TOS OF 71 Gear Hobbing Machine

Name: TOS OF 71 Gear Hobbing Machine
Brand: Liberty Metal & Machines Private Limited
Price: 8900 INR
Availability: InStock

Price 8900 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

TOS OF 71 Gear Hobbing Machine Specification

Feature
High precision, sturdy construction, and reliable performance

Color
Green

Machine Type
Gear Hobbing Machine

Voltage
415 V

Dimension (L*W*H)
2050 x 1450 x 1750 mm

Used For
Gear cutting and hobbing operations

Weight
Approximately 2500 kg

Condition
Used

Output
High quality cut gears

Capacity
Gears up to 710 mm diameter

Power
4.5 kW

Feed Range
0.57.5 mm/rev

Machine Floor Space Requirement
Approximately 3 m

Minimum Number of Teeth
6

Main Motor Power
4.5 kW

Clamping Type
Manual

Maximum Workpiece Diameter
710 mm

Coolant System
Integrated

Spindle Speed
50-200 rpm

Maximum Gear Module
10 module

Table Speed Range
40-200 rpm

Maximum Hob Diameter
160 mm

Table Bore Diameter
80 mm

About TOS OF 71 Gear Hobbing Machine

TOS (Czech Republic) make Gear Hobbing Machine in excellent working condition. The model of the machine is OF 71 and the Max.

Module capacity of the machine is 7 modules and Max. Gear Diameter is 710 mm. The technical details are as follows -

Make - TOS (Czech Republic)

Model - OF 71

Max. Module Capacity - 7 Modules

Max. Gear Diameter - 710 mm

Max. Width of Gear - 335 mm

Min. & Max. No. of Teeth - 8 to 300

Table Diameter - 630 mm

Max. Dimensions of Hob Cutter - Diameter 195 mm x 220 mm Length

Max. Gear Diameter (with Support) - 500 mm

Hob Speeds - 40 rpm to 315 rpm

- Machine is complete with Change Gears etc.

- Operating Manuals are available.

- Machine is in excellent working condition.

Video link - https://youtu.be/ITsfid2imHg

Precision Gear Cutting

Achieve high accuracy and quality with the TOS OF 71 Gear Hobbing Machines robust design and advanced features. The machines high precision, sturdy construction ensures consistent results for gears up to 710 mm in diameter, making it ideal for demanding industrial applications.

Versatile Performance

The TOS OF 71 offers a wide speed and feed range, with a table speed between 40200 rpm and feed rates from 0.5 to 7.5 mm/rev. Its capability to handle modules up to 10 and various gear sizes makes it a practical choice for diverse gear hobbing requirements.

Integrated Cooling for Reliability

The integrated coolant system helps maintain optimal cutting temperatures, prolonging tool life and ensuring superior surface finish on cut gears. This feature supports continuous, heavy-duty operations while enhancing both quality and machine longevity.

FAQs of TOS OF 71 Gear Hobbing Machine:

Q: How is the TOS OF 71 Gear Hobbing Machine operated?

A: The TOS OF 71 Gear Hobbing Machine utilizes manual clamping for workpieces and features user-adjustable settings for table and spindle speeds, allowing operators to adapt to different gear sizes and materials during hobbing operations.

Q: What types of gears can this machine produce?

A: This machine is suitable for manufacturing high-quality spur and helical gears with modules up to 10 and workpiece diameters up to 710 mm, using a hob diameter of up to 160 mm and accommodating gear teeth counts starting from as low as 6.

Q: Where is the TOS OF 71 Gear Hobbing Machine typically used?

A: It is commonly used in manufacturing plants, export/import facilities, and gear production workshops requiring precise gear cutting, particularly in industries needing high-capacity gear solutions. The machine is made in the Czech Republic and employed by exporters, importers, and manufacturers.

Q: When should the coolant system of the TOS OF 71 be used?

A: The integrated coolant system should be active during all gear hobbing and cutting operations. It helps maintain suitable temperatures for both the tool and workpiece, which increases tool life and contributes to a quality surface finish.

Q: What are the benefits of using this gear hobbing machine?

A: Users benefit from its high precision, reliable performance, robust construction, and the ability to produce gears of large diameter with consistent quality. Its flexible speed and feed settings enable adaptation to different cutting requirements, enhancing productivity and efficiency.

Q: How much space does the machine require for installation?

A: The TOS OF 71 Gear Hobbing Machine needs approximately 3 m of floor space for proper installation, considering its overall dimension of 2050 x 1450 x 1750 mm and weight of about 2500 kg.
