TOS OH-6 Gear Shaper Machine

Name: TOS OH-6 Gear Shaper Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 10000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

TOS OH-6 Gear Shaper Machine Specification

Output
High Accuracy Gear Machining

Voltage
380 V

Used For
Internal and External Gear Cutting

Dimension (L*W*H)
1950 x 1200 x 2450 mm

Machine Type
Gear Shaper Machine

Capacity
Module up to 6 mm

Condition
Used

Power
Main Motor 3.7 kW

Color
Green

Feature
Precision Gear Shaping, Robust Design, Easy Operation

Weight
Approx. 3200 kg

Control Type
Conventional Mechanical Controls

Max Number of Teeth
180

Lubrication System
Automatic Centralized Lubrication

Max Workpiece Diameter
630 mm

Feed Range
0.1 to 1.4 mm per stroke

Min Number of Teeth
10

Table Speed Range
7.5 - 120 rpm

Max Gear Width
100 mm

Shaper Cutter Stroke
90 mm

Table Bore Diameter
90 mm

Rapid Traverse
Yes

Machine Floor Space Required
2.5 m x 1.5 m

Coolant System
Integrated

TOS OH-6 Gear Shaper Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

TOS OH-6 Gear Shaper Machine About

Make - TOS (Czech Republic)

Model - OH-6

Max. Module Capacity - 6 Modules

Max. Gear Diameter - 500 mm

Max. Stroke Length - 110 mm

Stroke Rate - 50 strokes/min to 315 strokes/min

Spindle Diameter - 78 mm

Height between Table to Spindle Body - 235 mm

- Complete with its Change Gears.

- Operating Manual & Electrical Drawings are available.

- Machine is in excellent working condition.

Video of the Machine -

https://youtu.be/2ulIXsx08XU

Precision Engineering for Versatile Gear Shaping

The TOS OH-6 Gear Shaper Machine stands out for its ability to cut both internal and external gears with great precision. Thanks to its sturdy construction, adjustable feed range, and reliable controls, it meets diverse production needs. Its maximum workpiece diameter of 630 mm and gear width of 100 mm offer flexibility for a wide array of applications in gear manufacturing industries.

Efficient Operation and User-Friendly Features

Equipped with an integrated coolant system and automatic centralized lubrication, the TOS OH-6 ensures smooth and continuous operation. Rapid traverse and adjustable table speed (from 7.5 to 120 rpm) further enhance productivity. Conventional mechanical controls make the machine easy to operate and maintain, ideal for workshops aiming for high output with minimal downtime.

FAQ's of TOS OH-6 Gear Shaper Machine:

Q: How does the TOS OH-6 Gear Shaper Machine benefit gear manufacturers?

A: This gear shaper offers precision cutting for both internal and external gears, ensuring high accuracy and consistency. Its robust design and advanced features such as automatic lubrication and a rapid traverse system help boost productivity while reducing operational downtime.

Q: What range of gear sizes and types can be processed with this machine?

A: The TOS OH-6 can handle workpieces with a maximum diameter of 630 mm and cut gears with 10 to 180 teeth, up to 100 mm in width, and module sizes up to 6 mm. It is suitable for a wide variety of gear profiles and sizes.

Q: When is it advisable to use the TOS OH-6 for gear shaping tasks?

A: It is recommended for both individual and batch production when precision, efficiency, and versatility are required in internal and external gear cutting, especially in automotive, machinery, and gear manufacturing industries.

Q: Where can this gear shaper machine be installed optimally?

A: The TOS OH-6 requires a floor space of 2.5 m x 1.5 m, making it suitable for installation in medium to large workshops or gear manufacturing facilities-especially where heavy-duty and accurate machining is needed.

Q: What is the process for operating the TOS OH-6 Gear Shaper Machine?

A: Operators set the workpiece and cutter according to the gear specifications. Using mechanical controls, stroke length, feed rate, and table speed are adjusted. The automatic lubrication and integrated coolant system ensure smooth machining throughout the shaping process.

Q: How is maintenance handled for this gear shaper?

A: Regular inspection and cleaning are essential. The machine comes with an automatic centralized lubrication system, which reduces manual effort and increases component lifespan. Checking coolant levels and mechanical controls periodically will ensure optimum performance.

Q: What usage features enhance efficiency in this gear shaper?

A: Features like rapid traverse, a wide feed range (0.1 to 1.4 mm per stroke), and table speed adjustment allow operators to adapt to varying production needs. The robust frame, integrated coolant, and automatic lubrication system support prolonged, reliable operation.
