TOS Hostivar 2Ud 750 mm Universal Cylindrical Grinder

Send Inquiry

Request To Call Back

TOS Hostivar 2Ud 750 mm Universal Cylindrical Grinder

Price 55000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

TOS Hostivar 2Ud 750 mm Universal Cylindrical Grinder Specification

Product Type
Universal Cylindrical Grinder

General Use
Precision Grinding of Cylindrical Surfaces

Material
Cast Iron Body, Hardened Steel Components

Type
External & Internal Grinding

Capacity
750 mm

Weight (kg)
Approx. 2900 kg

Computerized
No

Automatic
Semi-Automatic

Control System
Manual and Electric Controls

Drive Type
Electric Motor Belt Drive

Grinding Diameter
320 mm

Grinding Length
750 mm

Spindle Speed
20 to 850 RPM (Variable)

Grinding Wheel Size
400 mm x 50 mm x 203.2 mm

Voltage
380/400 V, 50 Hz

Dimension (L*W*H)
2500 mm x 1800 mm x 1400 mm

Feature
High Precision, Robust Construction, Swiveling Wheelhead, Manual Tailstock

Color
Green & White

Table Traverse
820 mm

Centre Height
175 mm

Lubrication System
Centralized

Machine Condition
Used, Good Working Condition

Internal Grinding Spindle Speed
12000 RPM

Tailstock Quill Travel
40 mm

Max Workpiece Weight
120 kg

Coolant System
Provided

Workhead Speed
40 to 400 RPM (Infinitely Variable)

TOS Hostivar 2Ud 750 mm Universal Cylindrical Grinder Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About TOS Hostivar 2Ud 750 mm Universal Cylindrical Grinder

Make - TOS Hostivar (Czech Republic)

Model - 2Ud

Center Height - 150 mm

Max. Diameter of Job - 290 mm

Max. Length of Job - 750 mm

Grinding Wheel Size - Diameter 350 mm x 50 mm Width

Work-Head Speeds - 38 rpm to 380 rpm

- Equipped with Internal Grinding Attachment.

- Features like Auto-Cut, Delay, Auto-Slow, Plunge Grinding etc.

- Operating Manual & Electrical Drawings are available.

- Machine is in excellent working condition.

Video of The Machine-

https://youtu.be/LK5oGcqu814

Robust Construction & High Precision

Built with a sturdy cast iron frame and durable hardened steel parts, the 2Ud 750 mm grinder offers remarkable stability during precision operations. The robust construction, coupled with a high-quality swiveling wheelhead and manual tailstock, provides consistent grinding results for both external and internal cylindrical surfaces. Suitable for heavy-duty use, it ensures longevity and reliability in demanding workshops.

Versatility & Adjustable Performance

Equipped to handle workpieces up to 120 kg, this grinder features variable spindle speeds and a grinding diameter capability of up to 320 mm. The machines table traverse of 820 mm and grinding length of 750 mm allow for versatile operations on varied cylindrical components. Infinitely variable workhead speeds and internal grinding spindle speeds guarantee adaptability to different material and surface finish requirements.

Efficient Control & User-Friendly Design

The semi-automatic TOS Hostivar 2Ud offers both manual and electric controls for flexibility and ease of operation. Its centrally coordinated lubrication system and in-built coolant setup ensure smooth, efficient functioning and minimal downtimes. With a straightforward interface and reliable mechanical features, users can expect efficient workflows with minimal operator fatigue.

FAQs of TOS Hostivar 2Ud 750 mm Universal Cylindrical Grinder:

Q: How does the TOS Hostivar 2Ud Universal Cylindrical Grinder ensure high precision during operations?

A: The grinders robust cast iron body, hardened steel components, and swiveling wheelhead contribute to its overall stability and accuracy. Centralized lubrication and an efficient coolant system also maintain optimal operating conditions for precision grinding.

Q: What types of workpieces and materials can this grinder accommodate?

A: The machine is designed for grinding cylindrical surfaces on workpieces weighing up to 120 kg, with a grinding length capacity of 750 mm and diameter up to 320 mm. It is suitable for a wide range of ferrous and non-ferrous materials.

Q: When is it recommended to use the internal grinding spindle feature?

A: The internal grinding spindle, reaching speeds up to 12,000 RPM, is ideal for operations where precise internal surface finishing is required, such as in bores and sleeves within a cylindrical workpiece.

Q: Where can the TOS Hostivar 2Ud be installed and operated?

A: This machine is suitable for installation in industrial manufacturing plants, tool rooms, or workshops involved in precision machining, especially those focused on export, import, or manufacturing of metal components.

Q: What is the general process for using this machine effectively?

A: Set up the workpiece on the centers, adjust the wheelhead and select appropriate speeds, then use the manual and electric controls to initiate grinding. The coolant and lubrication systems should be engaged for efficient, high-quality results. Regular maintenance ensures sustained performance.

Q: How does the semi-automatic and manual control benefit operators?

A: Operators have flexibility to precisely control operations, making it easier to adapt to diverse work requirements. Manual intervention can fine-tune processes, and electric controls speed up repetitive tasks for improved productivity.

Q: What are the main benefits of choosing this machine for cylindrical grinding tasks?

A: The TOS Hostivar 2Ud offers high precision, versatility in handling multiple workpiece sizes, durable construction, and user-friendly operation. Its combination of mechanical and electrical features makes it ideal for both routine and specialized cylindrical grinding applications.
