Machines Private Limited
Price: 25000 INR
Availability: InStock

Price 25000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

TOS BUA 16A Precision Cylindrical Grinding Machine Specification

Product Type
Cylindrical Grinding Machine

General Use
Precision external and internal grinding of cylindrical surfaces

Material
Cast iron (machine body), tool steel (working parts)

Type
Universal

Capacity
160 x 630 mm (Swing x Max. Grinding Length)

Weight (kg)
Approx. 2200 kg

Computerized
No

Automatic
Semi-Automatic

Control System
Manual with mechanical controls

Drive Type
Electrical motor drive

Grinding Diameter
max. 160 mm

Grinding Length
max. 630 mm

Spindle Speed
1650 / 2100 rpm

Grinding Wheel Size
400 x 50 x 203 mm

Voltage
400 V / 50 Hz

Dimension (L*W*H)
2300 x 1700 x 1400 mm

Feature
High-precision operation, robust construction, easy operation, coolant system included

Color
Standard machine green or as required

Table Swivel Range
+ / - 7°

Minimum/Maximum Workpiece Length
30 mm / 630 mm

Surface Finish Achievable
up to 0.002 mm

Coolant Pump Power
0.09 kW

Chuck Type
Manual 3-jaw chuck (option)

Workpiece Center Height
100 mm

Wheel Peripheral Speed
33 m/s

Cross Slide Feed
Hand operated

Main Motor Power
2.2 kW

Internal Grinding Attachment
Optional

Tailstock Sleeve Taper
MT 3

Lubrication System
Centralized manual lubrication

TOS BUA 16A Precision Cylindrical Grinding Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About TOS BUA 16A Precision Cylindrical Grinding Machine

Make - TOS (Czech Republic)

Model - BUA 16A

Center Height - 85 mm

Max. Diameter of Job - 160 mm

Max. Length of Job - 250 mm

Grinding Wheel Size - Diameter 250 mm x 40 mm Width

Work-Head Speeds - 250 rpm to 710 rpm

Least Count of Wheel-Head Slide - 1 Micron

Table Rotation - +10 Degree to -10 Degree

- Micro-Feed Adjustments in both - Table Longitudinal & in Wheel-Head Travel.

- Features like Auto-Cycle, Plunge Grinding, Auto-Slow etc.

- Machine is in excellent working condition.

Video Link - https://youtu.be/XzjNrfsC5tk

Versatile Grinding Capability

The TOS BUA 16A adapts effortlessly to various grinding tasks, from precision external cylinder work to optional internal grinding with dedicated attachments. Its flexible spindle speed and table swivel range ensure consistent performance for diverse component requirements across industries.

Durable Construction & Efficient Operation

Engineered with a solid cast iron body and durable tool steel working components, this grinder ensures longevity and structural stability. The manual-mechanical controls offer intuitive operation, while the centralized lubrication system streamlines routine maintenance, maximizing uptime and production efficiency.

Exceptional Surface Finish & Accuracy

Achieve superior finishes up to 0.002 mm with the TOS BUA 16A, thanks to its fine wheel feed, high-precision spindle, and stable construction. The combination of powerful main motor and coolant system enhances accuracy and extends grinding wheel life, supporting demanding tolerance requirements.

FAQs of TOS BUA 16A Precision Cylindrical Grinding Machine:

Q: How is the TOS BUA 16A used for precision cylindrical grinding?

A: The TOS BUA 16A is designed for external and (optionally) internal grinding of cylindrical surfaces, allowing precise finishing of shafts, rods, and various round components by positioning workpieces between centers or in a manual chuck.

Q: What benefits does the centralized manual lubrication system provide?

A: The centralized manual lubrication system simplifies maintenance by enabling operators to easily lubricate all essential machine components, ensuring consistent smooth operation and prolonging the lifespan of mechanical parts.

Q: When should I consider using the internal grinding attachment?

A: You should utilize the optional internal grinding attachment when you need to achieve precise finishes on internal bores or holes within cylindrical workpieces, expanding the machines grinding versatility.

Q: Where can this grinding machine be effectively applied?

A: The TOS BUA 16A is suitable for precision engineering workshops, manufacturing plants, and tool rooms where tight tolerances and high-quality surface finishes are essential for cylindrical components.

Q: What process does the machine use to achieve high surface accuracy?

A: The grinder uses an electrically driven grinding wheel supported by a rigid spindle. Hand-operated cross slide feed and precise table movement enable controlled material removal, while the coolant system prevents overheating and maintains accuracy.

Q: How does the robust construction of the BUA 16A contribute to its performance?

A: Its cast iron frame and sturdy tool steel components minimize vibrations and deformation, leading to improved stability, greater accuracy, and consistently high-quality surface finishes even during prolonged use.
