TOS FA5H Universal Milling Machine

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

TOS FA5H Universal Milling Machine Specification

Model
FA5H

Rotation
360 Table Swivel

Product Type
Universal Milling Machine

General Use
Universal Milling Operations

Material
Cast Iron

Type
Horizontal & Vertical

Capacity
Heavy Duty

Weight (kg)
3200 kg (approx.)

Computerized
No

Automatic
Semi-Automatic

CNC Or Not
Not CNC

Control System
Manual

Table Size
1600 x 400 mm

Table Slide Way
Box Type

Floor Space
2800 x 2520 mm (approx.)

Spindle Speed
28 to 1400 rpm (18 steps)

Power
7.5 HP

Voltage
415 V

Dimension (L*W*H)
2800 x 2150 x 2000 mm (approx.)

Feature
Universal Swivel Table, Heavy Construction

Color
Green

Main Motor
5.5 kW

Table Feed Rate
22 - 1100 mm/min (longitudinal & cross)

Clamping Surface
1600 x 400 mm

Coolant Pump Motor
0.09 kW

X-Axis Travel
1250 mm

Spindle Taper
ISO 50

Number of T-Slots
3

Maximum Distance Between Table & Spindle Nose
470 mm

Y-Axis Travel
400 mm

Max. Vertical Head Spindle Speed
32 to 1600 rpm (16 steps)

Rapid Traverse Speed
3300 mm/min

T-Slot Size
18 mm

Z-Axis Travel
420 mm

Working Speed
Variable

TOS FA5H Universal Milling Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About TOS FA5H Universal Milling Machine

Make - TOS (Czech Republic)

Model - FA5H

Table Size - 2000 mm x 425 mm

XYZ Travels - 1250 mm x 425 mm x 470 mm

Spindle Taper - ISO 50

Spindle Speeds - 18 rpm to 1400 rpm

Table Travel Feed Rates - 10 mm/min to 1250 mm/min

Spindle Motor - 11 kW

- Complete with 2 x Brackets for Horizontal Milling.

- Equipped with Vertical Milling Head.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/VcXks4J1ecQ

Universal Milling Flexibility

The TOS FA5H Universal Milling Machine is engineered to handle a vast range of milling tasks owing to its horizontal and vertical spindle configuration. The swiveling table and long axis travel allow for intricate and variable angle milling, making it suitable for workshops with diverse production needs. Its adaptability makes it an excellent choice for both general purpose and specialized tasks.

Precision and Durability in One Package

Manufactured with a robust cast iron body and box-type slide ways, the FA5H is designed to maintain accuracy even during heavy-duty cycles. The machine features a strong clamping surface, 18 mm T-slots, and significant spindle travel, all supporting large workpieces while providing unwavering stability. Its build quality ensures both precision and longevity.

Operator-Friendly Manual Controls

With a manual control system and semi-automatic table feed features, the FA5H allows for hands-on operation, which is ideal for skilled machinists seeking precise control over each operation. The clear arrangement of speed steps and feeds contributes to ease of use, making the machine both productive and approachable in everyday manufacturing.

FAQs of TOS FA5H Universal Milling Machine:

Q: How does the universal swivel table benefit the FA5H milling machines usability?

A: The universal swivel table enables flexible positioning of the workpiece at various angles, supporting operations that require complex geometries or angular cuts. This adaptability significantly expands the machines versatility in performing diverse milling tasks.

Q: What types of milling operations can the TOS FA5H handle?

A: The FA5H is designed for universal milling, including both horizontal and vertical jobs. Its large table, variable spindle speeds, and sturdy construction make it suitable for heavy-duty jobs, surfacing, drilling, slotting, and angular milling.

Q: When is the best application scenario for using the FA5H Universal Milling Machine?

A: The FA5H excels in environments where a variety of part shapes and materials are processed, particularly in tool rooms, manufacturing plants, and workshops requiring sturdy, accurate, and flexible milling equipment for heavy and precise operations.

Q: Where can I position the FA5H in my workshop?

A: Due to its significant floor space (2800 x 2520 mm), the FA5H should be installed in a spacious, stable area of your workshop. Adequate clearance is necessary to facilitate smooth loading and unloading of large workpieces and unimpeded table movement.

Q: What is the process for changing spindle speeds on this milling machine?

A: The machine comes with a manual mechanism to select spindle speeds across 16 or 18 steps (depending on head). Operators can shift to the desired rpm range using the provided hand controls to suit specific cutting requirements.

Q: How does the heavy construction of the FA5H ensure precise milling results?

A: The strong cast iron frame and box-type table slide ways minimize vibrations and deflections during operation. This considerable rigidity enhances machining accuracy, especially during heavy-cutting and large part production.
