TOS Czech FGS 50/63 Heavy Duty Universal Milling Machine

Name: TOS Czech FGS 50/63 Heavy Duty Universal Milling Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

TOS Czech FGS 50/63 Heavy Duty Universal Milling Machine Specification

Model
FGS 50/63

Rotation
360 Swivel of Universal Milling Head

Product Type
Universal Milling Machine

General Use
Heavy Duty Universal Milling

Material
Cast Iron & Alloy Steel

Type
Heavy Duty Universal

Capacity
High production capability

Weight (kg)
4150 kg

Computerized
No

Automatic
No

CNC Or Not
Conventional (Not CNC)

Control System
Manual

Table Size
360mm x 1600mm

Table Slide Way
Box Type

Floor Space
2850mm x 3070mm

Spindle Speed
28 to 1400 RPM (18 steps)

Power
7.5 kW Main Motor

Voltage
380V / 3 Phase

Dimension (L*W*H)
2850mm x 3070mm x 1950mm

Feature
High Accuracy, Robust Build, Versatile Operations

Color
Green & Grey

T-Slot Size
18 mm

Lubrication System
Centralized

Coolant System
Integrated

Table Travel (X/Y/Z)
1120mm / 360mm / 420mm

Feeds (X/Y/Z)
10 1250 mm/min

Protection Class
IP 54

Vertical Quill Travel
125 mm

Spindle Taper
ISO 50

Noise Level
Low (< 80 dB)

Horizontal Table Load Capacity
1000 kg

Number of T-Slots
5

Vertical Head Adjustment
160mm

Rapid Traverse (X/Y/Z)
2500 mm/min

TOS Czech FGS 50/63 Heavy Duty Universal Milling Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About TOS Czech FGS 50/63 Heavy Duty Universal Milling Machine

Make - TOS (Czech Republic)

Model - FGS 50/63

Table Size - 1800 mm x 630 mm

XYZ Travels - 1400 mm x 630 mm x 500 mm

Spindle Taper - ISO 50

Spindle Speeds - 35.5 rpm to 1800 rpm

Spindle Motor - 15 kW

Table Feed Rates - 10 mm/min to 1800 mm/min

Weight Load Capacity - 1500 kg

- Automatic Up/Down of Table by 0.5 mm.

- Operating Manual & Electrical Drawings are available.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/ZLTBzqEA3Zc

Heavy Duty Performance & Versatility

Designed to handle high production workloads, the FGS 50/63 milling machine boasts a rigid build of cast iron and alloy steel. Its large table, powerful spindle, and universal head rotation deliver versatility to manage a spectrum of milling operations efficiently, meeting the diverse needs of metalworking facilities.

Precision & Reliability

Featuring box-type slide ways and a high-accuracy design, this machine maintains steady, vibration-free operation for precise milling. The centralized lubrication system supports consistent performance and minimizes maintenance, while integrated coolant and noise control enhance its reliability in demanding workspaces.

Flexible Operation & Easy Control

With manual controls and an 18-step spindle speed range, operators can finely tune feeds and speeds for different materials and processes. The 360 swivel universal milling head and adjustable table allow for intricate and custom machining jobs, maximizing equipment utility for manufacturers and traders.

FAQ's of TOS Czech FGS 50/63 Heavy Duty Universal Milling Machine:

Q: How does the FGS 50/63 Universal Milling Machine optimize heavy-duty milling tasks?

A: The FGS 50/63 is built with a robust cast iron and alloy steel frame, ISO 50 spindle taper, and high-capacity table, allowing it to handle large and demanding milling assignments. Its versatile design supports continuous, accurate work in high-production settings.

Q: What types of materials can be processed using this milling machine?

A: Thanks to its solid construction, adjustable speeds (28 to 1400 RPM), and universal milling head, the FGS 50/63 can machine a broad range of metals, including steel, cast iron, and alloys, making it suitable for general and complex metalworking operations.

Q: When should I use the vertical head adjustment or swivel for machining?

A: The vertical head adjustment and 360 swivel milling head are ideal when the workpiece requires angled cuts, complex contours, or multi-face machining. This flexibility enhances process capability and broadens the scope of applications for the machine.

Q: Where is the cooling and lubrication system located, and how does it function?

A: The integrated coolant system operates during machining to prevent overheating and prolong tool life. The centralized lubrication system continuously provides oil to critical components, minimizing wear and supporting seamless movement of slide ways and table.

Q: What are the key benefits of manual control in this conventional milling machine?

A: Manual control empowers skilled operators to precisely set feeds, speeds, and adjustments for unique or intricate jobs. It provides hands-on versatility without the complexity or cost of CNC, ideal for workshops needing both flexibility and reliability.

Q: How can users maximize the machine's table capacity and load for production efficiency?

A: Utilizing the full 1000 kg horizontal table load and five 18 mm T-slots, operators can securely mount large or multiple workpieces. This maximizes throughput and streamlines fixture setups, boosting efficiency in high-volume or diverse job runs.

Q: What is the process for switching between different spindle speeds and feeds?

A: Switching spindle speeds and feeds is accomplished manually via dials on the control panel. Operators select from 18 speed steps and a wide feed range to match material and operation needs, allowing for quick adaptation during varied milling processes.
